The following are some common messages that may be displayed, including error messages. If an
error message other than those listed below is displayed, please contact technical support in the USA
at (803) 329-0162 (ext. 0).
LCD Message Description
HI In READ mode: test sample concentration is above
the measurement range (test specific).
LO In READ mode: test sample concentration is below
the measurement range (test specific).
LO In ZERO mode: sample absorbance (due to a
cloudy or colored sample or a dirty cell) is too high
to zero, the meter will read "LO".
ER Excessive stray light detected. Normally this
does not occur, even when testing in sunlight.
Low battery indication.
The built-in CELL is transparent plastic and, when filled to the top, contains 4ml. The sturdy CELL design
will last for over 20,000 readings. Scratches on the CELL will not interfere or compromise the accuracy of
the readings because of its fixed position. For best accuracy, rinse cell with clean water immediately after
a test is completed. Do not use solvents, such as acetone, to clean the cell. When the CELL becomes
stained or cloudy from repeated testing, or when the meter does not blank when you press the ZERO/ON
button, the cell needs to be cleaned. Clean as follows: Fill cell with clean water and move the Cell
cleaning brush up-and-down and back-and-forth along the walls of the cell. Afterwards, rinse the cell and
the meter is ready for use again. Cleaning the cell regularly is especially recommended after you run a
test that is using turbidity or precipitation chemistry for analysis (Calcium Hardness and Cyanuric Acid).
To Install/Replace "AAA" Batteries:
1. Unscrew the O-ring sealed battery cover counter-clockwise. Use proper sized pliers if necessary.
Do not disturb the sealing O-ring. Batteries are not included.
2. Remove the used batteries and install 4 new AAA batteries following the diagram for
correct polarity (see diagram). We recommend high quality AAA alkaline batteries be used.
4. Replace the battery cover. Be sure to tighten the cover securely. This is necessary for meter to
be waterproof.
5. Dispose of the used batteries in accordance with your
local regulations.
6. Press ZERO/ON button to confirm the meter turns on.
The meter is now ready for operation.
7. Meter will not work if battery orientation is incorrect.
eXact
®
Registration of your eXact
activate the warranty. The eXact
workmanship for a period of five (5) years from the date of purchase by the customer. ITS will repair or
replace any part of the product which is deemed to be faulty or otherwise defective. The non-transferable
warranty does not cover product damage caused by abuse (such as crushing a tablet in the cell) or
improper use. If the meter is faulty or otherwise defective contact ITS by phone (+1-803-329-9712 Ext. 0)
or email (its@sensafe.com) to describe the problem and obtain a return authorization form before
returning the photometer to ITS. Damage caused by improper packing of the photometer for return
shipment to ITS will not be covered by the warranty. Customer is responsible for shipping charges to
ITS. ITS pays postage when photometer is returned to customer. A maximum processing fee of $75 will
be charged for repair or replacement of non-registered photometers and damages not covered by this
warranty. Registration is available over the phone (+1-803-329-9712 Ext. 0) or online at
http://www.sensafe.com/micro/warranty/ (Personal data is kept confidential)
Micro 7+ Meter Messages
®
About The Built-In Cell
Photometer 5-Year Limited Warranty
photometer must be received within 30 days from date of purchase to
®
photometer is warranted to be free from defects in materials and
®
Corrective Action
Dilute and retest. Dilution Kit available
(Part Number 487200).
Sample value is below measurement
range.
Dilute sample, filter sample, or clean cell. One of
these options should remedy the problem.
Place the LIGHT BLOCKING CAP over the CELL
for zeroing and for reading result. Moving
to a shaded area can also fix this problem.
Replace the batteries.

TOP VIEW
