Modbus Server - KNX

Points definition

Every point defined in the gateway has the Modbus Format, Point and R/W features associated to it that can be
configured. These features are explained in section 5.2.4.
Each point defined in IntesisBox has the following Modbus features associated to it:
Feature Description
#Bits One of the following bit lengths can be used:
One of the following Modbus data coding formats can be used:
Data Coding
Format
•
•
•
•
•
•
One of the following Modbus function codes can be used:
Function code
Byte Order
Register Address The Modbus register address inside the slave device for the point.
Bit inside the Bit inside the Modbus register (optional). The gateway allows bit decoding from
register generic 16 bits input/holding Modbus registers.
Bit coding into 16 bits input/holding Modbus registers is used for some devices to
encode digital values into this type of registers, being these registers normally
accessible using Modbus function codes 3 and 4 (read holding/input registers).
Read/Write 0: Read
1: Write
2: Read / Write
© Intesis Software S.L.U. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SLU
•
1 bit
•
16 bits
•
32 bits
16/32 unsigned.
16/32 bits signed (one's complement – C1).
16/32 bits signed (two's complement – C2).
16/32 bits Float.
16/ bits Bitfields.
Error comm
•
1- Read Coils.
•
2- Read Discrete Inputs.
•
3- Read Holding Registers.
•
4- Read Input Registers.
•
5- Write Single Coil.
•
6- Write Single Register.
•
15- Write Multiple Coils.
•
16- Write Multiple Registers.
•
Big Endian
•
Little Endian
•
Word Inverted Big Endian
•
Word Inverted Little Endian
