Page 13: Preface
Preface This guide contains the installation instructions for the advanced Layer 3+ AT-x950-28XSQ Ethernet switch. The instructions explain how to build a virtual stack of two units with the Virtual Chassis Stacking (VCStack) feature. For instructions on how to install the switch as a stand-alone device, refer to the AT-x950-28XSQ Stand-alone Switch Installation Guide.
Page 14: Document Conventions
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury.
Page 15: Contacting Allied Telesis
AT-x950-28XSQ Switch and VCStack Installation Guide Contacting Allied Telesis For assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. The page has links to the following services: ...
Page 16 Preface...
Page 17: Chapter 1: Overview
Chapter 1 Overview The chapter contains the following sections:  “AT-x950-28XSQ Switch” on page 18  “Features” on page 19  “Ports 1 to 24 for 1Gbps SFP or 10Gbps SFP+ Transceivers” on page 21  “Ports 25 to 37 for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers, or Breakout Cables”...
Page 18: At-X950-28Xsq Switch
Chapter 1: Overview AT-x950-28XSQ Switch The front panel of the AT-x950-28XSQ Switch is shown in Figure 1. Management Panel 24 Slots for 1Gbps SFP Four Slots for 40Gbps or AT-XEM2 Line Card or 10Gbps SFP+ 100Gbps Transceivers, or Expansion Slot...
Page 19: Features
AT-x950-28XSQ Switch and VCStack Installation Guide Features The main hardware features of the advanced Layer 3+ AT-x950-28XSQ Switch are listed here. Hardware The switch has the following hardware features: Features  1RU height  24 slots for 1Gbps SFP or 10Gbps SFP+ transceivers. Refer to “Ports 1 to 24 for 1Gbps SFP or 10Gbps SFP+ Transceivers”...
Page 20: Management Software And Interfaces
Chapter 1: Overview Management Here are the management software and interfaces: Software and  AlliedWare Plus management software. Interfaces  Command line interface, available locally through the Console port or remotely over the network.  Web browser interface available remotely over the network. The AlliedWare Plus management software comes pre-installed on the switch.
Page 21: Ports 1 To 24 For 1Gbps Sfp Or 10Gbps Sfp+ Transceivers
AT-x950-28XSQ Switch and VCStack Installation Guide Ports 1 to 24 for 1Gbps SFP or 10Gbps SFP+ Transceivers Ports 1 to 24 on the AT-x950-28XSQ Switch support 1Gbps SFP or 10Gbps SFP+ transceivers. SFP and SFP+ The ports support the following types of transceivers: Transceivers ...
Page 22: Table 1: Link And Activity Status Leds For Ports 1 To 24
Chapter 1: Overview Table 1. Link and Activity Status LEDs for Ports 1 to 24 State Description Solid Green The transceiver has established a 10Gbps link to a network device. Flashing Green The transceiver is transmitting or receiving data in 10Gbps. Solid Amber The transceiver has established a 1Gbps link to a network device.
Page 23: Ports 25 To 37 For 40Gbps Qsfp+ Or 100Gbps Qsfp28 Transceivers, Or Breakout Cables
AT-x950-28XSQ Switch and VCStack Installation Guide Ports 25 to 37 for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers, or Breakout Cables Ports 25, 29, 33, and 37 support the following types of transceivers and cables:  100Gbps QSFP28 transceivers  40Gbps QSFP+ transceivers ...
Page 24: Leds
Chapter 1: Overview 4LC-10, in lengths of 5 and 10 meters, respectively, with duplex LC connectors. Refer to Figure 5. Figure 5. ET3-MPO08-4LC-5 or ET3-MPO08-4LC-10 Fiber Optic Breakout Cable LEDs The ports have one link and activity status LED each. Refer to Figure 6. Bottom Transceiver Slot Top Transceiver Slot Figure 6.
Page 25: Port Numbering
AT-x950-28XSQ Switch and VCStack Installation Guide Table 2. Link and Activity Status LEDs for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers (Continued) State Description Flashing Amber The transceiver is transmitting or receiving data at 40Gbps. Possible causes of this state are listed here: - The slot is empty.
Page 26: Table 4: Port Numbering For Ports 25 To 37
Chapter 1: Overview Table 4. Port Numbering for Ports 25 to 37 With Fiber Optic With Breakout Port Transceiver or Cable Direct Attach Cable portn.0.25 portn.0.25 portn.0.26 portn.0.27 portn.0.28 portn.0.29 portn.0.29 portn.0.30 portn.0.31 portn.0.32 portn.0.33 portn.0.33 portn.0.34 portn.0.35 portn.0.36 portn.0.37 portn.0.37 portn.0.38 portn.0.39...
Page 27: Xem2 Series Ethernet Line Cards
AT-x950-28XSQ Switch and VCStack Installation Guide XEM2 Series Ethernet Line Cards The AT-x950-28XSQ Switch has one expansion slot on the front panel for an optional XEM2 Series Ethernet line card. The cards are shown in Figure 7 and described in the following sections.
Page 28: Xem2-12Xt Line Card
Chapter 1: Overview XEM2-12XT Line Card The XEM2-12XT Line Card is shown in Figure 8. Figure 8. XEM2-12XT Line Card RJ-45 Ports The card has 12 twisted pair ports with standard 8-pin RJ-45 ports. The specifications of the ports are listed in Table 5. Table 5.
Page 29: Leds
AT-x950-28XSQ Switch and VCStack Installation Guide Table 5. Twisted Pair Ports on the XEM2-12XT Line Card (Continued) Specification Description Maximum Distance 100 meters (328 feet) Connector 8-pin RJ-45 LEDs Each port has a single LED that displays link and activity information.
Page 30: Xem2-12Xs Line Card
Chapter 1: Overview XEM2-12XS Line Card The XEM2-12XS Line Card is shown in Figure 9. Figure 9. XEM2-12XS Line Card Transceivers The card has twelve ports that support the following types of 1Gbps SFP or 10Gbps SFP+ transceivers:  1Gbps SX or LX SFP transceivers ...
Page 31: Table 7: Port Link And Activity Leds On The Xem2-12Xs Line Card
AT-x950-28XSQ Switch and VCStack Installation Guide Table 7. Port Link and Activity LEDs on the XEM2-12XS Line Card State Description Solid Green The transceiver has established a 10GBase link to a network device. Flashing Green The transceiver is transmitting or receiving data at 10GBase.
Page 32: Xem2-4Qs Line Card
Chapter 1: Overview XEM2-4QS Line Card The XEM2-4QS Line Card is shown in Figure 10. Figure 10. XEM2-4QS Line Card Transceivers The card supports the following types of 40Gbps QSFP+ transceivers in its four ports:  QSFPSR4 transceiver - Maximum operating distance of 150 meters (492 feet) with 12-strand OM4 fiber optic cable.
Page 33 AT-x950-28XSQ Switch and VCStack Installation Guide Table 8. Port Link and Activity Status LEDs on the XEM2-4QS Line Card State Description Flashing Green The transceiver is transmitting or receiving data. Possible causes of this state are listed here: - The slot is empty.
Page 34: Xem2-1Cq Line Card
Chapter 1: Overview XEM2-1CQ Line Card The XEM2-1CQ Line Card is shown in Figure 11. Figure 11. XEM2-1CQ Line Card Transceivers The one port on the card supports the following 100Gbps QSFP28 transceivers:  QSFP28SR4 transceiver - Maximum operating distance of 70m (230 ft) or 100m (328 ft) with 12-strand OM3 or OM4 fiber optic cable, respectively.
