- Page 1 深圳市海天雄电子有限公司 Shenzhen Haitianxiong Electronic Co., Ltd. CES-i.MX6Q Product Manual NXP Development Platform Rev. V1.0 Date：2016-10-14 www.nrisc.com...
- Page 2 To meet the needs of different areas, the core board of CES-i.MX6Q development platform adopts array board, convenient plug and long cycle. User can cut the system function according to the specific needs and design a special control module in accordance with their characteristics.
-
Page 3: Function Interface
NXP Development Platform CES-i.MX6Q Product Manual Support Linux3.0.35、Android4.4.2 operating system； Rich resource and meet demands of different area. Function Interface USB SERIAL WIFI / BT COM3 Headphone COM4 SD Card UART DC JACK SWITCH SIM Card Core Board... - Page 4 NXP Development Platform CES-i.MX6Q Product Manual Hardware Parameter NXP Cortex-A9 i.MX6Q，Main frequency 1GHz 1GB DDR3 eMMC 8GB eMMC PMIC MMPF0100F0ZES chip VivanteGC355，VivanteGC320 Core Board Array board Connection way Quectel EC20，CNC WiFi & Bluetooth RL-UM02WBS-8723VAU LW1613 Camera OV3640，3million pix Ethernet 1*Gigabit Ethernet，RJ45...
- Page 5 NXP Development Platform CES-i.MX6Q Product Manual SATA 1*SATA Real-time clock Button Software Parameter——Linux 3.0.35 Operating system Linux 3.0.35 System boot program U-boot2008.09 arm-fsl-linux-gnueabi-gcc-4.6.2，i.MX6 special ARMv7， support Hard-float Cross compile tool operation System file format EXT4/NFS/FAT32 Support web browsing, sending and receiving text messages, to provide the source...
- Page 6 NXP Development Platform CES-i.MX6Q Product Manual eMMC drive Support 8G，provide the source code IO drive External interface control, to provide the source code Used for touch screen, camera peripheral, and leads to the interface, provide the I2C drive source code...
- Page 7 NXP Development Platform CES-i.MX6Q Product Manual HDMI drive HDMI HD display， provide the source code Support 10.1 inch LVDS（1280*800）HD display and 7inch RGB display， provide the LCD drive source code TOUCH drive GT92X，support multi point capacitive touch， provide the source code SD/MMC drive Support high speed of MMC and SDIO，...
-
Page 8: Package List
NXP Development Platform CES-i.MX6Q Product Manual Package List Development Platform （expanding board+Core User CD board） Serial line Touch pen Cable 10.1 inch LVDS HD display 7 inch RGB resistance USB line display （option） Power Adapter Camera（Optional） SD card（Optional） 4G module（Optional）... -
Page 9: Service Support
NXP Development Platform CES-i.MX6Q Product Manual Service Support Technician contact information： TEL：0755-86325375 86325376 26401175 26401176 FAX：0755-26400848-803 E-mail：ces_support@ces-tech.com Working Time： Monday-Friday：9：00～12：00，13：30～18：00 Statement This introduction Information is only for users’ reference，without prior notice for the necessary amendment. More product information, please visit www.nrisc.com Shenzhen Haitianxiong Electronic Co., Ltd.
