Simple Logger

Features

1

Indicators and Buttons

®
The AmpFlex
located on the front panel.
The button is used to start and stop recordings and to turn the logger on
and off. The red LED indicates the status of the logger; OFF, STANDBY
or RECORDING. When the LED is lit continuously, it indicates an
overload condition.

Inputs and Outputs

The top of the logger incorporates a
permanent flexible sensor attached
by a 5 ft lead.
The bottom has a 5-pin circular
connector used
transmission from the logger to your
computer.

Range Selection

Before operating, determine the
maximum current to be logged.
Remove the back cover and select
the appropriate range as shown.
®
®
AmpFlex Current Probes
!
00 V CAT III
RANGE:
MODEL:
PRESS
!
Continuous LED Indicates Overload
OGGER OPERATION:
. Press to Start Logging
(Logging = Two Blinks)
2. Press to Stop Logging
(Stand-By = One Blink)
3. Press & Hold 5 sec. to Shut Off
(Off = No Blinks)
Warning: All Data will be Deleted!
AmpFlex Logger
®
I N S T R U M E N T S
99 CHAUNCY STREET • BOSTON MA 02111, USA
( 17) 451-0227 • Fax ( 17) 423-2952 • www.aemc.com
MADE IN USA
BATTERY: 9 V, NEDA 1 04, LF22, LR 1
! RS-232
Logger has only one button and one indicator. Both are
for serial
3
(1) Start/Stop Button
(2) Flexible Sensor Input
(3) Operation Mode Indicator
(4) RS-232 Interface
4
data
6
HI
LO
HI
LO
