POC-128 Quick Start Manual
POC-128 Appearance
Front-view
* Please use VESA compatible mounting only.
Front Bezel Screen
VESA Mounting
\
I/O Ports
T he drawings and specifications in this document are property of Advantech and may not be reproduced, copied or used without prior written permission.
Packing List
(1) 1 x POC-W128
(2) 1 x Accessory box





(1) Function Keys
Rear-view
1 x Quick Start manual
1 x Protek PMP105-13-1-HI (18Vdc/5.84A) adapter
1 x Drivers & manual CD
1 x Tool bag x 1: 8 x spare screw s
1 x PE foam for adapter fix
Page 1 of 2
(2) I/O Ports
(1) (2) (4)
(3) (6)
(1) Ethernet (netw ork) ports labeled TCP/IP (LAN1)
(2) USB1-USB5 ports* (USB2.0X3, USB3.0 X2)
(3) Line-out, Microphone-in.
(4) HDMI port
(5) COM serial port
(6) VGA port
(5)
