  • Page 1 Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 2 Second Edition, May 2012 herein. Should Keysight and the user have a separate written agreement with warranty data. Do not proceed beyond a Printed in Malaysia...

  • Page 3: Keysight 1000B Series Oscilloscopes-At A Glance

    Keysight 1000B Series Oscilloscopes—At a Glance The Keysight 1000B Series oscilloscopes are low-cost portable digital storage oscilloscopes (DSOs) that deliver these powerful features: • Channel counts, input bandwidths, sample rates, and memory depths shown in the following table: Table 1...

  • Page 4: In This Book

    In This Book This guide shows how to use the Keysight 1000B Series oscilloscopes. Getting Started Describes the basic steps to take when first using the oscilloscope. Displaying Data Describes how to use the horizontal and vertical controls, channel settings, math waveforms, reference waveforms, and display settings.

  • Page 5: Table Of Contents

    Contents Keysight 1000B Series Oscilloscopes—At a Glance In This Book Figures Tables Getting Started Step 1. Inspect the package contents Step 2. Turn on the oscilloscope Step 3. Load the default oscilloscope setup Step 4. Input a waveform Step 5. Use Auto Scale Step 6.
  • Page 6 To export or import reference waveforms To return the reference waveform to its default scale Changing the Display Settings To display waveforms as vectors or dots To clear the display To set waveform persistence To adjust waveform intensity Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 7 To play-back waveforms To store recorded waveforms Adjusting the Trigger Level To adjust the trigger level To force a trigger Choosing the Trigger Mode To set up edge triggers To set up pulse width triggers Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 8 Vmin (Minimum Voltage) Vpp (Peak-to-Peak Voltage) Vtop (Top Voltage) Vbase (Base Voltage) Vamp (Amplitude Voltage = Vtop - Vbase) Vavg (Average Voltage) Vrms (Root-Mean-Square Voltage) Overshoot Preshoot Time Measurements Period Frequency Rise Time Fall Time Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 9 To switch between files, path, and directory panes To navigate the directory hierarchy To create new folders To edit folder/file names To delete folders To rename folders To delete files To recall files To rename files To display disk information Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 10 To set up the screen saver To select the vertical scale reference level To select the USB device port function Running Self-Calibration Reference Environmental Conditions Overvoltage Category Pollution Degree Pollution Degree Definitions Measurement Category Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 11 Contents Measurement Category Definitions Transient Withstand Capability Specifications and Characteristics Cleaning the Oscilloscope Contacting Keysight Safety Notices Warnings Safety Symbols Index Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 12 Contents Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 13: Figures

    Figure 22. Math Scale Setting Value Figure 23. FFT Waveform Figure 24. [Display] Key Figure 25. Alaising Figure 26. Theoretical Brick-Wall Frequency Response Figure 27. Sample Rate and Oscilloscope Bandwidth Figure 28. Real-Time Sampling Mode Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 14 Figure 52. [Print] Key Figure 53. [Utility] Key Figure 54. Mask Test Display Figure 55. Schematic Diagram of Mask Pass/Fail out Figure 56. Mask Pass/Fail out Figure 57. Mask Test Mask Setting Figure 58. Calibration Screen Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 15: Tables

    Tables Table 1. Keysight 1000B Series Oscilloscope Models Table 2. Power Requirements Table 3. Environmental Characteristics Table 4. Auto Scale Default Settings Table 5. Front Panel Controls Table 6. FFT Window Characteristics Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 16 Tables Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 17: Getting Started

    Keysight 1000B Series Oscilloscopes User’s Guide 1 Getting Started Step 1. Inspect the package contents Step 2. Turn on the oscilloscope Step 3. Load the default oscilloscope setup Step 4. Input a waveform Step 5. Use Auto Scale Step 6. Compensate probes Step 7.

  • Page 18: Step 1. Inspect The Package Contents

    3 Inspect the oscilloscope. • If there is mechanical damage or a defect, or if the oscilloscope does not operate properly or does not pass performance tests, notify your Keysight Technologies sales office. • If the shipping container is damaged, or the cushioning materials show signs of stress, notify the carrier;...

  • Page 19: Step 2. Turn On The Oscilloscope

    Use a power source that delivers the required power. Table 2 Power Requirements Name Typical Value Line rating: ~Line 50 W max 100-120 V/50/60/400 Hz, ±10% 100-240 V/50/60 Hz, ±10% To avoid electric shock, be sure the oscilloscope is properly grounded. WARNING Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 20 Non-operating to 15,000 m (49,213 ft) Vibration: Keysight class GP and MIL-PRF-28800F; Class 3 random Shock: Keysight class GP and MIL-PRF-28800F; (operating 30 g, 1/2 sine, 11-ms duration, 3 shocks/axis along major axis. Total of 18 shocks) Pollution degree 2: Normally only dry non-conductive pollution occurs.

