Familiarize yourself with the following safety notices used in this manual:
!
This means that if precautions are not heeded, it
may result in minor injury and/or possible machine
damage.

4.0 INTRODUCTION

This manual is provided by JET
or EHB-1018VMH. This manual contains instructions on installation, safety precautions, general operating procedures,
maintenance instructions and parts breakdown. Your machine has been designed and constructed to provide consistent,
long-term operation if used in accordance with the instructions as set forth in this document.

5.0 SPECIFICATIONS

Model Number
Stock Number
Capacity (in.):
Round at 90°
Round at 60°
Round at 45°
Rectangle at 90°
Rectangle at 60°
Rectangle at 45°
Square at 90°
Square at 60°
Square at 45°
Vise Swivel (°)
Head Movement (°)
Blade Size (in.)
Blade Wheel Diameter (in.)
Blade Wheel Speed (SFPM)
Bed Height (in.)
Motor (HP)
Overall Dimensions (in.)
Net Weight - approx. (lbs.)
Shipping Weight - approx. (lbs.)
The specifi cations in this manual were current at time of publication, but because of our
policy of continuous improvement, JET, reserves the right to change specifi cations at any
time and without prior notice, without incurring obligations.
6
®
covering the safe operation and maintenance procedures for a JET Model EHB-1018VM
EHB-1018VM
891070
10
6
10
10x17
6x5
10x12
10x10
5-1/2x5-1/2
10x10
0
60 R, 45 L
1 x .035 x 144
14
Variable 50-275
32
2 HP, 230/460V 3 Phase
CSA/CUS Certifi ed
85 x 40 x 44
1,166
1,276
!
This means that if precautions are not heeded, it
may result in serious or even fatal injury.
EHB-1018VMH
891080
10
6
10
10x17
6x5
10x12
10x10
5-1/2x5-1/2
10x10
0
60 R, 45 L
1 x .035 x 144
14
Variable 50-275
32
2 HP, 230/460V 3 Phase
CSA/CUS Certifi ed
85 x 40 x 44
1,210
1,320
Horizontal Band Saw
