2. Mechanism
The speed in which the paper passes through the decurl unit can be adjusted. If the speed is set too fast,
toner may adhere to the edge
of the paper, and if set too slow, wrinkles/creases may occur. Set to an optimum speed according to the
stock.
Related Advanced Settings
page 44 "Decurler feed speed"

3-Tray LCIT

FRR (feed and reverse roller paper feed system) is used to feed paper from the large capacity trays.
Every tray is installed with a blower fan to fan and separate the sheets before they are fed out with the
FRR system, which is especially effective for heavy stocks and sticky stocks. In addition, the pickup assist
function automatically turns on if [Coated] is selected from the paper settings.
If the pickup assist function is taking too much effect, double-feeds and other feed problems may occur.
To resolve such problems, adjust the fan power and/or turn ON or OFF the blower fan and/or the
pickup assist function.
Related Advanced Settings
page 43 "3-Tray LCIT"
2-Tray LCIT
The LCIT employs the air-assist pickup, similarly to the paper feed units of offset printers.
In addition to the air blown from the right/left sides, sucking air to pick up the top most sheet of the stack
enables smooth feeding without double-feeds and non-feeds even with coated stocks and super smooth
surfaced stocks that tend to stick together, providing good feed performance.
Functions of each of the fans are as follows:
• Updraft fan: Blows air to the leading edge to float up the sheet.
24
DZH021