  • Page 21: Figure 1 Power Switch

    Getting Started 2 Turn on the oscilloscope. Power switch Figure 1 Power Switch Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 22: Step 3. Load The Default Oscilloscope Setup

    2 When the Default menu appears, press [Menu On/Off] to turn off the menu. (The Undo softkey in the Default menu lets you cancel the default setup and go back to the previous setup.) Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 23: Step 4. Input A Waveform

    Use one of the supplied passive probes to input the Probe Comp signal from the front panel of the oscilloscope. To avoid damage to the oscilloscope, make sure that the input voltage at the BNC CAUTION connector does not exceed the maximum voltage (300 Vrms, CAT I). Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 24: Step 5. Use Auto Scale

    The trigger source selected is the highest-numbered channel that has a waveform applied. (The Undo softkey in the AUTO menu lets you cancel the auto scale and go back to the previous setup.) Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 25 Adjusted Volts/Div Coarse Bandwidth limit Waveform invert Horizontal position Center Horizontal "s/div" Adjusted Trigger type Edge Trigger source Measure the channel with input waveform automatically. Trigger coupling Trigger voltage Midpoint setting Trigger sweep Auto Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 26: Step 6. Compensate Probes

    4 If waveform does not appear like the Correctly Compensated waveform shown Figure 4, then use a nonmetallic tool to adjust the low frequency compensation adjustment on the probe for the flattest square wave possible. High Frequency Compensation For the supplied passive probes: Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 27: Figure 5 High Frequency Probe Compensation

    4 If waveform does not appear like the Correctly Compensated waveform shown Figure 5, then use a nonmetallic tool to adjust the 2 high frequency compensation adjustments on the probe for the flattest square wave possible. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 28: Step 7. Become Familiar With The Front Panel Controls

    Keys are used for run controls and to change other oscilloscope settings via menus and softkeys. Entry knob Setup and File controls Horizontal controls Run controls Softkeys Math functions Vertical controls Reference waveforms Trigger controls Menu controls Figure 6 Front Panel Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 29: Front Panel Overlays For Different Languages

    3 When the overlay is against the front panel, insert the tabs on the right side of the overlay into the slots on the front panel. 4 Let the overlay flatten out. It should remain secure on the front panel. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 30: Step 8. Become Familiar With The Oscilloscope Display

    Acquisition Status Trigger, rising edge, channel 1, Timebase 1.56 V Status, 500 us per division Waveform Channel 1 Reference Channel 1 Status, DC coupling, 500 mV per division Figure 7 Oscilloscope Display Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 31: Using The Oscilloscope Softkey Menus

    When one of the oscilloscope front panel keys turns on a menu, you can use the five softkeys to choose items from the menu. Some common menu item choices are: Accesses the next page of items in the menu. Accesses the previous page of items in the menu. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 32 The [Menu On/Off] front panel key turns off the menu or turns on the last accessed menu on again. The Menu Display item in the Display menu lets you select the amount of time menus are displayed (see “To change the menu display time” page 62). Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 33: Step 9. Use The Run Control Keys

    • When the [Run/Stop] key is red, data acquisition is stopped. To start acquiring data, press [Run/Stop]. • To capture and display a single acquisition (whether the oscilloscope is running or stopped), press [Single]. After capturing and displaying a single acquisition, the [Run/Stop] key is red. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 34: Step 10. Access The Built-In Help

    1 Press and hold the front panel key, softkey, or pushable knob on which you would like quick help information. The built-in help is available in 11 different languages (see “Setting the Language (Menu and Help)” on page 128). Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 35: Securing The Oscilloscope

    Getting Started Securing the Oscilloscope To secure a 1000B Series oscilloscope to its location, you can use a Kensington lock or the security loop. Hole for Kensington lock Security loop Figure 10 Securing the Instrument Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 36 Getting Started Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 37: Displaying Data

    Keysight 1000B Series Oscilloscopes User’s Guide 2 Displaying Data Using the Horizontal Controls Using the Vertical Controls Using Math Function Waveforms Using Reference Waveforms Changing the Display Settings This chapter describes how to use the horizontal and vertical controls, channel...

