Barracuda Networks NG Network Access Client SP4 Administrator's Manual page 103

9.6.8 Listing and Context Menu
The listing is divided into the following columns:
Table 9–4
Live Activity window details
Column Description
Direction
Flags the connection direction (
Load
Displays the current connection load ( to
Date/Time Date and time of traffic initiation.
Application Application name and its PID (Process ID).
Protocol Protocol assigned to the application.
Source Source IP of the connection.
Destination Destination IP of the connection.
Port Connection port.
User Name of the user who has initiated the connection attempt.
Traffic Policy Name of the effective firewall rule.
bps Connection load in bits per second.
Idle Idle time of the connection.
Total Total amount of data transfer, that is sum of incoming (column In) and outgoing (column Out) traffic.
Start Expired time span since connection initiation.
Service Affected service object or UUID (Universal Unique IDentifier).
ID Internal slot ID.
Session Effective connection state or current session timeout value.
Timeout
Select and right-click a list entry to display the following context menu:
Table 9–5
Live Activity window - Context menu
Item
Show Details
Disconnect
Resolve Source/Destination IP
101 Barracuda NG Network Access Client - Administrator's Guide
outgoing connections;
).
Description
Select Show Details or double-click a list entry to view a summary of connection details.
Terminates the selected connection.
Tries to resolve the source/destination IP and summarizes the results (port, IP address, hostname and
description) in a separate window.
Note:
Entries displayed in italic indicate closed connections waiting for RST-ACK (reset acknowledgement). The
RST-ACK must be awaited in order to avoid its blocking by the firewall.
incoming connections).
