Filtering - Barracuda Networks NG Network Access Client SP4 Administrator's Manual

Summary of the client's health status or more details of a failed connection. Values could be
"Client is healthy". If the client is unhealthy, the column "Information" contains details about
the failed health checks. "No rule matched", another possible information, means that
identity matching failed.
•
Last health state, which could be one of the four "Healthy", "Unhealthy", "Probation", or
"Untrusted".
•
Possible values are Access", "Not Restricted", or "Probation".
•
Result of the last authentication, which could be either "OK" or "Not OK".
•
Name of the matching policy rule.
•
Originating box where the Access Control Service runs on (only relevant in CC Barracuda
NG Network Access Client GUI context).
•
Displays the type "Health Evaluator", "Authenticator" or "Remediation", depending on the
Access Control Service module which created the entry.
•
Client's MAC address as reported by the NG client.
•
Client's local machine Secure Identifier (SID) as reported by the NG client.
4.1.2

Filtering

All available tabs provide filtering options at the top of the Barracuda NG Access Monitor GUI.
To activate a filter and refresh the Status list it is necessary to press the button "Update List".
Filters are case sensitive. Some of the filters provide a list of available entries, other filter criteria can be entered man-
ually. For manual input there are wildcards ('*', '?') available. For example, Filter 10.0.8.1? filters for IP addresses
10.0.8.10 to 10.0.8.19, the filter 10.0.8.1* also matches 10.0.8.100 to 10.0.8.199.
The filter categories are split into Basic Filters and Advanced Filters. Depending on the currently
selected tab some filters are not available or set as preselection.
The Basic Filter provides the following filter criteria:
•
Restrict the time period for which entries should be listed.
•
This filter provides the different health states "Healthy", "Unhealthy", "Probation", and
"Untrusted" to display only the selected entries
63 Barracuda NG Network Access Client - Administrator's Guide
Healthstate
IsolationState
Auth. (PHIBS)
Rule
Boxname
Type
MAC Address
SID
From date/dime
Health State
