FIG.A
FIG.B
FIG.C
IFC17004.01
www.powercommander.com
1
Remove the main seat and the passenger seat.
2
Remove the covers for each side of the fuel tank as shown in Figure A.
3
Prop the front of the fuel tank up.
4
Slide the junction box that is under the main seat from it's rubber sleeve.
This allows room for the PCFC harness.
5
Route the PCFC harness underneath the sub frame crossover as shown in
Figure B.
6
Unplug the stock wiring harness from the throttle bodies as shown in Figure C.
This is a 16-pin brown connector located under the fuel tank on the right hand
side of the bike.
2008-2010 Kawasaki ZX-10R - 3
