4. Mechanical & electrical characteristics
Enclosure
Color
Supply Voltage
Mounting
DALI bus power
source
DALI port
Ethernet port
(BACnet/IP, device
config)
LED indicators
Push buttons
Console port
Configuration
Firmware
Operational
temperature
Operational
humidity
Protection
RoHS conformity
Certifications
1
DALI test push-button and LED are meant to perform a quick test of your DALI line and connected ballasts.
2
Standard cable DB9 male-DB9 female 1,8 meters long is supplied with the device for connection to a PC COM port for
configuring and monitoring the device using the serial port (Ethernet is also possible). The configuration software, compatible
®
with Windows operating systems, is also supplied.
2
File: IBOX-BAC-DALI User Manual eng r1.pdf
© Intesis Software S.L. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SL
Plastic, type PC (UL 94 V-0).
Dimensions: 159mm 105mm x 58mm.
Light Grey / RAL 7035.
230Vac +/-10% 6W
(3-pole plug-in terminal block – line, neutral and earth)
Wall.
DIN rail EN60715 TH35.
15Vdc +/-2% 250mA.
(DALI bus is powered from IntesisBox)
1 x DALI electrically isolated (2-pole plug-in terminal block).
1 x Ethernet 10BT RJ45.
1 x Power indicator.
2 x DALI activity (Tx, Rx).
2 x Ethernet link & activity (LNK, ACT).
1 x DALI bus power
1
1 x DALI test
1
1 x DALI test
EIA232. DB9 female connector (DCE).
Via Ethernet or serial console port.
Allows upgrades via console port.
0°C to +60°C
25-90% at 50ºC, non condensing
IP20 (IEC60529).
Compliant with RoHS directive (2002/95/CE).
CE
User's Manual eng r0
2
