2.3 Mounting the VDO any-size handlebar holder

C1DS
C2DS
Step 1 Position the holder socket on the handlebar (stem optionally).
C3DS
Step 2 Feed the fixing clamp through the slot below the holder socket, pass the clamp
C4DS
around the handlebar (stem optionally) and tighten it with a little screw driver. Do not
overstress, the plastic screw might be damaged.

2.4 Twist-Click mounting of the computer

The VDO Twist-Click-System securely connects the computer with the handlebar holder.
C1DS
C2DS
step 1 Hold the computer in the 10 O'clock position (approx. 45° to the left) and place it into
C3DS
the socket.
C4DS
step 2 turn the computer to the right "twist" until it engages in the socket.
step 3 for removal turn the computer to the left (do not press or yank)
>>> P04
>>> P05
