- Page 1 CYCLECOMPUTING BEDIENUNGSANLEITUNG INSTRUCTION MANUAL MANUEL D´INSTALLATION ET D´UTILISATION MANUALE D´INSTALLAZIONE E FUNZIONAMENTO INSTALACION Y OPERACIÓN MANUAL HANDLEIDING C1DS C2DS C3DS C4DS...
- Page 2 *Watch out: old batteries require special disposal...
- Page 3 OPEN CLOSE OPEN CLOSE Battery...
- Page 5 screw...
- Page 6 OPEN CLOSE...
- Page 7 AC-button...
- Page 8 WS in mm / inch...
- Page 9 Tire size WS in mm KMH WS in inch MPH Tire size WS in mm KMH WS in inch MPH 47-305 16x1,75 1272 50,1 32-630 27x1 1/4 2199 86,6 47-406 20x1,75 1590 62,6 40-622 28x1,5 2224 87,6 34-540 24x1 3/8 1948 76,7 47-622...
- Page 10 IMPORTANT! This information will help you understand how the digital transmission of your VDO computer works. You really must follow the initial set-up steps in the order described below. ATTENTION: At a break during your ride the receiver will be switched off after 30 minutes (battery consumption).
- Page 11 This manual is valid for all VDO Series-C models. Some functions and features are not available with all models. The “flag” icon on the beginning of a chapter indicates which model this chapter is relevant for. = valid for models C1DS, = valid for models C2DS, C3DS & C4DS C3DS &...
- Page 12 >>> P01 Contents C1DS C2DS Please check package contents for its completeness: C3DS C4DS 1 VDO computer 1 VDO digital transmitter 2 Battery 3V CR2032 for the computer and transmitter 2 Battery door for the computer and transmitter 1 Handle bar mount...
- Page 13 Preface C1DS C2DS Congratulations! C3DS C4DS With your choice of a VDO cycle computer, you have decided to own the most advanced technology available. To enjoy the full potential of your computer and benefit from all the technical features, we recommend you thoroughly study this manual.
- Page 14 Index part I VDO DIGITAL SYTEM C1DS C2DS Welcome to the club: your VDO-USER-CARD C3DS Functions C4DS Optional features Installation Battery installation (computer and transmitter) Mounting sensor and magnet Mounting cable and VDO any-size handlebar mount TWIST-CLICK mounting of the computer...
- Page 15 Basic settings Language selection Measuring and setting the wheel size(s) Setting the clock Setting the odometer Changing wheel sizes from bike 1 to bike 2 Reset functions Service-Interval-Indicator Sleep-Mode Cadence (optional) Important hint: Index part II „>>> P04“ links at the begin- Stopwatch C2DS ning of a chapter are related...
- Page 16 Index part III NAVIGATOR functions C3DS C4DS Index part IV Timing functions C4DS 10.1 Selecting timing functions 10.2 Timer/countdown programming 10.3 Timer/countdown/stop watch start/stop/reset 10.4 Additional countdown functions Index part V Troubleshooting C1DS C2DS Warranty disclaimer C3DS Technical specifications C4DS...
- Page 17 1.0 VDO DIGITAL SYTEM Your VDO cycle computer operates on digitally coded, wireless transmission. Different from C1DS C2DS analogue radio transmission, data is digitally transmitted (data packages step-by-step). With C3DS your actual speed varying, the reading will change stepwise. Individual coding of the signals C4DS ensures that only data coming from your transmitter is processed.
- Page 18 ages are sent after, once the interference is over. Following data is immediately updated when the re-send data is received : trip distance riding time average speed maximum speed odometer Hence, your current data may change erratically after a interference = Update of your computer.
- Page 19 Here you can find many useful information and additional hints. C. The quick-reference manual helps you if you have not used your computer for a while and can’t remember how to use it. 1.2 Functions Information-Functions C1DS, C2DS, C3DS, C4DS: C1DS C2DS TRIPDISTANCE...
- Page 20 Timer 1 / Timer 2 COUNTDOWN countdown timer FORECAST KM(MI) trip distance prediction (at countdown) REMAIN KM(MI) trip distance remainder (at countdown) Additional Functions C1DS, C2DS, C3DS, C4DS: DIGI CONNECT RESET - Manual Transmitter Search CLOCK time display in 12 or 24 h mode...
