- Page 1 END USER INSTRUCTIONS Transmitters: T9-02, T9-12 T11-04, T11-14 safe smart strong ED-TG2-TX102-EN-v02 Language: English (original) T 1 1...
- Page 2 ©Tele Radio AB Datavägen 21 SE-436 32 Askim Sweden Phone: +46 (0)31 748 54 60...
-
Page 3: Table Of Contents
End user instructions│ T9/T11│ CHAPTER 1: INTRODUCTION 1.1 About this document 1.2 About Tiger TG2 systems CHAPTER 2: SAFETY 2.1 Warnings & restrictions 2.2 Safety features CHAPTER 3: TECHNICAL DATA 3.1 Transmitter specifications 3.2 Radio frequency band CHAPTER 4: PRODUCT GENERAL DESCRIPTION 4.1 Transmitter front 4.2 Transmitter back 4.3 Display and top LED CHAPTER 5: STATUS AND ERROR INDICATIONS 5.1 Top LED status indication 5.2 Error indications and messages... -
Page 4: End User Instructions│ T9/T11
End user instructions│ T9/T11│ 10.3 AEC ANNEX A: INDEX ED-TG2-TX102-EN-v02... -
Page 5: Chapter 1: Introduction
The End user instructions may be withdrawn or revised by Tele Radio AB at any time and without further notice. Corrections and updates will be added to the latest version of the manual. Always download the End user instructions from our website, www.tele-radio.com, for the latest available version. - Page 6 End user instructions│ T9/T11│ Chapter 1: Introduction Tele Radio AB products are covered by a warranty against material, construction, or manufacturing faults. See "Chapter 9: Warranty, service, repairs, and maintenance". ED-TG2-TX102-EN-v02...
-
Page 7: About This Document
Before installing or operating the product, read the corresponding documentation carefully. Tele Radio AB's product range is composed of transmitters, receivers, and accessories intended for use together as a system. These End user instructions cover general safety issues, main technical specifications, standard operating instructions and battery information. -
Page 8: About Tiger Tg2 Systems
O v er v iew o f t h e a v a il a bl e mo del s Step buttons transmitters Available frequencies Number of buttons Model Display 433 MHz 915 MHz ● ● ● T9-02 ● ● ● T9-12 ● ● ● T11-04 ● ●... -
Page 9: Chapter 2: Safety
IMPORTANT! Tele Radio AB remote controls are often built into wider applications. These systems should be equipped with: • a wired emergency stop where necessary ... - Page 10 End user instructions│ T9/T11│ Chapter 2: Safety Always follow operating and maintenance instructions as well as all applicable safety procedures and requirements. Do not open the receiver encapsulation unless you are qualified. You must satisfy the age requirements in your country for operating the equipment.
-
Page 11: Safety Features
2 .2 S af et y f eat u res 2 . 2 . 1 S T O P B UT T O N Tele Radio AB transmitters are equipped with a stop button. When the Stop button is pressed, the stop relays on the receiver deactivate. -
Page 12: Chapter 3: Technical Data
End user instructions│ T9/T11│ Chapter 3: Technical data CHAP TER 3: TECHNICAL D ATA 3 .1 T ran s m it t er s p ec if ic at io n s T9-02 T9-12 T11-04 T11-14 Number of buttons... -
Page 13: Radio Frequency Band
End user instructions│ T9/T11│ Chapter 3: Technical data 3 .2 Radio f requ en c y b an d 3 . 2 . 1 4 3 3 M H Z For radio systems operating on frequency band 433 MHz, the frequency band is divided into 69 channels (channel 1-69). - Page 14 End user instructions│ T9/T11│ Chapter 3: Technical data 3 . 2 . 2 9 1 5 M H Z Radio systems operating on frequency band 915 MHz use frequency-hopping spread spectrum (FHSS) to communicate. The frequency band is divided into 15 frequency banks (1-15).
