  • Page 1 CAME.COM/UK FAST70-P Complete kit for a pair of swing gates weighing up to 200kg per leaf / max. width 2.3m QUICK SETUP GUIDE Typical gate setup & geometry Gate motor manual release Kit wiring diagram Control panel guide & safety...
  • Page 2: Table Of Contents

    CONTENTS Control Panel: Kit Contents Quick Start Guide Safety Instructions Control Panel: Programming Transmitters Typical Gate Setup Control Panel: Safety Geometry Optional Accessories Manual Release Instructions Kit Wiring Diagram FAST70-P: KIT CONTENTS FA70230CB FA70230 AF43S Radio Frequency Card Motor with built-in ZF1N Motor Control Panel topd4Fks...
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS When correctly installed in compliance to installation instructions and adhering to all current electrical, mechanical and manufacturer regulations, your automation system will provide a high degree of safety and problem free operation. Please take note of the following warnings that must be followed in order to prevent accidents during your gate operation: •...
  • Page 4: Typical Gate Setup

    FAST: TYPICAL GATE SETUP OUTSIDE OF GATES INSIDE OF GATES FAST Motor Flashing Light (optional) 2nd set of Photocells (optional) Built-in Control Panel Selector Keypad (optional) Mechanical End Stop (not supplied) Reception Antenna Photocells (on outside of gate posts) Photocell column (optional accessory) CONTROL PANEL •...
  • Page 5: Geometry

    FA70230CB: GEOMETRY Preliminary checks Tick 1. Check that the gate structure is sturdy enough, the hinges work efficiently and that there is no friction between the fixed and moving parts 2. Make sure that measurement does not exceed the value shown in the reference table 3.
  • Page 6: Manual Release Instructions

    FAST: MANUAL RELEASE The FAST swing gate operators have a manual release lock beneath a hatch on the front of the motors. To manually release the gates: 1. Open the hatch covering the lock 2. Insert release key into lock and turn clockwise 3.
  • Page 7: Control Panel

    FAST70-P: wiring diagram ZF1N FA70230 FA70230CB Control Panel Motor Motor Cable/length 1m - 20m = 3 Core 1.5mm 20m - 30m = 3 Core 2.5mm Mains Supply 230 V AC If this If this Cable/length operator operator is 1m - 20m = 3 Core 1.5mm is installed installed on 20m - 30m = 3 Core 2.5mm...
  • Page 8: Quick Start Guide

    Safety inputs should now be configured and the gate force tested as required. Please refer to the full manual to complete the commissioning. Should the gates not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
  • Page 9 Press and hold the PROG button for 10 seconds. The warning LED fl ashes quickly during the procedure and turns off once the deletion is completed. Set DIP-switch 4 to OFF. Should the transmitter not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
  • Page 10 ZF1N: SAFETY SAFETY INPUTS FUNCTIONS > C1 REOPENING DURING CLOSING • When the automation is in its closing cycle and the safety circuit is triggered the automation will stop and reverse its motion until it reaches its fully open position again. •...
  • Page 11 FAST70-P: ACCESSORIES Code(s) Description RADIO KEYPAD SELECTORS 806SL-0170 SELT1W4G - Surface-mounted, 433.92 MHz radio-frequency keypad selector, 12-keys, with blue backlighting. 25 savable codes and password to access the programming mode. Settable in Rolling Code or Fixed Code mode. RAL7024 Grey colour. 806SL-0180 SELT1W8G - Surface-mounted, 868.35 MHz radio-frequency keypad selector, 12-keys, with blue backlighting.
  • Page 12 YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