- Page 21 Service-Interval-Indicator (wrench symbol) Additional Function C2DS, C3DS, C4DS: Timing Indicator Additional Function C4DS: Audible signal (beeper) for timing-functions 1.3 Optional features The following genuine VDO parts are available at your Bike Shop C1DS C2DS - set transmitter/magnet/handlebar mount C3DS - cadence set...
- Page 22 >>> P02 2.1 Installing the batteries in the digital transmitter and the computer Both, your VDO computer and your VDO transmitter are coming with a 3 V battery (type C1DS C2DS 2032). C3DS C4DS A. First install the battery in the digital transmitter Step 1.
- Page 23 IMPORTANT: On inserting the battery into the transmitter, the coding of the digital signals is automatically generated. The computer is only able to find the coded signal at the initial putting into operation. After a battery change, a new coding is generated in the transmitter.
- Page 24 >>> P03 2.2 Mounting transmitter and magnet C1DS C2DS important mounting instructions: C3DS C4DS a) maximum distance transmitter – computer = 150 cm (59 in) b) distance transmitter - magnet: 3 to max 10 mm (up to 0.04 in) c) mount the transmitter on the fork leg, same side where you want the computer to be on the handlebar.
- Page 25 >>> P04 2.3 Mounting the VDO any-size handlebar holder C1DS C2DS Step 1 Position the holder socket on the handlebar (stem optionally). C3DS Step 2 Feed the fixing clamp through the slot below the holder socket, pass the clamp C4DS around the handlebar (stem optionally) and tighten it with a little screw driver.
- Page 26 2.5 The new 4-line VDO display Indicator elements (Icons) C1DS C2DS Service Indicator, TIMING Indicator, Indicator Bike 1/Bike 2 and measuring system (km or mi), C3DS comparison of actual and average speed, Menu control indicator (flashes for further menu C4DS...
- Page 27 Timing Indicator Selected measuring unit C2DS, C3DS, C4DS Indicator bike 1/2 Service Indicator Actual (current) Time (clock) speed Variation / differ- ence actual speed Reading of the func- to average speed tion selected in text element 1 Text line 1 Menu control indicator Text line 2...
- Page 28 2.6 The VDO EMC-operating system C1DS C2DS EMC = Easy Menu Control C3DS C4DS EMC eases operating the computer by a full text menu control well known from most cellular phones. 4 keys combined with the 4-line display provide comfortable and user-friendly operation.
- Page 29 (push once) cancel last entry / go back one menu level (hold) return to main menu 2.7 Functions / menu structure IMPORTANT: In information menu (IM1 to IM7, see below) C1DS C2DS the lower text line indicates the entry to a sub-menu. C3DS...
- Page 30 2.7.1 Information Menus IM1. TRIPDISTANCE/SETTINGS IM2. ODO TOTAL/MORE IM2.1. ODO BIKE 1 IM2.2. ODO BIKE 2 IM3. NAVIGATOR/SELECT EM2.1. NAVIGATOR/SET C3/C4 EM2.2. NAVIGATOR/RESET *Depending on selection in Set-up-Menu IM4. „TIMING-Function“/START* C2/C3/C4 IM5. MAX SPEED C2/C3/C4 IM6. AVG SPEED/ C4: MORE C4: IM6.1.** FORECAST KM C4: IM6.2.** REMAIN KM IM7.
- Page 31 2.7.2 Set Menus EM1. DATA/RESET EM1.1. TOUR DATA/RESET EM1.2. ODO TOTAL/RESET C3/C4: EM1.3. TOT RID TM/RESET EM2. DIGI CONNECT/RESET EM3. LANGUAGE/SELECT EM8.1. TIMING/?SELECT? EM8.1.1. TIMER 1/?SELECT? EM4. WHEELSIZE/SET EM8.1.2. TIMER 2/?SELECT? EM5. ODOMETER/SET EM8.1.3. TIMER 1+2/?SELECT? EM8.1.4. COUNTDOWN/?SELECT? EM6. CLOCK/SET EM8.1.4.
- Page 32 M-key. 3. Initial operation, AC-(“Auto clear”)-button >>> P06 After installing the battery, your VDO computer brings up an English main menu. C1DS C2DS Select your language to begin with. C3DS a c “TRIPDISTANCE / SETTINGS”...
