Installation Instructions
the bracket. When correctly assembled, the
2 grounhd bars mirror each other.
2. Remove 4 screws from the mounting holes in the
midplate, 2 from each side of the drive. For the
location of the mounting holes, see Illustration 1.1.
3. Position the 2 angle brackets with attached ground
bars over the mounting holes in the midplate. See
Illustration 1.3.
1 Mains side ground bar installed
Illustration 1.3 Ground Bars and Angle Brackets Installed
4
Ground Bar Kit for E1h/E2h Drives
®
VLT FC Series FC 102, FC 103, FC 202, and FC 302
4.
2 Motor side ground bar installed
Danfoss A/S © 10/2017 All rights reserved.
Fasten angle brackets to the midplate with 4 M5x18
mm screws (T25) from the kit, 2 in each angle
bracket. Tighten to 2.3 Nm (20 in-lb).
MI35K102
