Advanced OSD

If you need detailed information about the controls, please use the advanced menu.
There are 2 ways to access the advanced menu.
Method 1:
<To access the advanced menu>
• Press the MENU button to access the OSD menu. Use the LEFT/RIGHT and UP/DOWN buttons to navigate to the
ADVANCED SETTING in the Color Control Systems. Press the INPUT button to open the Advanced OSD menu.
<To exit the advanced menu>
• Press the EXIT button.
Method 2:
<To access the advanced menu>
• Turn off the monitor.
• Turn on the monitor by pushing the "POWER" and "INPUT" buttons simultaneously for at least one second. Then press the
"MENU" button.
• The Advanced OSD menu opens.
This menu is larger than the normal OSD.
<To exit the advanced menu>
• Turn the monitor power off then on again.
Press the "LEFT" or "RIGHT" button to navigate to the tag with the settings you want to adjust and then press the
"SELECT" button.
To move to another tag, press "EXIT", then press "LEFT" or "RIGHT" to highlight another tag.
Tag1 PICTURE MODE
PRESET
BRIGHTNESS*
WHITE
* 1 This item does not reset by FACTORY PRESET (Tag7), when the AUTO BRIGHTNESS is set to "ON".
Selects PICTURE MODE, from 1 to 5.
Sets the PICTURE MODE PRESET from the type of PRESET (see page 17).
Adjusts the overall image and screen background brightness.
1
Press "LEFT" or "RIGHT" to adjust.
Adjusts the white color by temperature or x, y setting. A lower color temperature will make
the screen reddish and a higher color temperature will make the screen bluish. A stronger
x makes the screen reddish, a stronger y makes it greenish and weak x, y makes it a
bluish white.
English-18