Page 35 AT-x950-28XSQ Switch and VCStack Installation Guide Table 9. Port Link and Activity Status LED on the XEM2-1CQ Line Card State Description Flashing Green The transceiver is transmitting or receiving data. Possible causes of this state are listed here: - The slot is empty.
Page 36: Management Panel
The management panel is not field-replaceable. USB Port You can use the USB port with a flash drive to perform the following management functions:  Provide a centralized network backup location for Allied Telesis Management Framework.  Store backup copies of configuration files. ...
Page 37: Net Mgmt Ethernet Management Port
AT-x950-28XSQ Switch and VCStack Installation Guide configuration file from flash drive. Using a flash drive with the switch is optional. NET MGMT The switch uses the NET MGMT port as a separate routed eth0 interface. The interface is not part of the switching matrix, but the switch can route Ethernet traffic in or out of the port from the network ports and Ethernet line card.
Page 38: Console (Rs-232) Port
Chapter 1: Overview Table 10. Twisted Pair Cable for the NET MGMT Port on the Management Panel Cable Type 10Mbps 100Mbps 1000Mbps Standard TIA/EIA 568-C- compliant Category 6a shielded cabling. For instructions on how to configure the NET MGMT port, refer to the Software Reference for x950 Switch, AlliedWare Plus Operating System.
Page 39: Figure 13: Switch Id Led With The Eco-Friendly Mode Disabled
AT-x950-28XSQ Switch and VCStack Installation Guide The switch is booting up. The switch has encountered a fault condition. The VCStack feature is disabled. The switch is operating as a stand-alone unit, with the ID number 1. The switch is a member of a VCStack and has an ID number in the range of 1 to 8.
Page 40: Eco-Friendly Button
Chapter 1: Overview eco-friendly You use the eco-friendly button on the management panel to turn the LEDs on or off. You might turn off the LEDs when you are not using them Button to monitor the control and Ethernet line cards, to conserve electricity. When the LEDs are off, the overall power consumption of the chassis is reduced by approximately 2 watts.
Page 41: Optional Direct Attach Cables
AT-x950-28XSQ Switch and VCStack Installation Guide Optional Direct Attach Cables The optional direct attach cables listed in Table 12 offer an economical way to add 10Gbps, 40Gbps, or 100Gbps connections over short distances for the base ports and XEM2 Line Cards.
Page 42: At-Pwr600 Power Supply
Chapter 1: Overview AT-PWR600 Power Supply The AT-PWR600 module is the power supply for the switch. The model name can be found on a label on the release tab on the front panel. Refer to Figure 15. Figure 15. AT-PWR600 Power Supply Here are the power supply guidelines: ...
Page 43: Leds
The power supplies are installed in the PSU A and PSU B slots in the rear panel of the chassis. If you are installing only one power supply, Allied Telesis recommends installing it in PSU A slot because that slot does not come with a blank slot cover.
Page 44: At-Fan05 Cooling Fan
Chapter 1: Overview AT-FAN05 Cooling Fan The cooling unit for the chassis is the AT-FAN05 Fan module. Refer to Figure 16. Figure 16. AT-FAN05 Fan Module Here are the fan module guidelines:  The switch comes with two pre-installed fan modules in FAN A and FAN B slots on the rear panel.
Page 45: Designating Ports In The Command Line Interface
AT-x950-28XSQ Switch and VCStack Installation Guide Designating Ports in the Command Line Interface The individual ports on the switch are identified with the PORT parameter in the command line interface of the AlliedWare Plus management software. The format of the parameter is shown in Figure 17.
Page 46 Chapter 1: Overview You must include the PORT parameter when identifying individual ports, and omit it from the last port when specifying ranges. Here are examples of the PORT parameter in the INTERFACE command for switches in a stack. The first example enters the port Interface mode for base port 11 in a switch with ID 1: awplus>...
Page 47: Chapter 2: Virtual Chassis Stacking
Chapter 2 Virtual Chassis Stacking The sections in this chapter are listed here:  “Overview” on page 48  “Stacking Guidelines” on page 49  “Stack Trunks” on page 50  “Master and Member Switches” on page 59  “Switch ID Numbers” on page 60 ...
Page 48: Overview
Chapter 2: Virtual Chassis Stacking Overview The Virtual Chassis Stacking (VCStack) feature lets you build a virtual stack of two AT-x950-28XSQ switches. The feature allows the switches to function as a single networking unit, with the following benefits:  Simplifies management - You can manage the devices of the stack as a single unit, rather than individually.
Page 49: Stacking Guidelines
No additional software or license is required.  The default setting for the VCStack feature on the AT-x950-28XSQ Switch is disabled. Enabling it requires rebooting the switch. Instructions later in this guide explain how to enable the feature and reboot the unit.
Page 50: Stack Trunks
The fiber optic transceivers or direct attach cables of a trunk must be from Allied Telesis. Transceivers or cables from other network equipment providers might not perform properly in stack trunks. For a list of supported transceivers, refer to the Allied Telesis web site. ...
Page 51: Figure 20: Stack Trunk Of Four 10Gbps Links Of Sfp+ Transceivers In The Base 10Gbps Slots
AT-x950-28XSQ Switch and VCStack Installation Guide  You can use any base 10Gbps transceivers slots for a trunk.  There are no default trunk transceiver slots.  The base 10Gbps transceiver slots also support 1Gbps transceivers. However, you cannot use 1Gbps transceivers in stack trunks.
Page 52: Figure 21: Invalid 10Gbps Trunk Of Only One Link
Chapter 2: Virtual Chassis Stacking 10Gbps Figure 21. Invalid 10Gbps Trunk of Only One Link  As mentioned earlier, a 10Gbps trunk can have either fiber optic transceivers or AT-SP10TW direct attach twinax cables. However, a trunk cannot have both types of cables. An example of this type of invalid trunk is shown in Figure 22.
Page 53: 40/100Gbps Transceiver Slots
AT-x950-28XSQ Switch and VCStack Installation Guide  A stack trunk cannot have both 10Gbps base slots and 10Gbps transceivers in AT-XEM2-4QS Line Cards. An example of an invalid trunk of four 10Gbps links of both base and line card transceivers is shown in Figure 24.
Page 54: Figure 26: Stack Trunk Of Four 40Gbps Links
Chapter 2: Virtual Chassis Stacking 40Gbps Figure 26. Stack Trunk of Four 40Gbps Links  A stack trunk of 100Gbps transceivers must have two links. An example is shown in Figure 27. 100Gbps Figure 27. Stack Trunk of Two 100Gbps Links Here are examples of invalid 40Gbps or 100Gbps trunks: ...
Page 55: Optional Xem2 Line Cards
AT-x950-28XSQ Switch and VCStack Installation Guide attach cables. Refer to Figure 29. Direct Attach Fiber Optic Cable Cable Figure 29. Invalid Trunk with Both Fiber Optic and Direct Attach Cables  You cannot use a 10Gbps breakout cable for a trunk. Refer to Figure 30.
Page 56: Figure 31: Example Of A Stack Trunk Using At-Xem2-12Xt Line Cards
