Backyard Discovery PERGOLA SWING Owner's Manual page 16

(4)
STEP 4
WASHER LOCK EXT 8x19 BLK
BOLT WH 5/16x2 BLK
(8 PLCS)
LAG SCREW WH 5/16x2 BLK
WASHER LOCK EXT 8x19 BLK
!
D1 - SUPPORT BRACE - W4L07809
1 3/8"x5 1/4"x25 3/8" (36x134x646)
(8 PLCS)
D1
(4 PLCS)
(4 PLCS)
WASHER
(12)
LOCK EXT
8x19 BLK
(8)
LOCK EXT
12x19 BLK
WASHER LOCK EXT 12x19 BLK
(8 PLCS)
NUT BARREL WH 5/16x7/8 BLK
(8 PLCS)
D1
D1
D1
WASHER
NUT
(8)
BARREL WH
5/16x7/8 BLK
D1
