Tilt
Place your hands on the top and bottom sides of the monitor screen and adjust the tilt as desired (Figure TS.1).
CAUTION: Handle with care when tilting the monitor screen.
Swivel
Place your hands on both sides of the monitor screen and adjust the swivel as desired (Figure TS.2).
Flexible Arm Installation
This LCD monitor is designed for use with a flexible arm. Contact NEC for more information.
To prepare the monitor for alternate mounting purposes:
• Follow the instructions provided by the manufacturer of the display mount.
CAUTION: To meet the safety requirements, the monitor must be mounted to an arm that supports the weight of the
monitor. See page 26 for details. Remove the monitor stand before mounting.
Remove the Monitor Stand for Mounting
To prepare the monitor for alternate mounting purposes:
1. Disconnect all cables.
2. Place your hands on each side of the monitor screen and lift up to the
highest position.
3. Place the monitor face down on a non-abrasive surface (Figure S.1).
4. Place one hand around the base and one hand on the
Quick ReleaseLever.
Push and hold the Quick Release Lever in the direction indicated
by the arrow (Figure S.1).
5. Lift up the stand to unhook it from the monitor (Figure S.1).
The monitor can now be mounted using an alternate method.
Reverse the process to reattach the stand.
NOTE: Handle with care when removing the monitor stand.
Figure TS.1
Figure TS.2
English-9
Figure S.1
