13.2 Using the HARDWARE Command

The HARDWARE serial command can be used to
verify that installed option cards are recognized by the
system. The HARDWARE command returns a
single-digit card code, representing the card installed:
Code
0
4
8
Table 13-2. HARDWARE Command Option Card Type
Codes
If an installed card is not recognized (HARDWARE
command returns code of 0), ensure that the card is
seated properly. Reinstall the card, if necessary, then
cycle the power to read the configuration again. If the
card is still not recognized, you may need to try a
different option card.

13.3 Using the XE EDP Command

The XE EDP command can be used to remotely query
the 520 for the error conditions shown on the front
panel. The XE command returns a decimal number
representing any existing error conditions.
If more than one error condition exists, the number
returned is the sum of the values representing the error
conditions (see Table 13-3). For example, if the XE
command returns the number 1040, this value
represents the sum of an A/D reference error (1024)
and an A/D calibration checksum error (16).
Error
Code Description
0 No error
1 EEPROM physical
error
2 Virgin EEPROM
4 Parameter
checksum error
8 Load cell calibration
checksum error
16 A/D calibration
checksum error
32 Print format
checksum error
64 Internal RAM data
error
128 External RAM data
error
Table 13-3. Error Codes Returned on XE Command
66 520 Installation Manual
Card Type
No card installed
Analog Output Card
Bus Card
Binary Value
0000 0000 0000 0000 0000
0000 0000 0000 0000 0001
0000 0000 0000 0000 0010
0000 0000 0000 0000 0100
0000 0000 0000 0000 1000
0000 0000 0000 0001 0000
0000 0000 0000 0010 0000
0000 0000 0000 0100 0000
0000 0000 0000 1000 0000
Error
Code Description
256 NV register
checksum error
512 A/D physical error
1024 A/D reference error
2048 Tare register error
4096 Accumulator
overflow error
8192 A/D underrange
16384 Power failure
32768 Gross > overload
limit
65536 Gravity error
131072 Count error
262144 Low battery error
524288 Option board error
Table 13-3. Error Codes Returned on XE Command

13.4 Status Messages

Two EDP commands, P and ZZ, can be used to
provide status about the indicator.
• The P EDP command returns whatever is
currently shown in the indicator's primary
display area.
• The ZZ EDP command returns whatever is
currently shown in both the primary and
secondary displays. Depending on the type of
device used to receive data from the indicator,
the standstill and center of zero symbols may
be shown as spaces or as special characters.
The ZZ command returns information in the
following format:
PPPPPPP uu ssssssssssssssss
where:
• is the information shown on
PPPPPPP
the primary display
• is the 2-digit units annunciator
uu
•
ssssssssssssssss
secondary display
If the indicator is in an underrange or overload
condition, the weight value is replaced with
(overload) or :::::: (underrange).
Binary Value
0000 0000 0001 0000 0000
0000 0000 0010 0000 0000
0000 0000 0100 0000 0000
0000 0000 1000 0000 0000
0000 0001 0000 0000 0000
0000 0010 0000 0000 0000
0000 0100 0000 0000 0000
0000 1000 0000 0000 0000
0001 0000 0000 0000 0000
0010 0000 0000 0000 0000
0100 0000 0000 0000 0000
1000 0000 0000 0000 0000
is the contents of the
&&&&&&