- Page 33 AC-button on the rear of the housing. 3.1 Manual Transmitter Search – DIGI CONNECT RESET After a battery change, a new coding is automatically generated in the transmitter. The C1DS C2DS computer must learn this new coding. Therefore, you have to activate the manual transmitter...
- Page 34 4. Basic settings Basic settings are settings crucial to data measuring and operating the computer. Such as C1DS C2DS language, wheel size(s), clock. C3DS C4DS WATCH OUT: Any SET procedure must be completed (menu question ?SET OK? gets accepted by pushing c). Should a SET procedure not be completed, any data entered is not stored.
- Page 35 4.2 Measuring and setting the wheel size(s) In order for your VDO computer to precisely calculate speed and distance, you have to mea- C1DS C2DS sure the circumference of your wheels With an incorrect wheel size set, all related values like C3DS speed, trip distance, odometer etc.
- Page 36 If you have selected the Metric system (KM) you have to enter your wheel size/s in millimeters. If you have selected English system (MI) you have to enter your wheel size/s in inches. TIP: Write down your wheel sizes on your VDO-User-Card for easy reference. The values listed in the chart >>>P08 are approximate.
- Page 37 If applicable, enter wheel size 2 as described above If you don’t need to enter the second wheel size, hold the b key until the computer returns to main menu TRIPDISTANCE/SETTINGS. Watch out: Default settings for the wheel sizes are as follows: Bike 1 = 2155 mm and Bike 2 = 2000 mm.
- Page 38 4.3 Setting the clock C1DS a c “TRIPDISTANCE / SETTINGS” C2DS C3DS a c “CLOCK / SET” C4DS a c “CLOCK 24-H-DISPLAY” or “CLOCK 12-H-DISPLAY” <<flashing numbers>> are ready to be set: set hours “?CONTINUE?” for minutes a c set minutes “?SET OK?”...
- Page 39 4.4 Setting the odometers C1DS C2DS You can set odometers anytime or after a battery change. Note the odometer readings for C3DS bike 1 and 2 before changing the battery C4DS a c “TRIPDISTANCE/SETTINGS” a c “ODOMETER / SET” a c “ODO BIKE 1 / SET” or “ODO BIKE 2 / SET”...
- Page 40 4.5 Changing wheel sizes from bike 1 to bike 2 If you have programmed 2 wheel sizes for 2 bikes you have to adjust your computer C1DS C2DS accordingly prior to your trip. C3DS C4DS a c „TRIPDISTANCE/SETTINGS“ a c „WHEELSIZE/SELECT“, accepted by c a c „WHEELSIZE 1“...
- Page 41 4.6 Reset functions To reset / delete certain or all tour data C1DS C2DS a c “TRIPDISTANCE/SETTINGS” C3DS a c “DATA / RESET” C4DS “TOUR DATA / RESET” or “ODO TOTAL / RESET” or “TOT RIDE TM / RESET” (only C3DS, C4DS) accept / select “RESET”...
- Page 42 TOT RID TM RESET: total ride time, ride time bike 1, ride time bike 2 (C3DS, C4DS) 5. Service-Interval-Indicator Your VDO computer features a Service-Interval-Indicator for bike 1 and bike 2. Like the C1DS C2DS indicator in some cars, the Service-Interval-Indicator reminds you to have your bike checked C3DS and serviced in a shop.
- Page 43 After further 50 km/mi the Service-Interval-Indicator symbol (wrench) will also disappear. 6. Sleep-Mode Your VDO-Computer features a sleep mode function to save battery power. During Sleep C1DS C2DS Mode the major portion of your display is shut down to save battery power. Only the clock, C3DS the Service-Interval-Indicator (if applicable) and the TIMER symbol (if activated) are displayed.
- Page 44 7. Cadence (optional) Your VDO computer is prepared for cadence measuring. To make use of these functions, C1DS C2DS you need to purchase the optional CADENCE KIT (Articlecode: 4402) at your Bike-Dealer. C3DS C4DS Operating instructions for cadence functions are described in detail in the CADENCE KIT’s extra manual.