  • Page 38: Using The Horizontal Controls

    • The [Horiz] key — displays the Horizontal menu which lets you display the zoomed (delayed) time base, change the time base mode, and display the sample rate. Figure 11 Horizontal Controls Figure 12 shows the screen icon descriptions and control indicators. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 39: To Adjust The Horizontal Scale

    (time/div) setting (and the oscilloscope’s sample rate — see “Memory Depth and Sample Rate” on page 69). The time/div setting changes in a 1-2-5 step sequence. The time/div setting is also known as the sweep speed. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 40: To Adjust The Horizontal Position

    The position knob adjusts the horizontal position of all channels, math functions, and reference waveforms. • Push the horizontal position knob to “zero” the trigger point (in other words, move it to the center of the screen). Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 41: To Display The Zoomed Time Base

    The horizontal position knob moves the area of magnification forward and backward on the original waveform. • The bottom half of the display shows the magnified data in the zoomed time base. Zoomed window Zoomed window view Figure 13 Zoomed Time Base Window Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 42: To Change The Horizontal Time Base (Y-T, X-Y, Or Roll)

    The oscilloscope uses the untriggered sample acquisition mode and waveform data is displayed as dots. The sampling rate can vary from 4 kSa/s to 100 MSa/s, and the default sampling rate is 1 MSa/s. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 43: Figure 14 X-Y Display Format Showing Out-Of-Phase Waveforms

    Displaying Data Figure 14 X-Y Display Format Showing Out-of-Phase Waveforms Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 44: To View The Sample Rate

    1 Press [Horiz]. 2 In the Horizontal menu, the Sa Rate menu item displays the sample rate used for the current horizontal scale setting. See Also “Memory Depth and Sample Rate” on page 69. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 45: Using The Vertical Controls

    (depending on a preference setting). • The vertical position knobs — change the vertical position of the waveform on the screen. Scale knobs Position knobs Figure 15 Vertical Controls Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 46: To Turn Waveforms On Or Off (Channel, Math, Or Reference)

    The amplitude/div setting is displayed in the status bar at the bottom of the screen. To adjust the vertical position Adjusting their vertical position lets you compare waveforms by aligning them above one another or on top of each other. When an input channel waveform is on: Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 47: To Specify Channel Coupling

    Blocks the DC component of the input waveform and passes the AC component. See Figure This lets you use greater sensitivity (amplitude/div settings) to display the AC component of the waveform. The waveform is disconnected from the oscilloscope input. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 48: Figure 16 Dc Coupling Control

    Displaying Data DC Coupling DC Coupling Status Figure 16 DC Coupling Control AC Coupling AC Coupling Status Figure 17 AC Coupling Control Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 49: To Specify A Bandwidth Limit

    1 If the channel’s menu is not currently displayed, press the channel key ([1], [2], [3], or [4]). 2 In the Channel menu, press BW Limit to toggle the bandwidth limit setting “ON” and “OFF”. Bandwidth limit OFF Figure 18 BW Limit Control OFF Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 50: To Specify The Probe Attenuation

    To use a digital filter You can apply a digital filter to the sampled waveform data. 1 If the channel’s menu is not currently displayed, press the channel key ([1], [2], [3], or [4]). Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 51: To Change The Volts/Div Control Sensitivity

    1-2-5 step sequence from 2 mV/div to 10 V/div (with “1X” probe attenuation). Fine Also known as vernier, the vertical scale knob changes the amplitude/div setting in small steps between the normal (coarse scale) settings. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 52: To Invert A Waveform

    1 If the channel’s menu is not currently displayed, press the channel key ([1], [2], [3], or [4]). 2 In the Channel menu, press Invert to toggle between “ON” and “OFF”. Figure 20 Figure 21 show the changes before and after inversion. Figure 20 Waveform Before Inversion Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 53: Figure 21 Waveform After Inversion

    Displaying Data Figure 21 Waveform After Inversion Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 54: Using Math Function Waveforms

    The math scale setting is shown at the bottom of the display. Math Scale Figure 22 Math Scale Setting Value To add, subtract, or multiply waveforms 1 Press [Math]. 2 In the Math menu, press Operate. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 55: To Display The Frequency Domain Using Fft

    There are four FFT windows. Each window has trade-offs between frequency resolution and amplitude accuracy. What you want to measure and your source waveform characteristics help determine which window to use. Use the guidelines in Table 6 to select the best window. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 56 10 Use the horizontal position knob to adjust the frequency per division. The frequency scale is displayed on the screen. Use this to display the frequencies associated with the peaks in the FFT waveform. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 57: Figure 23 Fft Waveform

    This frequency is half of the sample rate. Frequencies above the Nyquist frequency will be under sampled, which causes aliasing. The Nyquist frequency is also called the folding frequency because aliased frequency components fold back from that frequency when viewing the frequency domain. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 58: Using Reference Waveforms

