- Page 2 INSTALLATION AND OPERATION MANUAL - VDO CYTEC C05+ Preface Thank you for buying a VDO CYTEC bicycle computer. The more familiar you get with this model, the more enjoyable your trips are going to be. Please read thoroughly all the information provided in this manual. You are getting important and useful hints for operation to make you fully benefit from all the technical features of your VDO CYTEC bicycle computer.
- Page 3 Warning: Before tightening the handlebar holder, make sure to adjust the position of the computer head (inclination) when the LCD-display is best visible for you. Only when you find the best position tighten the screw. screw...
- Page 4 1.2 Mounting the speed transmitter / sender The sensor should be mounted on the same side of the fork as the holder is on the handlebar. Make sure to position the respective rubber shim between fork and sender, position the curved back of the sender next to the spokes and make sure the sender is aimed at the receiver (computer head).
- Page 5 1.3 Mounting the spoke magnet Distance between magnet and sensor should be approx. 1-5 mm. In case this distance is not achievable in the current positioning, slide the sensor and the magnet on the fork or spoke accordingly. Watch out: Please remove the computerhead from the handlebar holder when you intend not to use your bike for a longer period of time.
-
Page 6: Installing Battery Into Computer Head
1.4 Installing battery into computer head To save battery power, your VDO CYTEC C05+ comes with the battery not yet fitted. Prior to initial use you have to install the battery first. Insert battery with positive (+) end on top. Watch out: Once the battery is properly fitted, the computer immediately changes into set-up mode (see also chapter 5). - Page 7 1.5 Function Indicator Your VDO CYTEC C05+ features a function indicator ((1)). When you are done mounting the computer, ((1)) flashes at the first rotation of the wheel. When the wheel-size is properly entered, actual speed is displayed as well.(see chapter 5). In case the function-indicator ((1)) is not flashing, please double-check: Is the computer properly fitted onto the handlebar holder? Is the spoke magnet accurately positioned opposite the speed transmitter (max 5 mm distance)?
- Page 8 LOCK UNLOCK 2.CLICK 1.LOCK 1.PRESS 2.UNLOCK...
- Page 9 3. Information features of your VDO CYTEC C05+ 3. Information features of your VDO CYTEC C05+ Your VDO CYTEC C05+ provides you with following information: Your VDO CYTEC C05+ provides you with following information: KMH-MPH KMH-MPH current speed indicated in either KMH or MPH, featuring automatic conversion into MPH current speed indicated in either KMH or MPH, featuring automatic conversion into MPH trip counter, counts your trip distance up to 999,99 km or miles.
- Page 10 This button / key has several functions. All functions of the button / key are outlined in the chart below. Your display Button / Key to indicates following be pushed information DST-ODO-CLK-ATM push MODE key brief (0.1 sec) push MODE key long (5 sec) push MODE key long (5 sec) push MODE key long (5 sec) Watch out:...
- Page 11 5.1 Programming (setting up) your wheelsize In order for the VDO CYTEC C05+ to indicate your actual speed and your trip distance, the correct wheelsize has to be entered. Wheelsize is the outer circumference of the wheel including the tire. following default is entered wheelsize = WS = 2124 mm Watch out:...
- Page 12 Watch out: In case you have selected MPH readout you must enter your wheelsize in mm. WS in mm...
- Page 13 5.3 Entering your wheelsize / entering odometer After initially installing the battery or after a battery change, your VDO CYTEC C05+ automatically switches into set-up mode for wheelsize and odometer. Start with Step 3. You might as well enter the set-up mode for wheelsize and odometer at any time by proceeding as follows: Step 1: Call ODO information in your display.
- Page 14 In case you wish to enter the precise wheelsize you have measured yourself (i.e. 2257), please proceed with step 5. Step 5: Not pressing the MODE button with in 2 seconds will make the last digit (2124) flash and change the value (4-5-6-7...) Once the correct digit (7) comes up, press the mode button.
- Page 15 Set ODOMETER Press to Stop switch to next Press to Stop switch to next Press to Stop switch to next Press to Stop switch to next Press to Stop switch to next Press sec. to start Press to select Press to switch Press to Stop switch to next Press to Stop...
- Page 16 5.4 Setting the clock CLK 5.4 Setting the clock CLK 5.4 Setting the clock CLK Your VDO CYTEC C05+ features a clock with hour and minute display Your VDO CYTEC C05+ features a clock with hour and minute display Your VDO CYTEC C05+ features a clock with hour and minute display in 24 h mode To access the clock set-up mode proceed as follows: in 24 h mode To access the clock set-up mode proceed as follows: in 24 h mode To access the clock set-up mode proceed as follows:...
- Page 17 6. Resetting information to zero 6. Resetting information to zero The following information may be reset to zero with your VDO CYTEC C05+: The following information may be reset to zero with your VDO CYTEC C05+: DST = trip distance DST = trip distance Watch out: Watch out:...
- Page 18 8 . Battery change Tip: Take down your total distance and wheelsize prior to battery change. 8.1 Changing the battery in the computer head see chapter 1.4. 9. Troubleshooting This chart outlines possible malfunctions, their causes and solutions. malfunction possible cause speed display check for proper distance between does not appear...
- Page 19 10. Warranty We warrant VDO CYTEC models (sensor, computer head and handlebar holder) to the original purchaser for five years from date of purchase against defects in material and workmanship. This does not cover the batteries and defects resulting from normal wear and tear, improper care, accidents, abuse or alteration.
- Page 20 Contents 1 computer head 1 handlebar holder with screw 1 wireless transmitter with battery 12 V, type V23GA 1 rubber shim for sensor mount 1 spoke magnet 5 cable ties 1 battery 3 V, type CR 2032 1 installation and operation manual The CYTEC tin box easily holds a mini-tool and a spare tube to carry on with your ride.