Chapter 2: Virtual Chassis Stacking 1. The AT-XEM2-12XT Line Card supports both 1Gbps and 10Gbps on its ports. However, static trunks require 10Gbps. 2. The AT-XEM2-12XS Line Card supports both 1Gbps SFP and 10Gbps SFP+ transceivers. However, static trunks require 10Gbps SFP+ transceivers. ...
Page 57: Figure 33: Invalid Stack Trunk Of Transceivers In At-Xem2-12Xs Line Card And 10Gbps Base Slots
Figure 34. Invalid 100Gbps Stack Trunk of Base 100Gbps Slots and AT- XEM2-1CQ Line Cards  Allied Telesis does not recommend using the AT-XEM2-1CQ Line Card for a stack trunk because it has only one transceiver slot and the switch has only one expansion slot. Consequently, the trunk would have only one link.
Page 58: Additional Guidelines
Chapter 2: Virtual Chassis Stacking Additional Here are additional guidelines: Guidelines  The base 10Gbps transceiver slots and AT-XEM2-12XS Line Card support 1Gbps transceivers. However, stack trunks do not support 1Gbps transceivers.  Trunk links must be direct connections between ports on the switches, without any intervening network devices, such as media converters, routers, or other Ethernet switches.
Page 59: Master And Member Switches
AT-x950-28XSQ Switch and VCStack Installation Guide Master and Member Switches One switch of a stack functions as a master switch. Its main functions are listed here:  Coordinate and monitor stack operations.  Verify that the switches are using the same version of management software.
Page 60: Switch Id Numbers
Chapter 2: Virtual Chassis Stacking Switch ID Numbers Each switch must be assigned an ID number. The range is 1 to 4. The default is 1. The ID numbers are displayed on the ID LEDs on the front panels of the units. You can assign the numbers yourself or let the master switch assign the numbers automatically when you first power on the stack.
Page 61: Optional Feature Licenses
Allied Telesis. Contact your authorized reseller or distributor for a list of optional features licenses for this product. Here are the guidelines to feature licenses for a stack of AT-x950-28XSQ Series switches: ...
Page 62 Chapter 2: Virtual Chassis Stacking...
Page 63: Chapter 3: Beginning The Installation
Chapter 3 Beginning the Installation The chapter contains the following sections:  “Reviewing Safety Precautions” on page 64  “Installation Options” on page 69  “Choosing a Site for the Chassis” on page 70  “Unpacking the Switch” on page 71 ...
Page 64: Reviewing Safety Precautions
Chapter 3: Beginning the Installation Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedure. Note Safety statements that have the  symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/support. Warning Class 1 Laser product.
Page 65 AT-x950-28XSQ Switch and VCStack Installation Guide Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord.  E3 Warning Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet.
Page 66  E25 Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28 Note Use dedicated power circuits or power conditioners to supply reliable electrical power to the device.
Page 67 AT-x950-28XSQ Switch and VCStack Installation Guide Note If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than the room ambient temperature. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).
Page 68 Chapter 3: Beginning the Installation Warning The temperature of an operational SFP or SFP+ transceiver may exceed 70° C (158° F). Exercise caution when removing or handling transceivers with unprotected hands.  E43 Warning The chassis must be supplied by a grounded three wire AC source through the power supply cord.
Page 69: Installation Options
AT-x950-28XSQ Switch and VCStack Installation Guide Installation Options Figure 37 illustrates the four installation options. Tabletop 19-inch Equipment Rack with Standard Brackets 19-inch Equipment Rack with Optional AT-RKMT-SL01 Wall Installation with Sliding Rack Mount Kit Standard Brackets Figure 37. Installation Options...
Page 70: Choosing A Site For The Chassis
Chapter 3: Beginning the Installation Choosing a Site for the Chassis Observe these site requirements.  If you are installing the device in an equipment rack, check that the rack is safely secured so that it will not tip over. Devices should be installed in the rack starting at the bottom, with the heavier devices near the bottom of the rack.
Page 71: Unpacking The Switch
AT-x950-28XSQ Switch and VCStack Installation Guide Unpacking the Switch To unpack the switch from its shipping box, perform the following procedure: 1. Remove the accessories and documents from the accessory partition. Refer to Figure 38. Figure 38. Removing Accessories 2. Remove the accessory partition. Refer to Figure 39 on page 72.
Page 72: Figure 39: Removing The Shipping Partition
Chapter 3: Beginning the Installation Figure 39. Removing the Shipping Partition 3. Lift the switch from the shipping box and place it on a level, secure table. Refer to Figure 40 on page 73. Warning The switch is heavy. Ask for assistance lifting the device out of the shipping box.
Page 73: Figure 40: Lifting The Switch From The Shipping Box
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 40. Lifting the Switch from the Shipping Box 4. Remove the switch from the shipping end-caps and protective bag. Refer to Figure 41. Figure 41. Removing the Switch from the Shipping End-caps and...
Page 74 Chapter 3: Beginning the Installation 5. Visually inspect the product for damage. 6. Visually inspect the front panel for the components shown in Figure 1 on page 18. 7. Verify that there are two pre-installed fan modules in FAN A and FAN B slots on the rear panel.
Page 75: Verifying The Accessory Kit
AT-x950-28XSQ Switch and VCStack Installation Guide Verifying the Accessory Kit Figure 42 lists the accessory items that are included with the switch. One 2 m (6.6 ft) local management cable with RJ-45 (8P8C) and DB-9 (D-sub 9-pin) connectors. Sixteen bracket screws...
Page 76 Chapter 3: Beginning the Installation Note If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. After unpacking the switch and verifying the accessory kit, go to “Unpacking the AT-PWR600 AC Power Supply” on page 77.
Page 77: Unpacking The At-Pwr600 Ac Power Supply
AT-x950-28XSQ Switch and VCStack Installation Guide Unpacking the AT-PWR600 AC Power Supply To unpack the AT-PWR600 Power Supply, perform the following procedure: 1. Remove the power cord and any documents from the accessory partition. Refer to Figure 43. Figure 43. Removing the Power Cord and Documents from the AT- PWR600 AC Power Supply 1.
Page 78: Figure 44: Removing The Partition From The At-Pwr600 Ac Power Supply Shipping Box
Chapter 3: Beginning the Installation Figure 44. Removing the Partition from the AT-PWR600 AC Power Supply Shipping Box 2. Lift the power supply from the shipping box and place it on a level, secure table. Refer to Figure 45 on page 79. Warning The power supply is heavy.
Page 79: Figure 45: Removing The Power Supply From The Shipping Box