    2 If exporting a waveform, in the REF menu, press Source, and continue pressing the softkey or turn the entry knob to select the waveform you want to export. 3 Presh Location to choose “External”. 4 Press Save or Import. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 59: To Return The Reference Waveform To Its Default Scale

    To load the selected waveform (.wfm file), press Import. To return the reference waveform to its default scale 1 Press [Ref]. 2 In the REF menu, press Reset. The scale and position of the waveform as originally saved are restored. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 60: Changing The Display Settings

    Displaying Data Changing the Display Settings Figure 24 [Display] Key To display waveforms as vectors or dots 1 Press [Display]. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 61: To Clear The Display

    To change the grid 1 Press [Display]. 2 In the Display menu, press Grid, and continue pressing the softkey or turn the entry knob to select between: Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 62: To Adjust The Grid Brightness

    2 In the Display menu, press Menu Display, and continue pressing the softkey or turn the entry knob to select “1 s”, “2 s”, “5 s”, “10 s”, “20 s”, or “Infinite” menu display time. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 63: Capturing Data

    Keysight 1000B Series Oscilloscopes User’s Guide 3 Capturing Data Overview of Sampling Choosing the Acquisition Mode Choosing the Acquisition Mode Recording/Playing-back Waveforms Adjusting the Trigger Level Choosing the Trigger Mode Setting Other Trigger Parameters Using the External Trigger Input This chapter describes sampling and acquisition modes and how to set up...

  • Page 64: Overview Of Sampling

    /2 = Nyquist frequency (f ) = folding frequency Aliasing Aliasing occurs when signals are under-sampled (f < 2f ). Aliasing is the signal distortion caused by low frequencies falsely reconstructed from an insufficient number of sample points. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 65: Oscilloscope Bandwidth And Sample Rate

    At the oscilloscope bandwidth, sampling theory says the required sample rate is = 2f . However, the theory assumes there are no frequency components above in this case) and it requires a system with an ideal brick-wall frequency response. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 66: Figure 26 Theoretical Brick-Wall Frequency Response

    (square waves are made up of sine waves at the fundamental frequency and an infinite number of odd harmonics), and typically, for 1 Ghz bandwidths and below, oscilloscopes have a Gaussian frequency response. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 67: Oscilloscope Rise Time

    See Also Evaluating Oscilloscope Sample Rates vs. Sampling Fidelity: How to Make the Most Accurate Digital Measurements, Keysight Application Note 1587 (http://literature.cdn.keysight.com/litweb/pdf/5989-5732EN.pdf) Oscilloscope Rise Time Closely related to an oscilloscope’s bandwidth specification is its rise time specification.

  • Page 68: Oscilloscope Bandwidth Required

    = 1.0 x f knee = 1.3 x f knee = 1.9 x f knee See Also Choosing an Oscilloscope with the Right Bandwidth for your Application, Keysight Application Note 1588 (http://literature.cdn.keysight.com/litweb/pdf/5989-5733EN.pdf) Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 69: Memory Depth And Sample Rate

    10 kSa/s. The actual sample rate, is displayed in the Horizontal menu (see “To view the sample rate” on page 44). The oscilloscope achieves the actual sample rate by throwing away (decimating) unneeded samples. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 70: Choosing The Sampling Mode

    Use the real-time sampling mode when capturing (non-repetitive) single-shot or pulse waveforms. The 1000B Series oscilloscopes provide real-time sampling rates up to 500 MSa/s (when two channels are on) or 1 GSa/s (when one channel is on). To select the Real-Time sampling mode: 1 Press [Acquire].

  • Page 71: To Select The Equivalent-Time Sampling Mode

    The benefits of the equivalent-time sampling mode are negligible when sample rates are the same as available in the real-time sampling mode. In the 1000B Series oscilloscopes, the equivalent time sampling mode can achieve up to 40 ps of horizontal resolution (equivalent to 25 GSa/s).
  • Page 72 Capturing Data 2 In the Acquire menu, select Sampling to choose the “Equ-Time” sampling mode. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 73: Choosing The Acquisition Mode

    The osilloscope can operate in normal, average, or peak detect acquisition modes. You can choose the oscilloscope’s acquisition mode in the Acquire menu (accessed by pressing the [Acquire] front panel key). Figure 30 [Acquire] Key Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 74: To Select The Normal Acquisition Mode

    In the Average acquisition mode, acquisitions are made, and the running average over the specified number of acquisitions is displayed. Use the Average acquisition mode to remove random noise from the waveform and to improve measurement accuracy. Figure 31 Noisy Waveform Without Averaging Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 75: To Select The Peak Detect Acquisition Mode

    Consequently, samples are thrown away (decimated), and you can miss narrow excursions on a signal. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 76: Figure 33 Peak Detect Waveform

