SETTING OSD LANGUAGE
1. Press the MENU button to open the OSD menu.
2. Press the LEFT/RIGHT button to navigate to the MENU TOOLS.
3. Press the UP/DOWN button to navigate to LANGUAGE, and then press the LEFT/RIGHT button to select the desired OSD
language.
4. Press the MENU/EXIT button to close the OSD menu.
NOTE:
Setting the OSD language is only necessary upon initial setup. The OSD language will stay the same until changed
by the user.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
NOTE: For low brightness settings, the display will automatically compensate by adjusting the screen contrast.
This will result in a reduced contrast ratio.
For high brightness settings, the display will automatically compensate by lowering UNIFORMITY
compensation. This may result in decreased uniformity.
If digital compensation occurs, the brightness value on the OSD will change to magenta.
NOTE: The optimal display brightness is within a range where the OSD menu appears black. When the display
cannot achieve the desired brightness, the numerical brightness value on the OSD will blink.
NOTE: There is a brightness value limitation when you enable ECO MODE or AUTO BRIGHTNESS.
ECO MODE
Decreases the amount of power consumed by reducing the brightness level.
OFF: Does not function.
ON: Reduces the maximum possible brightness to about 100 cd/m
BLACK
Adjusts the black luminance.
When low settings are selected that cannot be displayed, the indicator on the OSD will turn magenta.
CONTRAST (Analog input only)
Adjusts the overall image and background screen brightness by input signal level.
NOTE: It is recommended to use BRIGHTNESS to adjust screen brightness for lower power consumption and
improved image quality.
AUTO CONTRAST (Analog input only)
Adjusts the image for Analog input.
Image Controls
LEFT / RIGHT
Controls horizontal image position within the display area of the LCD.
DOWN / UP
Controls vertical image position within the display area of the LCD.
H.SIZE (V.SIZE) (Analog input only)
Adjusts the horizontal size by increasing or decreasing this setting.
If the "AUTO ADJUST" function does not give you a satisfactory picture setting, additional tuning can be performed by
using the "H.SIZE (or V.SIZE)" function (dot clock). A Moiré test pattern can be used for this. This function may alter the
width of the picture. Use LEFT/RIGHT Menu to center the image on the screen. If the H.SIZE (or V.SIZE) is incorrectly
calibrated, the result would look like the left drawing. The image should be homogeneous.
When H.SIZE value is
When H.SIZE value is
wrong.
.
2
When H.SIZE value is
improved.
English-12
correct.
