Backyard Discovery PERGOLA SWING Owner's Manual page 25

E2 - RIGHT ARM REST - W4L07340
(1)
1 3/8"x3 3/8"x26 5/8" (36x86x677)
H10 - SWING RAIL SUPPORT - W4L07344
(1)
1"x3 3/8"x13" (24x86x330)
STEP 13
WASHER LOCK EXT 12x19 BLK
NUT BARREL WH 5/16x7/8 BLK
NUT BARREL WH 5/16x7/8 BLK
(1)
- CHAIN SUPPORT BRACKET - A4M00632
FIG. 1
(2 PLCS)
(2 PLCS)
(2 PLCS)
WASHER LOCK EXT 12x19 BLK
(2 PLCS)
E2
SCREW PFH 8x2-1/2 BLK
(2 PLCS)
NUT LOCK 5/16 BLK
(1 PLC)
WASHER FLAT 9x18 BLK
(1 PLC)
E2
H10
H10
NUT BARREL
(4)
WH 5/16x7/8 BLK
WASHER LOCK
(4)
EXT 8x19 BLK
WASHER LOCK
(4)
EXT 12x19 BLK
BOLT WH 5/16x2-1/4 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
CHAIN SUPPORT BRACKET
(1 PLC)
WASHER FLAT 9x18 BLK
(1 PLC)
BOLT HEX 5/16x1-1/2 - BLK
(1 PLC)
BOLT WH 5/16x1 1/2 BLK
(2 PLC)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
WASHER FLAT
(2)
9x18 BLK
NUT LOCK 5/16
(1)
BLK
FIG. 2
