1 Description

Introduction

This document describes the integration of KNX installations into Modbus RTU and Modbus TCP systems using the
IntesisBox Modbus Slave – KNX gateway.
The aim of this integration is to make accessible a KNX TP-1 installation from a Modbus control system or device,
as if it was a part of the own KNX TP-1 (EIB) system and vice-versa.
For this, IntesisBox acts as a Modbus TCP server or Modbus RTU slave device in its Modbus interface, allowing
read/write points from the Modbus client device(s), and offering this point's values through its KNX interface, acting
in the KNX system as one more KNX device of the system.
Configuration is carried out using the configuration software IntesisBox
This document assumes that the user is familiar with KNX and Modbus technologies and their technical terms.
© Intesis Software S.L.U. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SLU
Ethernet TCP
KNX TP-1
Modbus RTU RS232
Integration of KNX TP-1 devices or installations into
Modbus RTU Master or Modbus TCP Clients
control and monitoring systems
User Manual r1.0 eng
®
MAPS.
Modbus TCP
Modbus RTU RS485
