  • Page 1 56F8013 Demonstration Board User Guide 56F8000 16-bit Digital Signal Controllers MC56F8013DBUG Rev. 0 3/2005 freescale.com...
  • Page 3: Table Of Contents

    Introduction 56F8013 Demonstration Board Architecture ....... . . 1-1 56F8013 Demonstration Board Connections ....... . . 1-2...
  • Page 4 56F8013 Demonstration Board User Guide, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 5 LIST OF FIGURES Block Diagram of the 56F8013 Demonstration Board ....1-2 Connecting the 56F8013 Demonstration Board Cables....1-3 Diagram of the Debug LED Interface .
  • Page 6 56F8013 Demonstration Board User Guide, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 7 LIST OF TABLES RS-232 Serial Connector Description ....... . . 2-2 LED Control.
  • Page 8 56F8013 Demonstration Board User Guide, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 9 This manual describes the hardware on the 56F8013 Demonstration Board in detail. Audience This document is intended for application developers who are creating software for devices using the Freescale 56F8013 part or a member of the 56F8000 family that is compatible with this part. Organization This manual is organized into two chapters and two appendices.
  • Page 10 Voltage is often shown as unless specifically positive: +3.3V noted as a negative value Blue Text Linkable on-line ...refer to Chapter 7, License Bold Reference sources, ...see: paths, emphasis http://www.freescale.com/ 56F8013 Demonstration Board User Guide, Rev. 0 viii Freescale Semiconductor Preliminary...
  • Page 11 56F8013 Digital signal controller with motor control peripherals Analog-to-Digital; a method of converting Analog signals to Digital values Analog-to-Digital Converter; a peripheral on the 56F8013 part Digital Signal Controller EOnCE Enhanced On-Chip Emulation; a debug bus and port which enables a designer...
  • Page 12 The following sources were referenced to produce this manual: [1] DSP56800E Reference Manual, DSP56800ERM, Freescale Semiconductor, Inc. [2] 56F8000 Peripheral Reference Manual, MC56F8000RM, Freescale Semiconduc- tor, Inc. [3] 56F8013 Technical Data, MC56F8013, Freescale Semiconductor, Inc. 56F8013 Demonstration Board User Guide, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 13: 56F8013 Demonstration Board Architecture

    Chapter 1 Introduction The 56F8013 Demonstration Board is used to demonstrate the abilities of the 56F8013 digital signal controller and to provide a hardware tool allowing the development of applications. The 56F8013 Demonstration Board is an evaluation module board that includes a 56F8013 part, RS-232 interface, user LEDs, user pushbutton switches and a daughter card connector.
  • Page 14: 56F8013 Demonstration Board Connections

    The 56F8013 Demonstration Board is flexible enough to allow a user to fully exploit the 56F8013's features to optimize the performance of his product, as shown in Figure 1-1.
  • Page 15: Connecting The 56F8013 Demonstration Board Cables

    Figure 1-2. Connecting the 56F8013 Demonstration Board Cables Perform the following steps to connect the 56F8013 Demonstration Board cables: 1. Connect the parallel extension cable to the parallel port of the host computer. 2. Connect the other end of the parallel extension cable to the JTAG interface POD. Connect...
  • Page 16 56F8013 Demonstration Board User Guide, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 17: Technical Summary

    Chapter 2 Technical Summary The 56F8013 Demonstration Board is designed as a versatile development card using the 56F8013 processor, allowing the creation of real-time software and hardware products to support a new generation of applications in servo and motor control, digital and wireless messaging, digital answering machines, feature phones, modems, and digital cameras.
  • Page 18: 56F8013

    2.1 56F8013 The 56F8013 Demonstration Board uses a Freescale 56F8013 part, designated as U1 on the board and in the schematics. This part will operate at a maximum external bus speed of 60MHz. A full description of the 56F8013, including functionality and user information, is provided in these documents: •...
  • Page 19: Debug Leds

    Figure 2-1. Table 2-2 describes the control of each LED. Setting GPIOA0, GPIOA1, GPIOA2, GPIOA3, GPIOA4, or GPIOA5 to a Logic One value will turn on the associated LED. 56F8013 INVERTING BUFFER +3.3V RED LED GPIOA0 YELLOW LED GPIOA1 GREEN LED...
  • Page 20: Debug Support

