- Page 1 Simple Logger ® AmpFlex ® Current Probes AL24-2500 / AL36-2500 AL24-5000 / AL36-5000 USER MANUAL...
- Page 2 Statement of Compliance ® ® Chauvin Arnoux , Inc. d.b.a. AEMC Instruments certifies that this instrument has been calibrated using standards and instruments traceable to international standards. We guarantee that at the time of shipping your instrument has met its published specifications.
-
Page 3: Table Of Contents
Table of Contents Warning ....................3 International Electrical Symbols .............. 3 Receiving Your Shipment................ 4 Packaging....................4 Specifications ..................4 Features ....................6 Indicators and Buttons ..............6 Inputs and Outputs ................6 Range Selection ................6 Battery Installation ................7 Operation.................... -
Page 4: Warning
® ® Simple Logger AmpFlex Current Probes Warning These safety warnings are provided to ensure the safety of personnel and proper operation of the instrument. • Read the instruction manual completely and follow all the safety information before attempting to use or service this instrument. •... -
Page 5: Receiving Your Shipment
® ® Simple Logger AmpFlex Current Probes Receiving Your Shipment Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify your distributor of any missing items. If the equipment appears to be damaged, file a claim immediately with the carrier and notify your distributor at once, giving a detailed description of any damage. - Page 6 ® ® Simple Logger AmpFlex Current Probes Sample Rate: 4096/hr max. Data Storage: 8192 readings Data Storage Technique: (TXR™) Time Extension Recording™ Power: 9V Alkaline NEDA 1604, 6JF22, 6LR61 Battery Life Recording: 6 months continuous recording @ 25°C Output: RS-232 via 5-pin circular connector; 1200 Bps INDICATORS Operation Mode Indicator: One Red LED ...
-
Page 7: Features
I N S T R U M E N T S 99 CHAUNCY STREET • BOSTON MA 02111, USA ( 17) 451-0227 • Fax ( 17) 423-2952 • www.aemc.com MADE IN USA BATTERY: 9 V, NEDA 1 04, LF22, LR 1... -
Page 8: Battery Installation
® ® Simple Logger AmpFlex Current Probes Battery Installation Under normal conditions, the battery will last up to 6 months of continuous recording unless the logger is restarted very frequently. In the OFF mode, the logger puts almost no load on the battery. Use the OFF mode when the logger is not in use. -
Page 9: Software
® ® Simple Logger AmpFlex Current Probes SOFTWARE MINIMUM COMPUTER REQUIREMENTS Processor: 486 or higher RAM Storage: 8MB Hard Drive Space: 8MB for application, approx. 400K for each stored 7, 8, 8.1, 10 ® file Environment: Windows Port Access: (1) 9-pin serial port and (1) parallel port for printer support INSTALLATION software is supplied on a USB drive. -
Page 10: Using The Software
® ® Simple Logger AmpFlex Current Probes USING THE SOFTWARE Launch the software and connect the RS-232 cable from your computer to the logger. Note: The first time the program is launched you will need to select a language. Select “Port” from the menu bar and select the Com port you will be using (see your computer manual). -
Page 11: Repair And Calibration
If you are experiencing any technical problems, or require any assistance with the proper operation or application of your instrument, please call or e-mail our support hotline: Phone: (800) 343-1391 • (508) 698-2115 • techsupport@aemc.com • www.aemc.com NOTE: Do not ship instruments to our Foxborough, MA address. - Page 12 ® ® Chauvin Arnoux , Inc. d.b.a AEMC Instruments 15 Faraday Drive • Dover, NH 03820 www.aemc.com 99-MAN 100208 v14 09/18...
