2.2 Mounting transmitter and magnet

C1DS
C2DS
important mounting instructions:
C3DS
C4DS
a) maximum distance transmitter – computer = 150 cm (59 in)
b) distance transmitter - magnet: 3 to max 10 mm (up to 0.04 in)
c) mount the transmitter on the fork leg, same side where you want the computer to be on the
handlebar. (not applicable for stem mounting with optional stem holder).
Step 1 Prefix the transmitter on the fork leg with cable ties (do not tighten yet)
Step 2 Put the magnet around a spoke, do not fix
Step 3 Direct the magnet to the marking on the transmitter at a distance of around 3 mm and
shut the clip-mechanism
Step 4 Align transmitter and magnet and tighten the transmitter's cable ties. Clip off the cable
tie ends not needed.
