4 User Interface of the Cluster Controller

4.2.4.7 Update and Save Menu

In the menu Update and save, you have the following options:
Parameter group
Update
Device configuration
Modbus

4.2.4.8 Parameter Groups of the Menus

Depending on whether you have selected the system view or the device view in the system tree,
either the parameters of entire device classes or the parameters of the selected device will be
displayed in the parameter groups. The parameter groups that are displayed in the menu and the
information contained in the parameter groups depend on the devices available in the system or
the device selected in the system tree.
Symbol Designation
Status
Type label
Settings
Device
User rights
DC side
AC side
Grid monitoring
System communication
32 ClusterController-BA-en-15
Option
Perform an update for the Cluster Controller via the user inter-
face (see Section 14, page 73).
Save or restore the device configuration of the Cluster Con-
troller (see Section 7.4, page 42)
Update or save the Modbus profiles or system configurations
(see Section 12.2, page 60)
Explanation
General information on device status
All values that identify the device/system
Update settings
Values that directly affect the device and that
cannot be assigned to any of the other parame-
ter groups (e.g. DC side)
All values that affect access to the device or the
system
Values that affect the DC side of the inverter or
the system
Values that affect the AC side of the inverter or
the system
Information that affects the utility grid and is par-
tially protected by the personal
SMA Grid Guard code
Values that define the communication between
the communication devices and the system, as
well as information on the update status of the
device
