Door Alarm Wire Recommendation
(from Multiplexer to Door Switch)
PTI Part #
wwir2450 *
wwir2450pl
wwir2450db
* Denotes standard recommended wire.
• Never use wire smaller than 24 AWG for installing door switches.
• Never use stranded wire for installing door switches.
• Applications that require shielded trunk line, use direct burial cable.
Intercom Wire Recommendation
(from LEF or NEM Base Station to intercoms)
PTI Part #
wwir1810s *
wwir1804s *
wwir1802s
wwir2210s
* Denotes standard recommended wire.
• Never use wire smaller than 22 AWG for installing LEF or NEM intercoms. We recommend
that 18 AWG be used in most installations for best results. Do not exceed 1600 feet in
linear distance when using 18 AWG or 600 feet in linear distance using 22 AWG.
114A3866.D Revised 7-2017
Belden
Wire Code
9585 24 AWG, 50-conductor solid copper wire (PVC Insulation)
N/A 24 AWG, 50-conductor solid copper wire (Plenum Insulation)
165185110 24 AWG, 50-conductor solid copper wire (Direct Burial)
Belden
Wire Code
18 AWG, 10-conductor stranded copper wire with overall
5345FE
shield and common ground (PVC Insulation)
18 AWG, 4-conductor stranded copper wire with overall
9418
shield and common ground (PVC Insulation)
18 AWG, 2-conductor stranded copper wire with overall
8760
shield and common ground (PVC Insulation)
22 AWG, 10-conductor stranded copper wire with overall
9946
shield and common ground (PVC Insulation)
Description
Description