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 45. Removing the Power Supply from the Shipping Box 3. Remove the power supply from the shipping end-caps and protective shipping bag. Refer to Figure 46. Figure 46. Removing the Power Supply from the Shipping End-caps and Protective Bag 4.
Page 80 Chapter 3: Beginning the Installation...
Page 81: Chapter 4: Installing Power Supplies And Optional Xem2 Line Card
Chapter 4 Installing Power Supplies and Optional XEM2 Line Card This chapter has the following procedures:  “Installing PWR600 AC Power Supplies” on page 82  “Installing an Optional XEM2 Ethernet Line Card” on page 86...
Page 82: Installing Pwr600 Ac Power Supplies
PSU A and PSU B on the left side of the rear panel. If you are installing only one power supply, you can install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel.
Page 83: Figure 47: Removing The Blank Power Supply Panel From Slot Psu B
AT-x950-28XSQ Switch and VCStack Installation Guide Release Tab Figure 47. Removing the Blank Power Supply Panel from Slot PSU B 3. Carefully align the power supply in the slot and slide it into the slot. Figure 48 on page 84 shows the module aligned for the PSU A slot.
Page 84: Figure 48: Sliding The Pwr600 Ac Power Supply Into The Switch
Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Figure 48. Sliding the PWR600 AC Power Supply into the Switch 4. When the power supply makes contact with the connector inside the switch, gently press on its faceplate to seat it on the connector. Refer to Figure 49 on page 85.
Page 85: Figure 49: Seating The Power Supply On The Internal Connector
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 49. Seating the Power Supply on the Internal Connector 5. Visually inspect the power supply to be sure that its faceplate is flush against the rear panel of the chassis. 6. If you purchased two power supplies for the switch, repeat this procedure to install the second unit.
Page 86: Installing An Optional Xem2 Ethernet Line Card
Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Installing an Optional XEM2 Ethernet Line Card This section contains the procedure for installing an optional XEM2 Ethernet line card in the expansion slot in the front panel of the switch. For background information, refer to “XEM2 Series Ethernet Line Cards”...
Page 87: Figure 51: Removing The Ethernet Line Card From The Anti-Static Bag
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 51. Removing the Ethernet Line Card from the Anti-static Bag 3. Position the line card with the notch on the faceplate in the bottom left corner, as shown in Figure 52, and carefully slide it into the slot.
Page 88: Figure 53: Seating The Ethernet Line Card In The Expansion Slot
Chapter 4: Installing Power Supplies and Optional XEM2 Line Card 4. When the line card makes contact with the internal connector in the switch. gently press on the sides of its faceplate to seat it on the connector. Refer to Figure 53. Figure 53.
Page 89: Figure 54: Tightening The Two Captive Screws On The Ethernet Line Card
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 54. Tightening the Two Captive Screws on the Ethernet Line Card 7. After installing the power supplies and optional XEM2 Line Card, go to one of the following chapters:  Chapter 5, “Installing the Switch on a Table” on page 91 ...
Page 90 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card...
Page 91: Chapter 5: Installing The Switch On A Table
Chapter 5 Installing the Switch on a Table This chapter contains the instructions for installing the switch on a table or desktop. Warning Switches should not be stacked on a table or desktop. They could present a physical safety hazard if you need to move or replace switches.
Page 92: Figure 56: Holes For Bumper Feet
Chapter 5: Installing the Switch on a Table Rear of Chassis Front of Chassis Figure 56. Holes for Bumper Feet Note The following procedure assumes that you have already reviewed the information and performed the procedures in Chapter 3, “Beginning the Installation” on page 63. To install the switch on a table, perform the following procedure: 1.
Page 93: Figure 58: Placing The Bumper Foot On A Base Corner Hole
AT-x950-28XSQ Switch and VCStack Installation Guide 3. Place the bumper foot onto one of the holes in the base of the switch. Refer to Figure 58. Figure 58. Placing the Bumper Foot on a Base Corner Hole 4. Insert the rivet to secure the bumper foot to the base. Refer to Figure 59.
Page 94 Chapter 5: Installing the Switch on a Table Supplies” on page 82.  To install an optional XEM2 Ethernet Line Card, go to “Installing an Optional XEM2 Ethernet Line Card” on page 86.  After installing both switches of the stack, go to Chapter 8, “Configuring Switches for Stacking”...
Page 95: Chapter 6: Installing The Switch In An Equipment Rack
Chapter 6 Installing the Switch in an Equipment Rack This chapter contains the instructions for installing the switch in a standard 19-inch equipment rack. The procedures in this chapter are listed here:  “Beginning the Installation” on page 96  “Removing the Bumper Feet”...
Page 96: Beginning The Installation
Chapter 6: Installing the Switch in an Equipment Rack Beginning the Installation This chapter contains the procedure for installing the switch in a standard 19-inch equipment rack, with the brackets included with the unit. Required Items The following items are required to install the switch in an equipment rack: ...
Page 97: Figure 61: At-X950 Switch Orientations In An Equipment Rack
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 61. AT-x950 Switch Orientations in an Equipment Rack...
Page 98: Removing The Bumper Feet
Chapter 6: Installing the Switch in an Equipment Rack Removing the Bumper Feet The bumper feet included with the switch should not be used when installing the device in an equipment rack. If they are already installed, perform the following procedure to remove them: 1.
Page 99: Installing The Switch
Please review the information and perform the procedures in Chapter 3, “Beginning the Installation” on page 63 before installing the switch. Caution The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28...
Page 100: Figure 63: Attaching The Equipment Rack Brackets
Chapter 6: Installing the Switch in an Equipment Rack Figure 63. Attaching the Equipment Rack Brackets 4. Have another person hold the switch in the equipment rack while you secure it using standard equipment rack screws (not provided). Refer to Figure 64. Figure 64.
Page 101 AT-x950-28XSQ Switch and VCStack Installation Guide  To install an optional XEM2 Ethernet Line Card, go to “Installing an Optional XEM2 Ethernet Line Card” on page 86.  After installing both switches of the stack, go to Chapter 8, “Configuring Switches for Stacking” on page 119.
Page 102 Chapter 6: Installing the Switch in an Equipment Rack...
Page 103: Chapter 7: Installing The Switch On A Wall
Chapter 7 Installing the Switch on a Wall The procedures in this chapter are listed here:  “Switch Orientations on a Wall” on page 104  “Recommended Minimum Wall Area Dimensions” on page 105  “Plywood Base for a Wall with Wooden Studs” on page 107 ...