    Peak Detect acquisition mode to avoid waveform aliasing. To select the Peak Detect acquisition mode: 1 Press [Acquire]. 2 In the Acquire menu, press Acquisition. 3 Continue pressing the Acquisition softkey or turn the entry knob to select “Peak Detect”. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 77: To Turn Off/On Sine(X)/X Interpolation

    The effects of sine(x)/x interpolation are only noticeable when the horizontal scale is set to 20 ns or faster. 1 Press [Acquire]. 2 In the Acquire menu, press Sinx/x to turn sine(x)/x interpolation “OFF” or “ON”. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 78: Recording/Playing-Back Waveforms

    1 In the Sequence menu ([Acquire] > Sequence > Mode=Record), press Operate to start or stop recording. Appears on the menu when not recording; press Operate to start recording. Appears on the menu when recording; press Operate to stop recording. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 79: To Play-Back Waveforms

    To select the interval between played-back frames 1 In the Sequence menu ([Acquire] > Sequence > Mode=Play back), press Interval. 2 Turn the entry knob to select an interval from 1 ms to 20 s. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 80: To Store Recorded Waveforms

    1000. To select internal/external recording storage location 1 In the Sequence menu ([Acquire] > Sequence > Mode=Storage), press Location to toggle between Internal and External. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 81 2 In the Sequence menu ([Acquire] > Sequence > Mode=Storage), press Imp./Exp.. 3 Use the Disk Manager to select the file and import or export the waveform recording. See “Using the Disk Manager” on page 116. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 82: Adjusting The Trigger Level

    1 Press [Force Trigger]. Forcing a trigger is useful, for example, when you want to display the DC voltage of a level signal. The [Force Trigger] key has no effect if the acquisition is already stopped. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 83 When the oscilloscope’s front panel is locked by a remote program (shown by a red “Rmt” on the upper-right part of the display), pressing the [Force Trigger] key returns the front panel to Local control. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 84: Choosing The Trigger Mode

    5 Press Source and continue pressing the softkey or turn the entry knob to select the waveform to trigger on: CH1 - CH2 The oscilloscope input channel. The external trigger input. AC Line The AC power line. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 85: To Set Up Pulse Width Triggers

    Positive pulse greater than the width setting. Positive pulse less than the width setting. Negative pulse greater than the width setting. Negative pulse less than the width setting. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 86: To Set Up Video Triggers

    If you select “Line Num”, press the following Line Num menu item and turn the entry knob to select the line number. Odd Field Trigger on an odd field. Even Field Trigger on an even field. 7 Press Standard to toggle between: Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 87: Figure 35 Line Synchronization

    Capturing Data NTSC Trigger on an NTSC video waveform. PAL/ SECAM Trigger on a PAL or SECAM video waveform. Figure 35 Line Synchronization Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 88: To Set Up Alternate Triggers

    At this point, the remaining items in the Trigger menu let you set up independent triggers for the selected channel. For each source, you can set up edge, pulse width, or video triggering. You can also specify other trigger setup options, except trigger sweep. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 89: Figure 37 Alternate Triggers

    Capturing Data Figure 37 Alternate Triggers Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 90: Setting Other Trigger Parameters

    To set the trigger coupling: 1 Press [Menu]. 2 In the Trigger menu, press Set Up. 3 In the Set Up menu, press Coupling. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 91: To Set The Trigger High-Frequency Reject Coupling

    To set the trigger high-frequency reject coupling: 1 Press [Menu]. 2 In the Trigger menu, press Set Up. 3 In the Set Up menu, press HF Reject to toggle between “ON” and “OFF”. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 92: To Change The Trigger Sensitivity

    To change the trigger sensitivity Trigger sensitivity specifies the vertical change that must occur in order for a trigger to be recognized. In the 1000B Series oscilloscopes, you can adjust the trigger sensitivity. For example, to reduce the influence of noise, you can lower the trigger sensitivity (by increasing the vertical change required to trigger).

  • Page 93: To Specify A Trigger Holdoff

    To reset the trigger holdoff 1 In the Set Up menu, select the Holdoff Reset menu item to return the trigger holdoff setting to the 100 ns minimum value. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 94: Using The External Trigger Input

    Capturing Data Using the External Trigger Input You can trigger on external inputs by selecting “EXT” as the trigger source in all trigger modes except Alternate. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 95: Making Measurements

    Keysight 1000B Series Oscilloscopes User’s Guide 4 Making Measurements Displaying Automatic Measurements Voltage Measurements Time Measurements Counter (Frequency) Making Cursor Measurements This chapter shows how to make automatic voltage measurements, automatic time measurements, and cursor measurements.

