Keysight 10070D User Manual

10070/3/4D Probes
An E2697A 1 MΩ input adapter is required to use these probes with a 50Ω input
oscilloscope. The E2697A includes one 10073D general purpose, 500 MHz, 10:1,
passive probe.
If the probe assembly is used in a manner not specified by the manufacturer, the protection
provided by the probe assembly may be impaired.
Cleaning. To clean the probe, disconnect it from the instrument and clean it with mild detergent and
water. Make sure the probe is completely dry before reconnecting it to the instrument.
The input voltage should not exceed the input voltage rating of the measuring instrument.
Keysight 5081-7690 Accessory Kit
Item Description
1 Retractable Hook Tip (also available as part number 5018-7697)
2 Colored identification tags
3 Ground Bayonet
4 IC Tip
5 Adjustment Tool
6 Ground Lead (black)
7 BNC adapter (not part of kit, order separately: 5081-7705)
This probe has a cable with a built-in wear indicator. When the insulation of the cable
deteriorates, the wear indicator becomes visible. Do not use the probe, when the
contrasting color (Black) is visible through the cable jacket. Using a product with a
worn cable may result in electric shock, fire, or equipment failure.
Avoid contact of the probe cable with hazardous live voltages. The rated voltage of the
probe tip is higher than the rated voltage of the probe cable. If the cable contacts
hazardous live voltages, it will not provide adequate protection. Contact of the cable
with hazardous live voltages may result in electric shock, fire, or equipment failure.
1
4
3
User's Guide
6
7
2
5
Qty
1
8
1
1
1
1
−