Page 104: Switch Orientations On A Wall
Chapter 7: Installing the Switch on a Wall Switch Orientations on a Wall You can install the switch on a wall with the front panel on the left or right, as shown in Figure 65. Do not install it with the front panel on the top or bottom.
Page 105: Recommended Minimum Wall Area Dimensions
AT-x950-28XSQ Switch and VCStack Installation Guide Recommended Minimum Wall Area Dimensions The recommended minimum dimensions for the reserved wall area for the switch are listed here:  Width: 77.4 centimeters (31 inches)  Height: 58.4 centimeters (23 inches) Figure 66 and Figure 67 on page 106 illustrate the recommended positions of the switch in the reserved area when the front panel is on the left and right, respectively.
Page 106: Figure 67: Minimum Wall Area Dimensions With The Front Panel On The Right
Chapter 7: Installing the Switch on a Wall Figure 67. Minimum Wall Area Dimensions with the Front Panel on the Right...
Page 107: Plywood Base For A Wall With Wooden Studs
AT-x950-28XSQ Switch and VCStack Installation Guide Plywood Base for a Wall with Wooden Studs If you are installing the switch on a wall that has wooden studs, Allied Telesis recommends using a plywood base for the device. (A plywood base is not required for a concrete wall.) Refer to Figure 68.
Page 108: Figure 69: Steps To Installing The Switch With A Plywood Base
Chapter 7: Installing the Switch on a Wall brackets on the switch is 37 centimeters (14 1/2 inches). The recommended minimum dimensions of the plywood base are listed here:  Width: 58.4 centimeters (23 inches)  Height: 55.9 centimeters (22 inches) ...
Page 109: Installation Guidelines
AT-x950-28XSQ Switch and VCStack Installation Guide Installation Guidelines Here are the guidelines to installing the switch on a wall:  You may install the switch on a wall that has wooden studs.  You may install it on a concrete wall.
Page 110 Chapter 7: Installing the Switch on a Wall  Cross-head screwdriver (not provided)  Stud finder for a wooden wall, capable of identifying the middle of wall studs and hot electrical wiring (not provided)  Drill and 1/4” carbide drill bit for a concrete wall (not provided) ...
Page 111: Installing The Plywood Base
AT-x950-28XSQ Switch and VCStack Installation Guide Installing the Plywood Base A plywood base is recommended when installing the switch on a wall that has wooden studs. Refer to “Plywood Base for a Wall with Wooden Studs” on page 107. Consult a qualified building contractor for installation instructions for the plywood base.
Page 112: Installing The Switch On The Plywood Base
This procedure assumes that the plywood base for the switch is already installed on the wall. Please review “Reviewing Safety Precautions” on page 64 and “Choosing a Site for the Chassis” on page 70 before performing this procedure. Allied Telesis recommends a minimum of three people for this procedure. Warning The device is heavy.
Page 113: Figure 71: Attaching The Switch To The Plywood Base
AT-x950-28XSQ Switch and VCStack Installation Guide The sides of the switch have two sets of holes. One set is for installing the switch on a wall with the brackets and the other is for the AT- RKMT-SL01 Rack Mounting Kit. For this procedure, you need to use the bracket holes, identified in Figure 60 on page 96.
Page 114 Chapter 7: Installing the Switch on a Wall 4. Do one of the following:  To install the power supplies, go to “Installing PWR600 AC Power Supplies” on page 82.  To install an optional XEM2 Ethernet Line Card, go to “Installing an Optional XEM2 Ethernet Line Card”...
Page 115: Installing The Switch On A Concrete Wall
AT-x950-28XSQ Switch and VCStack Installation Guide Installing the Switch on a Concrete Wall Allied Telesis recommends a minimum of three people for this procedure. To install the switch on a concrete wall, perform the following procedure: Warning The device is heavy. Always ask for assistance before moving or lifting it to avoid injuring yourself or damaging the equipment.
Page 116: Figure 72: Marking The Locations Of The Bracket Holes On A Concrete Wall
3. Please review the following guidelines:  Prior to drilling, set the drill to hammer and rotation mode. The modes break up the concrete and clean out the hole.  Allied Telesis recommends cleaning out the holes with a brush or compressed air.
Page 117: Figure 73: Installing The Switch On A Concrete Wall
AT-x950-28XSQ Switch and VCStack Installation Guide 6. Insert the four anchors into the holes. 7. Have two people hold the switch at the selected wall location while you secure it to the wall with the four provided screws. Refer to Figure 73.
Page 118 Chapter 7: Installing the Switch on a Wall...
Page 119: Chapter 8: Configuring Switches For Stacking
Chapter 8 Configuring Switches for Stacking This chapter contains the following sections:  “Introduction” on page 120  “Command Summary” on page 121  “Powering On a Switch” on page 124  “Starting a Local Management Session” on page 127 ...
Page 120: Introduction
Chapter 8: Configuring Switches for Stacking Introduction This chapter contains instructions on how to configure switches for stacking with VCStack. Please review the following information before performing the instructions:  The procedures should be performed in the order presented here. ...
Page 121: Command Summary
You must reset the switch after designating ports for 100Gbps transceivers or after replacing 100Gbps transceivers with 40Gbps transceivers or breakout cables. Allied Telesis recommends configuring these ports during the initial configuration procedure even if you do not intend to use them as the stack trunk.
Page 122: Stackport
MAC address, the higher the priority. A switch can have only one priority number. Allied Telesis recommends making a switch’s priority and ID numbers the same. This is not required, but it can make managing and troubleshooting a stack easier.
Page 123: Stack Renumber
This example changes the switch’s ID from 1 to 2: awplus(config)# stack 1 renumber 2 SWITCH To ensure that the first power-on of the stack is successful, Allied Telesis recommends configuring the units such that each unit knows about the PROVISION other prior to forming the stack.
Page 124: Powering On A Switch
Chapter 8: Configuring Switches for Stacking Powering On a Switch To power on an AT-x950-28XSQ Switch, perform the following procedure: 1. Connect the AC power cord included with the power supply to the AC power connector on the rear panel of the chassis. If the switch has two power supplies, you only need to power on one of them to configure the switch.
Page 125: Figure 75: Securing The Power Cord With The Restraining Strap
AT-x950-28XSQ Switch and VCStack Installation Guide Tab Slot Figure 75. Securing the Power Cord with the Restraining Strap 3. Connect the power cord to an appropriate AC power source. Refer to Figure 76. Note The illustration shows the North American power cord. Your power cord may be different.
