Appendix A: Power Consumption

a a: P
PPendIx
Power Consumption Management
Purpose
The purpose of the power consumption test is to verify the power dissipation
of system, and the loading of power supply.
Test Equipment
PROVA CM-07 AC/DC CLAMP METER
Device Under Test
DUT: sys#1/
Test Procedure
1. Power up the DUT, boot into Windows 7 x32 Professional.
2. Entering standby mode (HDD power down).
3. Measure the power consumption and record it.
4. Run Burn-in test program to apply 100% full loading.
5. Measure the power consumption and record it.
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
C
ower onsumPtIon
Test Data
Full-Loading Mode
Total
Standby S3 Mode
Total
68
Sys #1
+24V
2.1A
50.4W
0.4A
9.8W
