BUS LEDs

The BUS LED indicates the communication status between
the Modbus communication module and the Modbus network.
Table 2 describes the status of the BUS LED.
Table 2: BUS LED Activity
BUS LED Color Description
Green The unit controller is communicating to the network.
2
Yellow Communication module is initializing.
Communication error or timeout has expired. The unit
Red
1
controller is not communicating to the network.
If the Com LED Timeout parameter is set to 0, the timeout feature is disabled.
1.
See Table 3 for additional information.
If the timeout is set to 0 and therefore disabled, the LED remains green even
2.
in the event of a communication error.

Modbus Network Connector

An RS-485 connection port connects the Modbus
communication module to the Modbus Network. It has three
pins: + , -, and Ref. The module has two RS-485 ports, but only
the top connector (Channel 0) is used
IM 969-5 • MICROTECH III CHILLER UNIT CONTROLLER
(Figure 4).

Board-To-Board Connector

The 10-pin board-to-board connector connects the MicroTech
III chiller unit controller to the Modbus communication module
(Figure 5 and Figure 8).
Figure 5: Board-to-Board Connector
6