Page 126 Chapter 8: Configuring Switches for Stacking Note If the switch has two power supplies, you do not have to power on both of them to perform the procedures in this chapter. 4. Wait two minutes for the switch to initialize its management software. Afterwards, go to “Starting a Local Management Session,”...
Page 127: Starting A Local Management Session
AT-x950-28XSQ Switch and VCStack Installation Guide Starting a Local Management Session This procedure explains how to start a local management session on the switch. It assumes that you powered on the device and waited two minutes for it to initialize its operating software.
Page 128: Figure 78: User Exec Mode Prompt
Chapter 8: Configuring Switches for Stacking  Parity: None  Stop bits: 1  Flow controller: None Note The port settings are for a DEC VT100 or ANSI terminal, or an equivalent terminal emulator program. 4. Press Enter. You are prompted for a user name and password. 5.
Page 129: Configuring The Master Switch
AT-x950-28XSQ Switch and VCStack Installation Guide Configuring the Master Switch This section contains the following procedures for configuring the master switch of the stack:  “General Steps for the Master Switch,” next  “Configuring the Master Switch,” next  “Verifying the Master Switch” on page 133 ...
Page 130: Configuring The Master Switch
6. Designate the types of transceivers to be used in ports 25 to 37 with the PLATFORM PORTMODE INTERFACE command, on both the master switch and provisioned member switch. Allied Telesis recommends performing this task at this time even if you are not using these ports as the stack trunk.
Page 131 AT-x950-28XSQ Switch and VCStack Installation Guide Table 16. Configuring the Master Switch (Continued) Step Description and Command Move to the Global Configuration mode with the CONFIGURE TERMINAL command. awplus# configure terminal Enter configuration commands, one per line. End with CNTL/Z.
Page 132 Chapter 8: Configuring Switches for Stacking Table 16. Configuring the Master Switch (Continued) Step Description and Command Designate the ports as stacking ports with the STACKPORT command. awplus(config-if)# stackport % Save the config and restart the system for this change to take effect.
Page 133: Verifying The Master Switch
AT-x950-28XSQ Switch and VCStack Installation Guide Verifying the Perform the steps in Table 17 on page 133 to confirm the configuration of the master switch. Master Switch Table 17. Verifying the Master Switch Step Description and Command Start a new local management session on the master switch.
Page 134: What To Do Next
Chapter 8: Configuring Switches for Stacking Table 17. Verifying the Master Switch (Continued) Step Description and Command Check the running configuration of the master switch with the SHOW RUNNING- CONFIG command for the following commands: - Four STACK commands. - Two SWITCH PROVISION commands, with the IDs 1 and 2. - INTERFACE and STACKPORT commands designating the ports of the stack trunk for both the provisioned master switch (port1) and the member switch (port2).
Page 135 AT-x950-28XSQ Switch and VCStack Installation Guide 2. Configure the member switch. Refer to “Configuring the Member Switch” on page 136. 3. After configuring both master and member switches, cable the ports of the stack trunk. Refer to Chapter 9, “Cabling the Networking Ports” on page 147.
Page 136: Configuring The Member Switch
Chapter 8: Configuring Switches for Stacking Configuring the Member Switch Here are the procedures for configuring the member switch of the stack.  “General Steps for the Member Switch” on page 136  “Configuring the Member Switch - Part I” on page 137 ...
Page 137: Configuring The Member Switch - Part I
AT-x950-28XSQ Switch and VCStack Installation Guide 9. Specify the types of transceivers to be used in slots 25, 29, 33, and 37 for both the provisioned master switch and member switch with the PLATFORM PORTMODE INTERFACE command. 10. Designate the ports of the stack trunk on both the provisioned master switch and member switch, with the STACKPORT command in the port Interface mode.
Page 138 Chapter 8: Configuring Switches for Stacking Table 18. Configuring the Member Switch - Part I (Continued) Step Description and Command Verify that the switch hardware is operating correctly, with the SHOW SYSTEM ENVIRONMENT command. All components should have a status of Ok. awplus# show system environment Environment Monitoring Status Overall Status: Normal...
Page 139: Configuring The Member Switch - Part Ii
AT-x950-28XSQ Switch and VCStack Installation Guide Table 18. Configuring the Member Switch - Part I (Continued) Step Description and Command Restart the switch with the REBOOT command. awplus# reboot reboot system? (y/n): awplus# Type “Y” for yes. Wait two minutes for the switch to initialize its management software.
Page 140: Table 19: Configuring The Member Switch - Part Ii
Chapter 8: Configuring Switches for Stacking Table 19. Configuring the Member Switch - Part II (Continued) Step Description and Command Assign priority 2 to the member switch with the STACK PRIORITY command. awplus(config)# stack 2 priority 2 Specify the types of transceivers to be used in slots 25, 29, 33, and 37 on both the provisioned master switch (port1) and the member switch (port2) with the PLATFORM PORTMODE INTERFACE command.
Page 141: Verifying The Member Switch
AT-x950-28XSQ Switch and VCStack Installation Guide Table 19. Configuring the Member Switch - Part II (Continued) Step Description and Command Wait two minutes for the switch to initialize its management software. Go to “Verifying the Member Switch,” next. Verifying the Perform the steps in Table 20 to confirm the configuration of the member switch.
Page 142: What To Do Next
Chapter 8: Configuring Switches for Stacking Table 20. Verifying the Configuration of the Member Switch (Continued) Step Description and Command Enter the SHOW RUNNING-CONFIG command to check the running configuration for the following commands: - Four STACK commands. - Two SWITCH PROVISION commands, with IDs 1 and 2. - INTERFACE and STACKPORT commands designating the ports for the stack trunk for both the provisioned master switch (port1) and the member switch (port2).
Page 143 AT-x950-28XSQ Switch and VCStack Installation Guide 6. Cable the networking ports, as explained in Chapter 9, “Cabling the Networking Ports” on page 147.
Page 144: Powering On The Stack
Chapter 8: Configuring Switches for Stacking Powering on the Stack After enabling the VCStack feature on both switches and configuring them for stacking, you are ready to cable the ports of the stack trunk and power on the stack for the first time. (If you want to monitor the power-on sequence, connect a terminal or PC with a terminal emulator program to the Console port on either switch).
Page 145: Verifying The Stack
AT-x950-28XSQ Switch and VCStack Installation Guide Verifying the Stack To verify the stack, perform the following procedure: 1. Start a local management session on either the master or member switch. Refer to “Starting a Local Management Session” on page 127.
