Sheets float up and tend to result in double-
feeds.
Related Troubleshooting
• Double Feeding
For detailed procedure, see the Troubleshooting manual.
2-Tray LCIT: side fan level
1302 [2-Tray LCIT: Fan/Shutter]
Function
Adjusts the amount of air blown from the side fans to separate the sheets.
When to use
If double-feeds do not improve by setting 1301: [2-Tray LCIT: Paper Feed Mode] to [Prevent
Double Feed (Weakest Blow)], decrease the airflow in [Updraft Fan Level] in steps of 10%.
Sheets do not separate well because air does
not flow in between the sheets. Also, the sheets
tend to float up and result in double-feeds.
Related Troubleshooting
• Banding: 63mm (2.4inches) Intervals
• Worm Holes: Text or Edge of an Image
• Worm Holes: When Using the Clear Toner
For detailed procedure, see the Troubleshooting manual.
2-Tray LCIT: vacuum fan level
1302 [2-Tray LCIT: Fan/Shutter]
Face curl
[Side Fan Level]
Face curl
[Vacuum fan Level]
Paper Feed/Delivery from Mainframe Trays
Back curl
Sheets get pressed down and tend to result in
non-feeds.
Back curl
Sheets do not separate well because air does
not flow in between the sheets. Also, the sheets
tend to get pressed down and result in non-
feeds.
