Chapter 4: BIOS Setup
LPSS & SCC Configuration
This section is used to configure LPSS and SCC settings.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Boot Security
LPSS & SCC Devices Mode [PCI mode]
SCC Configuration
SCC eMMC Support [eMMC AUTO MODE]
SCC SD Card Support [Enabled]
SDR25 Support for SDCard [Disabled]
[Enabled]
DDR50 Support for SDCard
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
LPSS & SCC Devices Mode
Selects the LPSS and SCC device mode as ACPI mode or PCI mode.
SCC eMMC Support
Enables or disables SCC eMMC support.
SCC SD Card Support
Enables or disables SCC SD card support.
DDR50 Support for SDCard
Enables or disables DDR50 support for SD card.
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Save & Exit
LPSS & SCC Devices Mode
Settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
CSM Configuration
This section is used to configure the compatibility support module features.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Boot
Compatibility Support Module Configuration
CSM Support
CSM16 Module Version
Option ROM execution order
Network
Onboard LAN PXE
Storage
Video
Other PCI devices
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
CSM Support
Enables or disables CSM support.
Network
Controls the execution of UEFI and legacy PXE OpROM.
Onboard LAN PXE
Enables or disables onboard LAN PXE ROM.
Storage
Controls the execution of UEFI and legacy storage OpROM.
63
Security Save & Exit
Enable/Disable CSM Support.
[Enabled]
07.71
[Enabled]
[Disabled]
[Legacy only]
[Legacy only]
[Legacy only]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