Page 146 Chapter 8: Configuring Switches for Stacking...
Page 147: Chapter 9: Cabling The Networking Ports
Chapter 9 Cabling the Networking Ports This chapter contains the following procedures:  “Cabling 1Gbps and 10Gbps Twister Pair Ports” on page 148  “Guidelines to Handling Twisted Pair or Fiber Optic Transceivers” on page 149  “Installing Transceivers” on page 150 ...
Page 148: Cabling 1Gbps And 10Gbps Twister Pair Ports
Chapter 9: Cabling the Networking Ports Cabling 1Gbps and 10Gbps Twister Pair Ports This section applies to the 1Gbps/10Gbps twisted pair ports on the XEM2- 12XT Line Card. Here are the cabling guidelines:  The cable specifications are listed in Table 5 on page 28. ...
Page 149: Guidelines To Handling Twisted Pair Or Fiber Optic Transceivers
AT-x950-28XSQ Switch and VCStack Installation Guide Guidelines to Handling Twisted Pair or Fiber Optic Transceivers Please review the following guidelines before installing twisted pair or fiber optic transceivers:  Transceivers are hot-swappable. You can install them while the chassis is powered on.
Page 150: Installing Transceivers
Chapter 9: Cabling the Networking Ports Installing Transceivers Table 21 lists the types of transceivers supported by the base transceiver slots. Refer to the product data sheet for a list of approved transceivers. Table 21. Transceivers for the Base Transceiver Slots Base Ports Fiber Optic Transceiver - 1Gbps SX/LX SFP transceivers...
Page 151: Figure 82: Sp10T Transceivers
AT-x950-28XSQ Switch and VCStack Installation Guide Table 21. Transceivers for the Base Transceiver Slots (Continued) Base Ports Fiber Optic Transceiver - AT-QSFP1CU and AT-QSFP3CU direct Base ports 25, 29, 33, and attach cables in lengths of 1 and 3 37 (Continued) meters, respectively.
Page 152 Chapter 9: Cabling the Networking Ports Table 22. Transceivers for the Optional XEM2 Ethernet Line Cards Ethernet Line Card Transceiver XEM2-4QS 40Gbps QSFP+ transceivers: - QSFPSR4 fiber optic transceiver - Maximum operating distance of 150 meters (492 feet) with 12-strand OM4 fiber optic cable.
Page 153: Figure 83: Installing An Sfp Or Sfp+ Transceiver
AT-x950-28XSQ Switch and VCStack Installation Guide To install a fiber optic transceiver, perform the following procedure: 1. Select a port for the transceiver. 2. If the selected port has a dust cover, remove it. 3. Remove the transceiver from its shipping container and store the packaging material in a safe location.
Page 154: Figure 84: Installing 40Gbps Fiber Optic Transceivers In Xem2-4Qs Line Cards
Chapter 9: Cabling the Networking Ports Figure 84. Installing 40Gbps Fiber Optic Transceivers in XEM2-4QS Line Cards  100Gbps QSFP28 transceivers for base ports 25 to 37: refer to Figure 85. Figure 85. Installing 100Gbps QSFP28 Transceivers in Base Ports 25, 29, 33, 37 ...
Page 155: Figure 86: Installing 100Gbps Qsfp28 Transceivers In Xem2-1Cq Line Cards
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 86. Installing 100Gbps QSFP28 Transceivers in XEM2-1CQ Line Cards Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step. Otherwise, repeat steps 1 to 4 to install additional transceivers.
Page 156: Installing Direct Attach Cables
Chapter 9: Cabling the Networking Ports Installing Direct Attach Cables Table 12 on page 41 lists the direct attach cables for the base ports and XEM2 Line Cards. They offer an economical way to add 10Gbps, 40Gbps, or 100Gbps connections over short distances. To install direct attach cables, perform the following procedure: 1.
Page 157: Figure 88: Attaching Qsfpcu Cables
AT-x950-28XSQ Switch and VCStack Installation Guide Release Tab Figure 88. Attaching QSFPCU Cables 5. Connect the other end of the cable into a compatible port on another network device. 6. Repeat this procedure to install additional direct attach cables. Note To remove a cable from the port, gently push on the connector, pull on the release tab, and slide the connector from the port.
Page 158 Chapter 9: Cabling the Networking Ports...
Page 159: Chapter 10: Replacing Modules
Chapter 10 Replacing Modules This chapter contains the following procedures:  “Replacing XEM2 Ethernet Line Cards” on page 160  “Replacing PWR600 AC Power Supplies” on page 165  “Replacing FAN05 Modules” on page 170...
Page 160: Replacing Xem2 Ethernet Line Cards
Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing line cards. For instructions, refer to the Software Reference for AT-x950 Switches.
Page 161: Figure 89: Loosening The Screws On The Ethernet Line Card
AT-x950-28XSQ Switch and VCStack Installation Guide Note 100Gbps transceivers for the AT-XEM2-1CQ Line Card have handles. Always use the handles when installing or removing transceivers. 4. Use a #2 Phillips-head screwdriver to loosen the two screws on the faceplate of the card. Refer to Figure 89.
Page 162: Figure 90: Disconnecting An Ethernet Line Card From The Switch
Chapter 10: Replacing Modules Figure 90. Disconnecting an Ethernet Line Card from the Switch 6. Carefully slide the card from the switch. Refer to Figure 91. Figure 91. Sliding an Ethernet Line Card from the Switch 7. If you are not installing the line card in another switch, store it in its anti-static bag and shipping container.
Page 163: Figure 92: Placing The Ethernet Line Card In Its Anti-Static Bag
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 92. Placing the Ethernet Line Card in its Anti-static Bag 8. Do one of the following:  For instructions on how to install another card in the slot, start with step 2 in “Installing an Optional XEM2 Ethernet Line Card” on page 86.
Page 164: Figure 94: Tightening The Two Screws On The Line Card Blank Panel
Chapter 10: Replacing Modules Figure 94. Tightening the Two Screws on the Line Card Blank Panel...
Page 165: Replacing Pwr600 Ac Power Supplies
PSU A. The procedure is the same for slot PSU B. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing power supplies. For instructions, refer to the Software Reference for AT- x950 Switches.
Page 166: Figure 96: Opening The Restraining Strap On The Power Supply
Chapter 10: Replacing Modules Release Tab Figure 96. Opening the Restraining Strap on the Power Supply 3. Disconnect the power cord from the power supply. Refer to Figure 97. Figure 97. Disconnecting the Power Cord from the Power Supply...
Page 167: Figure 98: Removing The Power Supply
AT-x950-28XSQ Switch and VCStack Installation Guide 4. Press the release lever to the right and pull on the handle to release the power supply from the internal connector in the switch. Refer to Figure 98. Release Lever Figure 98. Removing the Power Supply 5.
Page 168: Figure 99: Removing A Power Supply
Chapter 10: Replacing Modules Figure 99. Removing a Power Supply 6. Do one of the following:  To install a new power supply, refer to “Installing PWR600 AC Power Supplies” on page 82 for instructions.  If you are not installing a new power supply, continue with the next step to install the blank panel 7.
