SWING-GATE OPERATOR
FA 00094 -E N
INSTALLATION MANUAL
FA70230CB
EN
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA70230CB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CAME FA70230CB

Summary of Contents for CAME FA70230CB

  • Page 1 SWING-GATE OPERATOR FA 00094 -E N INSTALLATION MANUAL FA70230CB English...
  • Page 2 HIS PRODUCT SHOULD ONLY BE USED FOR THE PURPOSE FOR WHICH IT WAS TO THE MOVING STRUCTURES TO THE COMPONENT PARTS ALL ANCHORING POINTS . CAME S. EXPLICITLY DESIGNED NY OTHER USE IS DANGEROUS IS NOT INCLUDING CABLES AND ANY ACCESSIBLE CONNECTIONS...

  • Page 3: Intended Use

    Gate-leaf length (m) We suggest you always fi t an electrolock onto swing gates for a more reliable closure. Technical data Type FA70230CB Protection rating (IP) Power supply (V - 50/60 Hz) 230 AC Power supply to motor (V - 50/60 Hz)
  • Page 4 Description of parts 1. Cover 2. Post bracket 3. Rubber shim 4. Control board 5. Gearmotor 6. Release hatch 7. Transformer 8. Limit switch 9. Transmission arm 10. Joint arm 11. Gate bracket Standard installation 1. Operator 2. Gearmotor 3. Flashing light 4.
  • Page 5 Applicative examples Fitted with standard jointed transmission-arm. Fitted with the STYLO-BD straight transmission-arm and slide rail. GENERAL INSTALLATION INDICATIONS Only skilled, qualified staff must install this product. Preliminary checks Before beginning, do the following: • check that the gate structure is sturdy enough, the hinges work efficiently and that there is no friction between the fixed and moving parts; •...

  • Page 6: Installation

    INSTALLATION The following illustrations are just examples, in that the space available for fitting the operator and accessories varies depending on the overall dimensions. It is up to the installer to find the most suitable solution.  The drawing show an operator fitted on the left. Install the operator on the right, symmetrically. Corrugate tube laying Lay the corrugated tubes you will need for the cables coming out of the junction pit.
  • Page 7 Marked the spots where the gate-post brace and gate brace will be fitted. The center-distances of the holes on the braces are shown in the Dimensions paragraph. Drill the anchoring points, fit the dowels or use plugs that will hold fast the screws. ...

  • Page 8: Fastening The Operator

    Fastening the operator Fit the gearmotor into the gate.post brace and tighten the nuts and bolts. Fit the plug into the socket on the gearmotor drive-shaft. Fasten the transmission arm to the drive-shaft using the slow-shaft washer and bolt. Ø10,5x39 UNI 5739 M10x14 Pin the driven arm to the transmission arm and tighten the washer and bolt.

  • Page 9: Establishing The Limit-Switch Points

    Release the gearmotor (see RELEASING THE GEARMOTOR), fit the driven arm to the gate brace as shown in the drawing. Ø 12 UNI 6592 Ø 12 UNI 6593 UNI 5739 Ø 6 M6x10 Establishing the limit-switch points  If the system is already fitted with opening and closing ground-stops, there is no need to adjust the limit switches. Contrarily, adjust the limit switches.
  • Page 10 Operator fitted on the left. With the gearmotor released and with the gate-leaf open at maximum 110°, turn the lower cam clockwise until the micro-switch activates. Fasten the cam by tightening the center screw. Close the gate leaf,turn the upper cam counter-clockwise until the micro-switch activates. Fasten the cam by tighte- ning the center screws.
  • Page 11 ELECTRICAL CONNECTIONS AND PROGRAMMING Warning! Before working on the control panel, cut off the main current supply and, if present, remove any batteries. All connections are quick-fuse protected. FUSES - Line 5 A-F - Accessories 3.15 A-F - Card 315 mA-F Description of parts 1.

  • Page 12: Power Supply

    Power supply 230 V AC 50/60 Hz  To vary the motor torque, move the corresponding faston terminal to one of the four positions; from 1 (min.) to 4 (max.). Bianco White Rosso Black Nero 1 2 3 4 Arancione Orange Purple Viola...
  • Page 13 Operator installed on the left and gearmotor installed on the right (inner view) with operator delayed when White closing. (Default setting) FA70230CB FA70230 White Electrical connections: operator fi tted to the right and gearmotor to the left (inner view) with operator delayed when opening.

  • Page 14: Command And Control Devices

    Command and control devices Before fitting the AF card, you MUST CUT OFF THE MAINS POWER SUPPLY and, remove any emergency batteries. Stop button (NC contact). For stopping the gate while excluding automatic closing. To resume movement either press the control button or any other control device.

  • Page 15: Operating Time

    Programming the features DIP-SWITCH Description of functions 1 ON AUTOMATIC CLOSING (1 OFF -deactivated) 2 ON OPEN-STOP-CLOSE-STOP from the button on 2-7 and/or from a transmitter (with AF card fitted) 2 OFF OPEN-CLOSE-INVERT from the button on 2-7 and/or from a transmitter (with AF card fitted) Adjusting the trimmers Trimmer Description of functions...
  • Page 16 Activating the radio control Connect the RG58 cable antenna cable to the corresponding terminals .  For TOP, TAM and TWIN series transmitters with 433.92 MHz frequency, set the AF card jumper as shown in the figure . Fit the AF card into the control board connector . ...

  • Page 17: Final Operations

    FINAL OPERATIONS Once you have fi nished with the connections and started up the operator, fi t the casing over the gearmotor (). Fit the casing over the gearmotor and close the hatch (). Lock the gearmotor using the key and fi t the protection cap (). RELEASING THE GEARMOTOR This procedure must be done with the main power cut off .
  • Page 18 INSTALLING AND CONNECTIONS FOR OUTER OPENING Following, are the only things that change compared to a standard installation: Fastening the brackets Establish where you will fit the gate brace and measure where the gate-post brace will fit. Make sure to respect the quotas shown in the drawing and table.
  • Page 19 Adjusting the micro-switches Operator fitted on the left. With the gearmotor released and with the gate-leaf closed,turn the lower cam clockwise until the micro-switch activates. Fasten the cam by tightening the center screw. With the gearmotor released and with the gate-leaf open at maximum 110°, turn the lower cam counter-clockwise until the micro-switch activates.
  • Page 20 Electrical connections: White Operator installed on the left and gearmotor installed on the right (inner view) with operator delayed when closing. FA70230CB FA70230 White Electrical connections: operator fi tted to the right and gearmotor to the left (inner view) with operator delayed when opening.

  • Page 21: Troubleshooting

    TROUBLESHOOTING TROUBLES POSSIBLE CAUSES FIXES It neither opens • There is no power supply • Check whether the power is on nor closes • The gearmotor is stuck • Lock the gearmotor • The transmitter's battery is run down • Replace the batteries •...
  • Page 22 Extraordinary maintenance The following table is for logging any extraordinary maintenance jobs, repairs and improvements performed by specialized contractors.  Any extraordinary maintenance jobs must be done only by specialized technicians. Extraordinary maintenance log Fitter's stamp Name of operator Job performed on (date) Technician's signature Requester's signature Job performed ___________________________________________________________________________________________...

  • Page 23: Dismantling And Disposal

    DISMANTLING AND DISPOSAL ☞ CAME S.p.A. applies a certified Environmental Management System at its premises, which is compliant with the UNI EN ISO 14001 standard to ensure the environment is safeguarded. Please continue safeguarding the environment. At CAME we consider it one of the fundamentals of our operating and market strategies. Simply...
