  • Page 1 Swing-gate operator FA01335-EN FA70230CB INSTALLATION MANUAL English...
  • Page 3 Machinery Directive 2006/42/EC and with the reference harmonized technical standards are identified in the CAME products general catalog or in the website www.came.com. • Make sure the mains power supply is disconnected during all installation procedures. • Check that the temperature ranges given and those of the location match.

  • Page 4: Dismantling And Disposal

    DISMANTLING AND DISPOSAL CAME S.p.A. employs an Environmental Management System at its premises. This system is certified and compliant with the UNI EN ISO 14001 regulation standard to ensure that the environment is respected and safeguarded. Please continue safeguarding the environment. At CAME we consider it one of the fundamentals of our operating and market strategies.

  • Page 5: Intended Use

    PRODUCT DATA AND INFORMATION Legend This symbol shows which parts to read carefully. This symbol shows which parts describe safety issues. This symbol shows which parts to tell users about. The measurements, unless otherwise stated, are in millimeters. Description Irreversible operator with control board and jointed transmission-arm for swing gates with each leaf up to 2.3 m long. Intended use Ideal for applying in private homes and apartment buildings, on small-to-medium gate posts Any installation and/or use other than that specified in this manual is forbidden.
  • Page 6 Control board All wiring connections are quick-fuse protected. For the system to work properly, before fitting any plug-in card, you MUST CUT OFF THE MAIN POWER SUPPLY and remove any batteries. Before working on the control panel, cut off the mains power supply and remove the batteries, if any. Gearmotor terminals Connector for plug-in radio frequency card (AF) Line fuse...

  • Page 7: Technical Data

    Dimensions Limits to use With irreversible gearmotors, an electric lock must be installed. MODELS FA70230CB Gate-leaf length (m) Gate-leaf weight (Kg) Technical data MODELS FA70230CB Power supply (V - 50/60 Hz) 230 AC Motor power supply (V) 230 AC Board power supply (V)
  • Page 8 Cable types and minimum thicknesses Cable length (m) up to 20 from 20 to 30 230 V AC Power supply 3G x 1.5 mm2 3G x 2.5 mm2 Power supply to motor 230 V AC 3G x 1.5 mm2 3G x 2.5 mm2 TX Photocells 2 x 0.5 mm2 2 x 0.5 mm2...

  • Page 9: Installation

    Set up the junction boxes and corrugated tubes you will need to make connections coming from the junction pit. An operator (FA70230CB) and a gearmotor (FA70230) must be installed on two-leaf gates . FA70230CB must be installed on the leaf that must start the opening maneuver first.
  • Page 10 Establishing the brackets fastening points First determine where the gate fastening bracket has to be positioned, then where the brace for fastening to the post has to be positioned. Respect the values indicated in the table. Leaf opening C Max arc (°) 90°...
  • Page 11 Fasten the braces using suitable dowels and screws. Fit the rubber shim into the gate-post brace. Fastening the gearmotor Release the gearmotor. Lay the cables needed for making the connection. Fit the gearmotor into the brace. Fasten the gearmotor to the brace using the nuts and bolts supplied. Fit the plug into the gearmotor shaft hole.

  • Page 12: Establishing The Limit-Switch Points

    Fasten the driven-arm to the transmission arm using the pin, washer and screw supplied. Fasten the driven-arm to the gate brace using the pin, washer and screw supplied. Ø 12 UNI 6593 Ø 6 UNI 5739 M6x10 Ø 12 UNI 6592 Ø...
  • Page 13 Operator fitted on the left Release the gearmotor. Entirely open the gate leaf. Turn the lower cam counter-clockwise until the micro-switch activates. Fasten the cam by tightening the center screw. Fully close the leaf. Turn the upper cam counter-clockwise until the micro-switch activates. Fasten the cam by tightening the center screws.

  • Page 14: Electrical Connections

    Output delivers normally 24 V AC. Maximum power 20 W. Electric lock 12 V - 15 W max 230VAC-50-60HZ power supply Connecting up the gearmotor The operator is designed to be fitted on the left. Red cable FA70230CB White cable Red cable FA70230CB White cable...
  • Page 15 Operator and gearmotor connection Red cable FA70230 FA70230CB White cable FA70230CB FA70230 Red cable FA70230 FA70230CB White cable FA70230 FA70230CB Signalling devices Flashing light It flashes during the operator opening and closing phases. W - E contact maximum capacity (230 V AC - 25 W) Operator status warning light It warns of the operator status.

  • Page 16: Command And Control Devices

    Command and control devices STOP button (NC contact) It stops the gate and excludes the automatic closing. Use a control device to resume movement. If the contact is not used it must be short circuited. The contact can be programmed for the hold-to-run function. Control device (NO contact) OPEN ONLY function - For opening only.
  • Page 17 DIR / DELTA-S photocells DIR / DELTA-S photocells Standard connection Connection with safety test Multiple photocell pairs can be connected. Multiple photocell pairs can be connected. If the photocells are left unused, short-circuit contact 2-C1. See safety test function. 2 TX C NC TX 2 2 TX C NC TX 2...
  • Page 18 PROGRAMMING Selecting the functions DIP-switch 1 ON AUTOMATIC CLOSING function DIP-switch 2 ON OPEN-STOP-CLOSE-STOP (sequential) function from control device (NO contact) and from radio transmitter fitted with AF card DIP-switch 2 OFF OPEN-CLOSE-INVERT (step-step) function from control device (NO contact) and from radio transmitter fitted with AF card DIP-switch 3 ON SAFETY TEST function At every opening or closing command, the board will check whether the photocells are working properly DIP-switch 4 ON...
  • Page 19 MANAGING USERS BY RADIO CONTROL Enabling the radio control Connect the RG58 cable to the terminals. Fit the AF card into the control board. Keep pressed the PROG button on the control board. Press any key on the transmitter you want to memorize. The warning LED flashes during the procedure and stays on with steady light once the saving is complete.

  • Page 20: Deleting A Single User

    Entering users You can register up to 50 users. Keep pressed the PROG button on the control board. Press any key on the transmitter you want to memorize. The warning LED flashes during the procedure and stays on with steady light once the saving is complete. Deleting a single user DIP-switch 4 must be set to ON.

  • Page 21: Deleting All Users

    Deleting all users DIP-switch 4 must be set to ON. Keep pressed for 10 seconds the PROG button on the control board. The warning LED flashes during the procedure and turns off once the deletion is completed. Reset DIP-switch 4 to OFF. FINAL OPERATIONS...
  • Page 22 OUTWARDS OPENING Establishing the brackets fastening points First determine where the gate fastening bracket has to be positioned, then where the brace for fastening to the post has to be positioned. Respect the values indicated in the table. Leaf opening arc (°) C Max 90°...
  • Page 23 Turn the upper cam counter-clockwise until the micro-switch activates. Fasten the cam by tightening the center screws. Connecting up the gearmotor The operator is designed to be fitted on the left. Red cable FA70230CB White cable Red cable FA70230CB White cable...
  • Page 24 Red cable FA70230 FA70230CB White cable FA70230CB FA70230 Red cable FA70230 FA70230CB White cable FA70230 FA70230CB...