  • Page 96: Displaying Automatic Measurements

    You can use the [Meas] key to display automatic measurements. The oscilloscope has 22 automatic measurements and a hardware frequency counter (see “Voltage Measurements” on page 98 and “Time Measurements” on page 101). Figure 39 [Meas] Key Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 97: To Display An Automatic Measurement

    2 In the Measure menu, press Clear to clear all automatic measurements from the display. To display or hide all automatic measurements 1 Press [Meas]. 2 In the Measure menu, press Display All to toggle the display of all automatic measurements “ON” or “OFF”. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 98: Voltage Measurements

    • Overshoot. • Preshoot. Overshoot Overshoot base Preshoot Figure 40 Voltage Measurement Points Vmax (Maximum Voltage) The maximum amplitude. The most positive peak voltage measured over the entire waveform. See Figure 40 on page 98. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 99: Vmin (Minimum Voltage)

    Vavg (Average Voltage) The arithmetic mean over the entire waveform. Vrms (Root-Mean-Square Voltage) The true root-mean-square voltage over the entire waveform.  --------------- - Where: = value at i point. n = number of points. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 100: Overshoot

    Making Measurements Overshoot Defined as (Vmax-Vtop)/Vamp, useful for square and pulse waveforms. See Figure 40 on page 98. Preshoot Defined as (Vmin-Vbase)/Vamp, useful for square and pulse waveforms. See Figure 40 on page 98. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 101: Time Measurements

    • Delay A-B, rising edges. • Delay A-B, falling edges. • Phase A-B, rising edges. • Phase A-B, falling edges. Period Measures the period of a waveform. Time origin line Base Period Figure 41 Period and Frequency Measurements Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 102: Frequency

    90% (upper) 50% (middle) 10% (lower) Vbase Rising Falling edge edge Figure 42 Rise Time and Fall Time Measurements Fall Time Measures the fall time of a waveform. See Figure 42 on page 102. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 103: Positive Pulse Width

    Measures the negative pulse width of a waveform. See Figure 43 on page 103. Positive Duty Cycle Measures the positive duty cycle of a waveform. Negative Duty Cycle Measures the negative duty cycle of a waveform. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 104: Delay Between Rising Edges

    Channel 2 Delay from channel 1 to channel 2 falling edge Figure 44 Delay Measurements Delay Between Falling Edges Measures the delay between two waveforms using the falling edges. See Figure 44 on page 104. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 105: Phase Between Rising Edges

    Channel 2 Phase from channel 1 to channel 2 rising edge Figure 45 Phase Measurements Phase Between Falling Edges Measures the phase between two waveforms using the falling edges. See Figure 45 on page 105. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 106: Counter (Frequency)

    Making Measurements Counter (Frequency) The 1000B Series oscilloscopes have an integrated 6-digit hardware frequency counter. The counter operates on the currently selected trigger source and can measure frequencies from 5 Hz to the bandwidth of the oscilloscope. The counter uses the trigger comparator to count the number of cycles within a period of time (known as the gate time), so the trigger level must be set correctly.

  • Page 107: Making Cursor Measurements

    Gives you one or two manually adjustable, cross-hair cursors that track the points of a waveform, measuring time and amplitude. Auto Gives you automatically adjusted cursors for the most recently displayed voltage or time measurement. Cursors are tuned off. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 108: To Use Manually Adjustable Cursors

    To use manually adjustable cursors You can set up two parallel, manually adjustable cursors to make amplitude (vertical) or time (horizontal) measurements on a selected waveform. 1 Press [Cursors]. 2 In the Cursors menu, press Mode. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 109: To Use Tracking Cross-Hair Cursors

    “Track”. 4 Press Cursor A, and continue pressing the softkey or turn the entry knob to select the channel on which to make the measurement (or “None” to turn off the cursor). Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 110: To Display Cursors For Automatic Measurements

    In the “Auto” cursors mode: • Cursors appear for the most recently displayed automatic measurement (see “To display an automatic measurement” on page 97). • No cursors are displayed if there are no automatic measurements. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 111: Saving, Recalling, And Printing Data

    Keysight 1000B Series Oscilloscopes User’s Guide 5 Saving, Recalling, and Printing Data Saving and Recalling Data Using the Disk Manager Printing Screens This chapter describes how to save, recall, and print data. The oscilloscope has internal, nonvolatile memory locations for saving and recalling waveforms and setups.