-
Page 15: Chapter 4: Product General Description
CHAP TER 4: P RO DUCT G ENERAL DESCRIP TIO N The pictures shown in this chapter are for illustrative purposes only. 4.1 T ran s m it t er f ro n t T9-02, T9-12 T11-04, T11-14 1. Rubber cover 6. -
Page 16: Transmitter Back
End user instructions│ T9/T11│ Chapter 4: Product general description 4.2 T ran s m it t er b ac k T9-02, T9-12 T11-04, T11-14 1. Rubber cover 4. Product label 7. Charger contacts for Tele Radio AB holders 2. Clip 5. -
Page 17: Display And Top Led
End user instructions│ T9/T11│ Chapter 4: Product general description 4.3 D is p l ay an d t o p LE D 4 . 3 . 1 L C D D I S P L A Y The transmitter display is intended for receiving and visualizing feedback information from the system as well as for basic configuration. -
Page 18: Chapter 5: Status And Error Indications
End user instructions│ T9/T11│ Chapter 5: Status and error indications CHAP TER 5: STATUS AND ERRO R IND ICATIO NS 5 .1 T o p LE D s t at u s in dic at io n The top LED lights or flashes green when the battery capacity is good and red when the battery capacity is poor. -
Page 19: Chapter 6: Operation
End user instructions│ T9/T11│ Chapter 6: Operation CHAP TER 6 : O P ERATIO N 6.1 G en eral in f o rm at io n To control a receiver, the transmitter must be registered and logged in to the receiver. -
Page 20: User Permissions
End user instructions│ T9/T11│ Chapter 6: Operation 6 . 2 . 1 M A I N M E N U Buttons Action Left Start button Enter the selected menu (Select) Right Start button Exit Menu mode and turn the transmitter off (Exit) Back 1–2... -
Page 21: Functionality Test
6.4 F u n c t io n al it y t es t NOTE: This list is intended for use as a support for the manufacturer of the equipment where Tele Radio AB remote control systems are installed. Before operating the radio system, follow the procedure below. -
Page 22: Start A Session (No Pin Code)
End user instructions│ T9/T11│ Chapter 6: Operation 6.5 S t art a s es s io n ( n o P IN c o de) To be able to control a receiver with the transmitter, the transmitter must be registered in the receiver. - Page 23 End user instructions│ T9/T11│ Chapter 6: Operation 5. Release both Start buttons. The buzzer stops, the top LED flashes. The display shows: [Logging in…] Once a radio link has been established, the top LED stops flashing and remains lit, the selected receivers red LEDs go out and the stop relays activate.
-
Page 24: Start A Session (Pin Code Required)
End user instructions│ T9/T11│ Chapter 6: Operation 6.6 S t art a s es s io n ( P IN c o de requ ired) To be able to control a receiver with the transmitter, the transmitter must be registered in the receiver. If no receiver is registered, the display will show after the stop button has been pulled out. - Page 25 End user instructions│ T9/T11│ Chapter 6: Operation Go to step 5 to log in to the previously selected receiver, go to next step to select another receiver. If no receiver is selected, the red LEDs for all available receivers will flash. The display will show [Select receiver(s)] 4.
-
Page 26: Log The Transmitter Out From A Receiver
End user instructions│ T9/T11│ Chapter 6: Operation 6.7 Lo g t h e t ran s m it t er o u t f ro m a rec eiver A transmitter already logged in to the receiver has to be logged out before any other transmitter can be logged in. -
Page 27: Chapter 7: Battery
End user instructions│ T9/T11│ Chapter 7: Battery CHAP TER 7 : BATTERY 7 .1 Bat t ery p rec au t io n s Carefully read the following safety instructions and warnings before using, charging or disposing of the batteries. Batteries contain flammable substances such as lithium or other organic solvents, which may result in overheating, rupture or combustion. - Page 28 End user instructions│ T9/T11│ Chapter 7: Battery 7 . 1 . 2 D I S P O S A L When discarding batteries, insulate the + and - terminals of batteries with insulating/ masking tape. Do not place multiple batteries in the same plastic bag. Do not incinerate or dispose of batteries in fire.
-
Page 29: Battery Information
End user instructions│ T9/T11│ Chapter 7: Battery 7 .2 Bat t ery in f o rm at io n NOTE: Only batteries approved by Tele Radio AB should be used in T9/T11 transmitters. NOTE: When the battery capacity reaches approximately 10 %, the top LED lights red. - Page 30 End user instructions│ T9/T11│ Chapter 7: Battery 7 . 2 . 1 RE M O V A L O F T H E I N T E RN A L B A T T E RY ( T 9 ) Electronics and batteries must be physically separated before disposal. 1.
