eXact Micro 7+ Instruction Manual page 8

For Pool and Spa Salt Systems
Salt/Chloride (as NaCl) Test Procedure
TR7
TURN METER ON
1
Press the ZERO/ON button to power the meter on; the display will show all annunciators,
then the current MENU selection, followed by the last reading.
SELECT TEST: TR7
2
Press and re-press the MENU button until the display shows the parameter TR7.
ADD THE SAMPLE
3
A 1 to 40 dilution of the pool water is required to perform this test. Follow the directions in the Mini
Dilution Kit (Part No. 487201, included) to perform the dilution. Rinse the CELL 3 times with the
diluted sample, and then fill the CELL to capacity (4ml) with the diluted sample.
ZERO METER
4
Press the ZERO/ON button. The cursor will move across the display, followed by 100 %T.
Meter is ready for testing.
DIP STRIP
5
Dip the eXact
immediately press READ. This starts the 20 SECOND countdown timer. During this time
move the strip in a gentle back and forth motion. Remove and discard the strip when the
time displays 1. The cursor will move across the display, informing you that it is about to
measure the sample. Record result displayed (this result is automatically stored in TR7).
USE TABLE
6
Find the "TR7" result in the table below to determine the Sodium Chloride concentration in ppm
(parts per million). (Example: a "TR7" result of 65.3 (use only the 65 for the chart) equals a Sodium
Chloride value of 2760 ppm). Record result. After testing is completed, rinse cell immediately.
Sodium Chloride results require the table below. Follow eXact
Procedure (above) using eXact
Chloride (Cl ), multiply the value from the chart below by 0.6. (Example: 4600ppm NaCl = 2760ppm Cl
–
eXact
%T
9
90 <1020 <1020
80 <1020 <1020
70 1740 1800
60 2520 2580
50 3180 3240
40 3780 3840
4320 4380
30
4920 4980
20
5520 5640
10
6840 >6840
0
Strip Micro CHLORIDE (as NaCl), Part No. 481657 into the CELL and
®
Chloride
Strip Micro CHLORIDE, Part No. 481657. NOTE: To convert the NaCl value to
®
Strip Micro CHLORIDE, Part No. 481657 - for 4mL Samples
®
8 7 6
<1020 <1020
1020 1080
1860 1980
2640 2700
3300 3360
3900 3960
4440 4500
5040 5100
5700 5760
>6840 >6840
Table
(as NaCl)
Micro 7+ Chloride (as NaCl) Test
®
5 4
<1020 <1020 <1020
1200 1260 1380
2200
2040 2100
2760 2820 2880
3420 3480 3540
4020 4020 4080
4560 4620 4680
5160 5220 5280
5820 5880 6000
>6840 >6840 >6840
8
3 2 1
<1020 <1020
1440 1560
2280 2340
3000 3060
3600 3660
4140 4200
4740 4800
5340 5400
6120 6300
>6840 >6840
Rev. 070710 NaCl-hr
CHLORIDE
)
–
0
<1020
1620
2400
3120
3720
4260
4860
5460
6540
>6840