  • Page 112: Saving And Recalling Data

    You can also save/recall waveforms and setups to an external USB drive when it is connected to a rectangular USB host port. 1 Press [Save/Recall]. 2 In the Storage menu, press Storage. 3 Continue pressing the Storage softkey or turn the entry knob to select “Waveform”. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 113: To Save And Recall Oscilloscope Setups

    To save to or recall from internal storage: a Press Internal. b In the Internal menu, press Location. c Continue pressing the Location softkey or turn the entry knob to select the desired internal storage location. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 114: To Save Screens To Bmp Or Png Format Files

    6 Use the disk manager dialog to navigate to the folder where you want to save the file (see “To navigate the directory hierarchy” on page 117). 7 In the External menu, press New File, enter the filename (see “To edit folder/file names” on page 118), and press Save. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 115: To Save Data To Csv Format Files

    7 Use the disk manager dialog to navigate to the folder where you want to save the file (see “To navigate the directory hierarchy” on page 117). 8 In the External menu, press New File, enter the filename (see “To edit folder/file names” on page 118), and press Save. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 116: Using The Disk Manager

    Disk Manager to select and name files and folders. To access the Disk Mana. menu: 1 Press [Save/Recall]. 2 In the Storage menu, press Disk Mana.. The Disk Manager screen appears. It looks similar to: Figure 49 Disk Manager Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 117: To Switch Between Files, Path, And Directory Panes

    1 In the Disk Mana. menu ([Save/Recall] > Disk Mana.), press New Folder. 2 Use the folder/file naming dialog to enter the folder name. See “To edit folder/file names” on page 118. 3 In the New Folder menu, press Save. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 118: To Edit Folder/File Names

    On “En”, change from single-byte to multi-byte character entry fields. • Select the menu item to delete a character from the name. To delete folders In the directory pane (see “To switch between files, path, and directory panes” page 117): Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 119: To Rename Folders

    2 Press Recall to load the selected file. To rename files In the files pane (see “To switch between files, path, and directory panes” page 117): 1 Turn the entry knob to select the file. 2 Press Rename. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 120: To Display Disk Information

    3 Use the folder/file naming dialog to edit the file name. See “To edit folder/file names” on page 118. 4 In the Rename menu, press Ok. To display disk information 1 In the Disk Mana. menu ([Save/Recall] > Disk Mana.), press Disk info. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 121: Printing Screens

    Saving, Recalling, and Printing Data Printing Screens You can print oscilloscope display screens to: • A PictBridge compliant printer connected to the (square) USB device port on the oscilloscope’s back panel. Figure 51 USB Device Port Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 122: To Choose A Pictbridge Printer

    If there are problems when connecting the USB device port to a PictBridge compliant printer or remote computer, see “To select the USB device port function” on page 135. To print with inverted screen colors 1 Press [Print]. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 123: To Choose Color Or Grayscale Printing

    Color When this option is selected, the traces are printed in color. To copy a screen to the printer 1 Press [Print]. 2 In the Print menu, press the Print softkey. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 124 Saving, Recalling, and Printing Data Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 125: Oscilloscope Utility Settings

    Keysight 1000B Series Oscilloscopes User’s Guide 6 Oscilloscope Utility Settings Displaying System Information Turning Sound ON or OFF Setting the Language (Menu and Help) Performing Mask Tests Setting Preferences Running Self-Calibration This chapter describes oscilloscope settings found in the Utilities menu.

  • Page 126: Figure 53 [Utility] Key

    Oscilloscope Utility Settings Figure 53 [Utility] Key Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 127: Displaying System Information

    2 In the Utilities menu, press Sound to toggle between on and off. Appears on the menu when sound is off; press Sound to run the test. Appears on the menu when sound is on; press Sound to stop the test Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 128: Setting The Language (Menu And Help)

    • Simplified Chinese. • Traditional Chinese. • Korean. • Japanese. • English. • German. • French. • Portuguese. • Spanish. • Italian. • Russian. If quick help is unavailable in a particular language, English is displayed. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 129: Performing Mask Tests

    To select the source channel for mask tests 1 In the Mask Test menu ([Utility] > Mask Test), press Source. 2 Continue pressing the Source softkey or turn the entry knob to select the desired input channel. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 130: To Run/Stop A Mask Test

    The message display shows the failed, passed, and total number of waveforms. Figure 54 Mask Test Display To set the mask test output condition 1 In the Mask Test menu ([Utility] > Mask Test), press Output. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 131: Figure 55 Schematic Diagram Of Mask Pass/Fail Out

    +5.0 V output PhotoMOS Relay 2k Ω socket connector I < ±100 mA to internal circuit V < ±400 V Recommended Custom Circuit Optically Isolated Figure 55 Schematic Diagram of Mask Pass/Fail out Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 132: To Stop A Mask Test On The Output Condition

