Functionality

From the KNX system point of view, in the start-up process of the gateway and also after a detection of a KNX bus
reset, the gateway polls the KNX signals configured to be updated in this situation and maintain the received values
in memory to be served to the Modbus system when requested. It also listens for any KNX telegram related to the
internal points configured in it and acts accordingly to the configuration of the related point.
From the Modbus system point of view, after the start up process, the gateway listens for any read or write request,
and serves any read request or performs any writing request of its internal points received from Modbus system. The
values received from Modbus become available to be read by the KNX system and vice-versa.
Every one of the mentioned Modbus points is associated to a KNX group address. With this, all the Modbus system
is seen as one more KNX device from the KNX system point of view, with the same configuration and operation
characteristics.
When a change in any Modbus point occurs, a WRITE telegram is sent to the associated Group Address in the KNX
bus. See details in section.
When a telegram is received from a KNX Group address associated to a Modbus point, a message is sent
immediately to the corresponding Modbus device to perform the corresponding action.

Gateway's capacity

IntesisBox capacity is listed below:
Element
Number of KNX
Communication
Objects
Number of KNX Main
Group Addresses
Number of KNX
Associations
Type of Modbus
Master devices
Number of Modbus
Master devices
© Intesis Software S.L.U. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SLU
100 250 600
version version version
100 250 600
100 250 600
200 500 1200
Modbus RTU (EIA485 or EIA232)
Modbus TCP
1 Master device per RTU Node
Up to 6 TCP connections
1200 3000
Notes
version version
Maximum
1200 3000 Communication Objects that can
be defined.
Maximum number of KNX Main
1200 3000
Group Addresses to be used
Maximum number of KNX
2400 6000
Associations
Those supporting Modbus
protocol. Communication over
TCP/IP and RTU
Number of Modbus Master
devices supported by the device