Page 169: Figure 100: Installing The Blank Power Supply Cover
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 100. Installing the Blank Power Supply Cover...
Page 170: Replacing Fan05 Modules
For background information, refer to “AT-FAN05 Cooling Fan” on page 44. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before replacing a fan module. For instructions, refer to the Software Reference for AT-x950 Switches.
Page 171: Figure 102: Disconnecting The Fan05 Module From The Switch
AT-x950-28XSQ Switch and VCStack Installation Guide 2. Carefully pull on the handle to disconnect the line card from the internal connector in the switch. Refer to Figure 102. Figure 102. Disconnecting the FAN05 Module from the Switch 3. Slide the fan module out of the switch. Refer to Figure 103.
Page 172: Installing Fan Modules
Chapter 10: Replacing Modules Installing Fan This procedure requires the following tool: Modules  #2 Phillips-head screwdriver (not provided) The illustrations show the installation of a fan module in FAN B slot on the back panel. The procedure is the same for installing a module in FAN A slot.
Page 173: Figure 105: Aligning The Fan05 Module In The Switch Slot
AT-x950-28XSQ Switch and VCStack Installation Guide Figure 105. Aligning the FAN05 Module in the Switch Slot 3. When you feel the module make contact with the internal connector, gently press on both sides to seat the module on the connector. Refer to Figure 106.
Page 174: Figure 107: Tightening The Two Captive Screws On The Fan05 Module
Chapter 10: Replacing Modules Figure 107. Tightening the Two Captive Screws on the FAN05 Module 5. To confirm the operations of the new fan module, start a local or remote management session and enter the SHOW SYSTEM ENVIRONMENT command in the User Exec or Privileged Exec mode.
Page 175: Chapter 11: Troubleshooting
This chapter contains suggestions on how to troubleshoot problems with the switch. Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support. Problem 1: The unit is not receiving power. All the port LEDs and Switch ID LED are off, and the fans are not operating.
Page 176 Chapter 11: Troubleshooting Solutions: Try the following:  Check that the transceiver is fully inserted in the port.  Verify that the fiber optic cable is securely connected to the port on the transceiver and the remote network device.  Verify that the remote network device is operating properly.
Page 177 AT-x950-28XSQ Switch and VCStack Installation Guide with the FEC command. Refer to the Software Reference for x950 Switch, AlliedWare Plus Operating System. Problem 5: A 4x10Gbps breakout cable in port 25, 29, 33, or 37 cannot establish links with network devices.
Page 178 If the trunk is using fiber optic transceivers, verify that they are fully inserted into the ports.  Verify that the transceivers are from Allied Telesis.  Verify that the fiber optic cables are securely connected to the ports on the transceivers.
Page 179 Solutions: One of the following problems has occurred:  A cooling fan has failed.  The internal temperature of the switch is outside the normal operating range and the unit might shut down. Contact your Allied Telesis sales representative for assistance.
Page 180 Chapter 11: Troubleshooting...
Page 181: Appendix A: Technical Specifications
Appendix A Technical Specifications This appendix contains the following sections:  ”Physical Specifications” on page 182  ”Environmental Specifications” on page 184  ”Power Specifications” on page 185  ”Certifications” on page 187  ”RJ-45 Twisted Pair Port Pinouts on the AT-XEM2-12XT Card” on page ...
Page 182: Physical Specifications
Dimensions (H x W x D) Table 23 lists the dimensions of the switches and power supplies. Table 23. Product Dimensions AT-x950-28XSQ 4.4 cm x 44.0 cm x 44.5 cm (1.7 in. x 17.3 in. x 17.5 in.) AT-XEM2-12XT Line Card 109.52 x 39.12 x 155.45 cm...
Page 183: Table 25: Ventilation Requirements
AT-x950-28XSQ Switch and VCStack Installation Guide Ventilation Table 25 lists the ventilation requirements. Table 25. Ventilation Requirements Recommended Minimum 10 cm (4.0 in) Ventilation on All Sides...
Page 184: Environmental Specifications
Appendix A: Technical Specifications Environmental Specifications Table 26 lists the environmental specifications of the switches. Table 26. Environmental Specifications Operating Temperature 0° C to 45° C (32° F to 113° F) (with QSFP28 transceivers) Operating Temperature 0° C to 50° C (32° F to 122° F) (without QSFP28 transceivers) Storage Temperature -25°...
Page 185: Power Specifications
AT-x950-28XSQ Switch and VCStack Installation Guide Power Specifications This section contains the maximum power consumption values and input voltages. Maximum Power Consumptions Table 27 list the maximum power consumptions. Table 27. Maximum Power Consumptions (Watts) AT-x950-28XSQ Switch with one 206.1 W...
Page 186: Table 30: Maximum Power Supply Efficiency (Based On 100V Input Voltage)
AT-PWR600 AC Power Supply Up to 85% Heat Dissipations Table 31 lists the heat dissipations. Table 31. Heat Dissipations (British Thermal Units/Hour) AT-x950-28XSQ Switch with one 703.24 BTU/hr AT-PWR600 Power Supply (no line card) AT-x950-28XSQ Switch with two 789.03 BTU/hr...
Page 187: Certifications
AT-x950-28XSQ Switch and VCStack Installation Guide Certifications Table 32 lists the product certificates. Table 32. Product Certifications EMI (Emissions) FCC Class A CISPR 22 Class A EN55032 Class A VCCI Class A ICES-003 Class A EMC (Immunity) EN55024 EN61000-3-2 EN61000-3-3...
Page 188: Rj-45 Twisted Pair Port Pinouts On The At-Xem2-12Xt Card
Appendix A: Technical Specifications RJ-45 Twisted Pair Port Pinouts on the AT-XEM2-12XT Card Figure 108 illustrates the pin layout of the RJ-45 connectors of the 1Gbps or 10Gbps ports on the AT-XEM2-12XT Line Card. Figure 108. Pin Layout (Front View) of the 1Gbps or 10Gbps Ports on the AT-XEM2-12XT Line Card Table 33 lists the pin signals when a port operating at 1GBase or 10GBase.
Page 189: Style Serial Console Port Pinouts
AT-x950-28XSQ Switch and VCStack Installation Guide RJ-45 Style Serial Console Port Pinouts Table 34 lists the pin signals of the RJ-45 style serial Console port. Table 34. RJ-45 Style Serial Console Port Pin Signals Signal Looped to pin 8. Looped to pin 7.
Page 190 Appendix A: Technical Specifications...

Allied Telesis AT-x950-28XSQ Installation Manual

Preface

Chapter 1: Overview

Chapter 2: Virtual Chassis Stacking

Chapter 3: Beginning the Installation

Chapter 4: Installing Power Supplies and Optional XEM2 Line Card

Chapter 5: Installing the Switch on a Table

Chapter 6: Installing the Switch in an Equipment Rack

Chapter 7: Installing the Switch on a Wall

Chapter 8: Configuring Switches for Stacking

Chapter 9: Cabling the Networking Ports

Chapter 10: Replacing Modules

Chapter 11: Troubleshooting

Appendix A: Technical Specifications

Quick Links

Related Manuals for Allied Telesis AT-x950-28XSQ

Summary of Contents for Allied Telesis AT-x950-28XSQ