    You can create masks by adding horizontal and vertical margins to a signal. You can save and load masks from internal memory or an external USB drive. And you can export and import masks from an exteral USB drive. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 133: Figure 57 Mask Test Mask Setting

    The margin can be set from 0.04 div to 4.00 div. To create a mask using the failure margin settings 1 In the Mask menu ([Utility] > Mask Test > MaskSetting), press Create Mask. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 134 When importing a mask while the Location is Internal or when importing or recalling a mask NOTE while the Location is External, the mask is imported or recalled to internal memory. To activate the mask, you must set the Location to Internal, then Recall from internal memory. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 135: Setting Preferences

    “To adjust the vertical scale” on page 46. To select the USB device port function The (square) USB device port on the oscilloscope’s back panel can be used for: • Connecting to a PictBridge compliant printer. Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 136 1 In the Preference menu ([Utility] > Preference), press USB Device to toggle between: Computer Specifies the that the USB device port will be connected to a computer host. PictBridge Specifies the that the USB device port will be connected to a PictBridge compliant printer host. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 137: Running Self-Calibration

    Before performing the automatic calibration, let the oscilloscope warm-up at least 30 NOTE minutes. To run the oscilloscope’s self-calibration: 1 Press [Utility]. 2 In the Utilities menu, press Sel f-Cal. 3 Follow the instructions on the Calibration screen. Figure 58 Calibration Screen Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 138 Oscilloscope Utility Settings Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 139: Reference

    Keysight 1000B Series Oscilloscopes User’s Guide 7 Reference Environmental Conditions Measurement Category Specifications and Characteristics Cleaning the Oscilloscope Contacting Keysight This chapter contains reference information for the 1000B Series oscilloscopes.

  • Page 140: Environmental Conditions

    This product is intended to be powered by MAINS that comply to Overvoltage Category II, which is typical of cord-and-plug connected equipment. Pollution Degree The 1000B Series oscilloscope may be operated in environments of Pollution Degree 2 (or Pollution Degree 1). Pollution Degree Definitions Pollution Degree 1: No pollution or only dry, non-conductive pollution occurs.

  • Page 141: Measurement Category

    Reference Measurement Category The 1000B Series oscilloscope is intended to be used for measurements in Measurement Category I. Use this instrument only for measurements within its specified measurement WARNING categories. Measurement Category Definitions Measurement category I is for measurements performed on circuits not directly connected to MAINS.

  • Page 142: Specifications And Characteristics

    Reference Specifications and Characteristics For complete, up-to-date specifications and characteristics, find the 1000B Series oscilloscopes data sheet at: www.keysight.com Cleaning the Oscilloscope If the instrument requires cleaning: 1 Remove power from the instrument. 2 Clean the external surfaces of the instrument with a soft cloth dampened with a mixture of mild detergent and water.

  • Page 143: A Safety Notices

    Keysight 1000B Series Oscilloscopes User’s Guide A Safety Notices Warnings Safety Symbols This apparatus has been designed and tested in accordance with UL 61010-1:2004 2nd Edition, and has been supplied in a safe condition. This is a Safety Class I instrument (provided with terminal for protective earthing). Before applying power, verify that the correct safety precautions are taken (see the following warnings).

  • Page 144: Safety Symbols

    Hazardous voltage symbol. Earth terminal symbol: Used to indicate a circuit common connected to grounded chassis. Keysight 1000B Series Oscilloscopes User’s Guide...

  • Page 145: Index

    DC voltage of a level signal, files, deleting, bandwidth required, oscilloscope, decimated samples, 69, files, loading, bandwidth, oscilloscope, default scale, reference waveform, files, renaming, beeper sound, Default Setup key, filter, digital, Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 146 78, horizontal position knob, 38, 40, mask, saving, overshoot measurement, horizontal resolution, masks, exporting/importing, overvoltage category, horizontal scale, 39, 70, masks, setting up, horizontal scale controls indicators, math function waveforms, 3, 44, Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 147 USB Device port function, recorded waveforms, storing, shipping container, USB ports, recording waveforms, Simplified Chinese language, Utility key, Rectangle FFT window, sine(x)/x interpolation, 40, 70, reference, Single key, reference level for vertical scaling, single-shot waveforms, Keysight 1000B Series Oscilloscopes User’s Guide...
  • Page 148 Vpp (peak-to-peak voltage) measurement, Vrms (root-mean-square voltage) measurement, Vtop (top voltage) measurement, warnings, waveform intensity, waveform math, waveform persistence, waveforms, recording/playing-back, 3, waveforms, turning on or off, window, FFT, X-Y format, X-Y time base, Keysight 1000B Series Oscilloscopes User’s Guide...

Table of Contents