- Page 31 End user instructions│ T9/T11│ Chapter 7: Battery 7 . 2 . 2 C H A RG E T H E B A T T E RY NOTE: For T9 transmitters, the 1/O switch must be in the 1/on position when charging. 1.
- Page 32 End user instructions│ T9/T11│ Chapter 7: Battery 3. The top LED turns green when the battery is fully charged,. Charger unit: The charger's LED turns green when the battery is fully charged. 4. Remove the charger plug and close the protection cap. For external batteries, remove the battery from the charger unit and put it back in the transmitter.
-
Page 33: Chapter 8: Foils
End user instructions│ T9/T11│ Chapter 8: Foils CHAP TER 8: FO IL S Foils are used to customized transmitters depending on the application. Tele Radio AB foils are made of durable, soft, flexible GO-PU/SM polyurethane film with a semi-matt surface on the front side. -
Page 34: Chapter 9: Warranty, Service, Repairs, And Maintenance
Tele Radio AB products are covered by a warranty against material, construction and manufacturing faults. During the warranty period, Tele Radio AB may replace the product or faulty parts. Work under warranty must be performed by Tele Radio AB or by an authorized service center specified by Tele Radio AB. -
Page 35: Chapter 10: Regulatory Information
T11-04 1 0 . 1 . 1 C E M A RK I N G Hereby, Tele Radio AB, declares that the radio equipment type(s) listed above is/ are in compliance with the Radio Equipment Directive 2014/53/EU. The latest version of the complete EU Declaration of Conformity is available on the Tele Radio AB website, www.tele-radio.com. -
Page 36: North America
End user instructions│ T9/T11│ Chapter 10: Regulatory information 1 0 .2 No rt h A m eric a Applies to: T9-12 T11-14 1 0 . 2 . 1 F C C S T A T E M E N T This device complies with part 15 of the FCC Rules. - Page 37 End user instructions│ T9/T11│ Chapter 10: Regulatory information device. Therefore, the outside of the device into which the module is installed must also display a label referring to the radio module. The final end device must be labelled in a visible area with the following: “Contains FCC ID: ONFC1108B”...
- Page 38 End user instructions│ T9/T11│ Chapter 10: Regulatory information Le module radio est étiqueté avec sa propre identification FCC et son propre numéro de certification IC. L'identification FCC et le numéro de certification IC ne sont pas visibles lorsque le module est installé à l’intérieur d’un autre dispositif, c'est la raison pour laquelle la partie externe du dispositif dans lequel le module est installé...
- Page 39 1 0 .3 A E C Applies to: T9-02 T11-04 1 0 . 3 . 1 A E C S T A T E M E N T ( Д Е К Л А Р А Ц И Я Е А С ) This product is declared as compliant within Eurasian Economic Union (EAC).
- Page 40 End user instructions│ T9/T11│ Annex A: Index ANNEX A: IND EX AEC Statement Battery Battery information Charge Removal of internal battery Battery precautions Handling Storage Charging temperature 12, 29 Dimensions Display specifications Disposal FCC statement FCC/IC labels Foils Functionality test IC Statement IP code LCD display ED-TG2-TX102-EN-v02...
- Page 41 End user instructions│ T9/T11│ Annex A: Index Log out Quick logout M245060 Maintenance Menu navigation Number of channels Number of frequency banks Operating temperature Operating time Power supply Radio communication Radio frequency band 433 MHz 915 MHz Frequency channels Radio frequency output power Radio module Safety Features Safety levels...
- Page 42 End user instructions│ T9/T11│ Annex A: Index Start the transmitter Start with PIN code Stop button Storage temperature Battery Switch off Top LED 17-18 Transmitter back Transmitter display Transmitter front views User permission Warnings & restrictions Maintenance Operation WEEE directive Weight ED-TG2-TX102-EN-v02...
- Page 43 End user instructions│ T9/T11│ This page intentionally left blank. ED-TG2-TX102-EN-v02...
- Page 44 safe smart strong These End user instructions are subject to change without prior notice. Download the latest End user instructions from www.tele-radio.com .