- Page 45 Indicator Symbol << >> Resetting Stopwatch: STOPWATCH select the appropriate menu. Hold for 3 seconds After 3 seconds the STOPWATCH is reset to zero. 9. NAVIGATOR functions Your VDO computer features a NAVIGATOR function that makes it possible to follow route C3DS C4DS (Road-Book) instructions.
- Page 46 Setting the NAVIGATOR a c “NAVIGATOR / SELECT” a c “NAVIGATOR / SET“ a c “FORWARD” or “BACKWARD“ to be selected <<flashing numbers>> are ready to be set: enter / set “?NEXT DIGIT?” accept or return by b continue with next digit or correct previous entry b At the end of the set procedure you will be asked “?SET OK?”...
- Page 47 Reset NAVIGATOR to zero. “NAVIGATOR / SELECT” “NAVIGATOR / RESET” Check back: “NAVIGATOR ?RESET?” accept “RESET DONE” appears briefly and your VDO-Computer automatically returns to main menu TRIPDISTANCE/SETTINGS. 10. Timing functions Your VDO-Computer features 5 individual timing functions. With any of the functions selected C4DS the TIMING indicator <<...
- Page 48 TIMER 2: You can program another time window, i.e. for a break in your interval training TIMER 2 counts on from zero. A double beep indicates the end of TIMER 2. TIMER 1+2: With this TIMING-function selected, TIMER 1 and TIMER 2 time windows are continuously cycled one after the other.
- Page 49 10.1 Selecting timing functions a c “TRIPDISTANCE / SETTINGS C4DS a c “TIMING / SELECT” “TIMING / ?SELECT?” Note: By accepting “?SELECT?” either default setting STOPWATCH or last selected timing function is displayed . “STOPWATCH” / “COUNTDOWN” / TIMER 1” / “TIMER 2” or “TIMER 1+2” SELECTION to be confirmed / accepted “DONE”...
- Page 50 10.2 TIMER/COUNTDOWN programming While the STOPWATCH does not need any further presetting, for the TIMER and COUNT- C4DS DOWN functions the time windows have to be programmed in the first place a c “TRIPDISTANCE / SETTINGS a c “TIMING / SELECT” a c “TIMING / ?SET?”...
- Page 51 10.3 Timer/Countdown/Stopwatch start, stop and reset / Beep Starting Timer/Countdown/Stopwatch C4DS Select the timing-function of your choice in your information display: “TIMER 1 /START” or “TIMER 2/START” or “TIMER1+2/START” or “COUNTDOWN /START” or “STOPWATCH /START” “START” / “STOP” Resetting Timer/Countdown/Stopwatch Timer and Countdown feature a “fast reset”...
- Page 52 Check back COUNTDOWN With COUNTDOWN-time elapsed an automatic check back appears: ?RESET?. If you accept this by pressing c, the previously programmed COUNTDOWN time is displayed. The COUNTDOWN is now ready to be started again. 10.4 Additional Countdown Functions In COUNTDOWN mode you get to FORECAST KM/MI and REMAIN KM/MI by information C4DS menu AVG SPEED: a c “AVG SPEED/MORE”...
- Page 53 COUNTDOWN by ?RESET?, you are able to review the projected FORECAST KM/MI of your last COUNTDOWN by the “FORECAST KM/MI” menu option. 11. Troubleshooting Here’s a listing of possible malfunctions, the probable causes and suggested solutions. C1DS C2DS C3DS Malfunction...
- Page 54 = Wheel size is ZERO Display fades Battery is weak Check battery, and replace eventually Display fades Temperatures below 5° Higher temperatures will m ake your C1DS C (41° F) make your LCD display work properly C2DS display fade C3DS C4DS 12. Warranty disclaimer...
- Page 55 ranty covers defects in material and workmanship. Defects on cables, senders, transmitters and mounting materials resulting from normal wear and tear, improper care, accidents, abuse or alteration are not covered by our warranty. Opening the computer housing (except for the battery door) is considered abuse, thus not covered by our 5 year warranty.
- Page 56 13. Technical Specifications Computer: approx. 45 x 52 x 16 mm, weight 45 g C1DS Handlebar holder: weight 15 g C2DS C3DS Transmitter: weight20 g C4DS Battery: 3V, Type 2032 (Computer), 3V Type 2032 (Transmitter) Battery life: 300 hours of use, approx. 6000 km (3940 mi) only speedtransmitter use 250 hours of use, approx.