    GPIO Port A, Bit 5 2.4 Debug Support A JTAG connector, J1, on the 56F8013 Demonstration Board allows the connection of an external Host Target Interface for downloading programs and working with the 56F8013’s registers. This connector is used to communicate with an external Host Target Interface, which passes information and data back and forth with a host processor running a debugger program.
  • Page 21: Reset

    Appendix 2.7 Power Supply The main power input to the 56F8013 Demonstration Board, +9V DC at 450mA, is through a 2.1mm coax power jack, P1. This input power passes through a reverse power-blocking diode to provide a DC supply input for the +3.3V voltage regulator, U3. A 450mA power supply is provided with the 56F8013 Demonstration Board;...
  • Page 22: Daughter Card Connector

    2.8 Daughter Card Connector The 56F8013 Demonstration Board contains a daughter card connector, P2, which contains the processor’s peripheral port signals. The daughter card connector is used to connect a daughter card or a user-specific daughter card to the processor’s peripheral port signals. The daughter card connector is a 40-pin 0.1”...
  • Page 23: Test Points

    Test Points 2.9 Test Points The 56F8013 Demonstration Board board has two test points: • +3.3V, TP1 • Digital Ground (GND), TP2 Technical Summary, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 24 56F8013 Demonstration Board User Guide, Rev. 0 Freescale Semiconductor Preliminary...
  • Page 25: Appendix A 56F8013 Demonstration Board Schematics

    Appendix A 56F8013 Demonstration Board Schematics 56F8013 Demonstration Board Schematics, Rev. 0 Freescale Semiconductor Appendix A-1 Preliminary...
  • Page 26 56F8013 Demonstration Board User Guide, Rev. 0 Appendix A-2 Freescale Semiconductor Preliminary...
  • Page 27 56F8013 Demonstration Board Schematics, Rev. 0 Freescale Semiconductor Appendix A-3 Preliminary...
  • Page 28 56F8013 Demonstration Board User Guide, Rev. 0 Appendix A-4 Freescale Semiconductor Preliminary...
  • Page 29 56F8013 Demonstration Board Schematics, Rev. 0 Freescale Semiconductor Appendix A-5 Preliminary...
  • Page 30 56F8013 Demonstration Board User Guide, Rev. 0 Appendix A-6 Freescale Semiconductor Preliminary...
  • Page 31 L1 — L2 SMEC, FCB0603-1000HNT LEDs Red LED, 1206 LED1, LED4 Hewlett-Packard, HSMS-C650 Yellow LED, 1206 LED2, LED5 Hewlett-Packard, HSMY-C650 Green LED, 1206 LED3, LED6, LED7 Hewlett-Packard, HSMG-C650 56F8013 Demonstration Board Bill of Material, Rev. 0 Freescale Semiconductor Appendix B-1 Preliminary...
  • Page 32 7x2 JTAG Header SAMTEC, TSW-107-07-S-D Switches SPST Pushbutton S1 — S3 Panasonic, EVQ-PAD05R Miscellaneous Stand-off Post, 4-40 Aluminum 0.25” Hex Female, 0.375” 4-40 Screws SAE 4-40 machine screw, 0.375” 56F8013 Demonstration Board User Guide, Rev. 0 Appendix B-2 Freescale Semiconductor Preliminary...
  • Page 33 450mA power supply Joint Test Action Group 56F8000 Peripheral Reference Manual JTAG 56F8013 JTAG 56F8013 Technical Data JTAG/Enhanced OnCE (EOnCE) 56F8013 Technical Data Sheet Light Emitting Diode Analog-to-Digital Low-profile Quad Flat Package LQFP Analog-to-Digital Converter LQFP On-board power regulation Daughter Card Expansion...
  • Page 36 Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc. All other product or service names are the property of their respective owners. This product incorporates SuperFlash® technology licensed from SST. © Freescale Semiconductor, Inc. 2004. All rights reserved. 56F8013 DBUG Rev. 0 03/2005...
