IntesisBox IBOX-BAC-DALI User Manual page 8

®
IntesisBox BACnet/IP Server – DALI
Additionally, IntesisBox implements two Analog Outputs allowing group-based control of
ballasts. See following list:
Object Name
Dali Gxx PwrSet Requested arc power level on group
Dali Gxx Cmd Requested command on group
1
This command will overwrite ballasts' permanent storage memory. Permanent storage memories have a limited rated number of writes. Therefore,
intensive/repetitive use of this command will harm your ballasts' permanent storage memory.
In the list, value xx
Additionally, IntesisBox implements two Analog Outputs allowing broadcast control of all
ballasts together. See following list:
Object Name
Dali All PwrSet Requested arc power level to all ballasts
Object Name
Dali All Cmd Requested command to all ballasts
3
This command will overwrite ballasts' permanent storage memory. Permanent storage memories have a limited rated number of writes. Therefore,
intensive/repetitive use of this command will harm your ballasts' permanent storage memory.
2
File: IBOX-BAC-DALI User Manual eng r1.pdf
© Intesis Software S.L. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SL
Description
0% (off) ... 100% / MAX level
0 – Set Arc Power Off
1 – Arc Power 100%
2 – Step Up
3 – Step Down
10 – Set Minimum Arc Power Level
11 – Set Maximum Arc Power Level
1yy – Go to Scene
2yy – Store Current Level as Scene
3yy – Clear/Remove Scene
1yyy – Set Fade Rate to
2yyy – Set Fade Time to
3yyy – Set Max Level Rate to
4yyy – Set Min Level Time to
5yyy – Set Power-on Level Time to
6yyy – Set System-failure Level to
poses as the group number being controlled, and takes value 0 to 15.
Description
0% (off) ... 100% / MAX level
Description
0 – Set Arc Power Off
1 – Arc Power 100%
2 – Step Up
3 – Step Down
10 – Set Minimum Arc Power Level
11 – Set Maximum Arc Power Level
1yy – Go to Scene
2yy – Store Current Level as Scene
3yy – Clear/Remove Scene
1yyy – Set Fade Rate to
2yyy – Set Fade Time to
3yyy – Set Max Level Rate to
4yyy – Set Min Level Time to
5yyy – Set Power-on Level Time to
6yyy – Set System-failure Level to
xx
xx
1
1
yy
1
yy
1
yy
yyy (steps/second)
1
yyy (seconds)
1
yyy (in %)
1
yyy (in %)
yyy (in %)
yyy (in %)
3
1
yy
1
yy
1
yy
yyy (steps/second)
1
yyy (seconds)
1
(in %)
yyy
1
yyy (in %)
yyy (in %)
yyy (in %)
User's Manual eng r0
BACnet
Type
Analog
Output
Analog
Output
1
1
1
BACnet
Type
Analog
Output
BACnet
Type
Analog
Output
1
1
1
URL http://www.intesis.com
email info@intesis.com
tel +34 938047134
Object ID #
100 + xx
300 +
xx
Object ID #
116
Object ID #
117
