4
TOOL COOL ®
BD Controller
101N07xx Series
24 V DC

1.1 Applications

1.2 Capability

1.3 Functions

1.4 Programming
Interface

1. Introduction

The BD350GH 24 V DC compressor system is intended mainly for in parking anti-idle applications.
Secondary applications could be
• Spot cooling in buses, golf carts, smaller boats, forklifts, campers etc
• Air cargo cooling
• Cooling of switchboards and batteries in radio stations for cellular phones
The cooling capacity of the compressor is approx. 900 Watt @ Pe/Pc ~+15/+55°C
The system is able to operate in ambient temperatures up to +55 ºC (131 F).
The operating conditions are High Back Pressure (HBP).
The main functions of BD350GH compressor systems are:
• Motor / Compressor speed control
• Thermostat control (ON / OFF or electronic via NTC temperature sensor)
• ECO function to optimize compressor speed for minimum power consumption
• Condenser fan control
• Evaporator fan control
• Communication interface
• Monitoring function
• Error & event log
• Battery protection functions
• Main Switch
• Log of specific parameters
• Optimization of specific parameters via PC software before commencing mass production
The controller can be accessed using either
- the Danfoss software tool, Tool4Cool® LabEdition, or
- a custom interface. Please contact Danfoss for further information regarding custom interfaces.
DEHC.PS.100.I1.02 5
