Mount the Flexible Arm
This LCD monitor is designed for use with a flexible arm.
1. Follow the instructions on how to Remove the Monitor Stand for Mounting to remove the stand.
2. Use the attached 4 screws to fasten the arm to the monitor (Figure F.1).
CAUTION: • Only use the screws (4 pcs) that are included or M4 sized screws
(Length: thickness of bracket and washer + 10-12 mm) when mounting to
avoid damage to the monitor and stand.
• To meet the safety requirements, the monitor must be mounted to an arm
which guaranties the necessary stability under consideration for the weight
of the monitor. The LCD monitor should only be used with an approved
arm (e.g. TUEV GS mark).
• Tighten all screws (recommended Fasten Force: 98 - 137N•cm).
A loose screw may cause the monitor to fall off the arm.
• Attaching the flexible arm should be done by two or more people if the monitor cannot be placed face down
on a flat surface for installation.
100 mm
100 mm
Figure F.1
English-10
Unit
Mounting
Bracket
Washer
Screw
10-12 mm
Thickness
of bracket
and washer
