UM10317
PCA9633 demonstration board OM6282
Rev. 01 — 15 December 2008
Document information
Info
Content
Keywords
I2C, PCA9633, RGB, RGBA, 2 x 8-bit PWM
Abstract
The OM6282 is an add-on to NXP's I2C 2005 -1 demo board. This daughter
board makes it easy to test and design with the PCA9633, a 4-bit Fast-mode
Plus (Fm+) LED driver. These boards, along with the I2CUSB Lite GUI
(PC based), provide an easy to use evaluation platform.
User manual
Advertisement
Table of Contents
Related Manuals for NXP Semiconductors UM10317
Summary of Contents for NXP Semiconductors UM10317
- Page 1 UM10317 PCA9633 demonstration board OM6282 Rev. 01 — 15 December 2008 Document information Info Content Keywords I2C, PCA9633, RGB, RGBA, 2 x 8-bit PWM Abstract The OM6282 is an add-on to NXP’s I2C 2005 -1 demo board. This daughter board makes it easy to test and design with the PCA9633, a 4-bit Fast-mode Plus (Fm+) LED driver.
-
Page 2: Contact Information
NXP Semiconductors Revision history Date Description 20081215 user manual; initial release Contact information For more information, please visit: For sales office addresses, please send an email to: UM10317_1 User manual http://www.nxp.com salesaddresses@nxp.com Rev. 01 — 15 December 2008 UM10317 PCA9633 demonstration board OM6282 ©... -
Page 3: Introduction
NXP Semiconductors 1. Introduction The PCA9633 evaluation board features LEDs for color mixing, blinking and dimming demonstrations. A graphical interface allows the user to easily explore the different functions of the driver. The board can be connected in series with other I to create an evaluation system. -
Page 4: Installation
NXP Semiconductors 4. Installation 4.1 I2C 2005-1 board and WIN-12CUSB Lite software The OM6282 is a daughter card to the OM6275 I2C 2005-1 demo board. You may download the WIN-I2CUSB Lite Software, the OM6275 user manual UM10206, and find ordering information at the NXP web site http://www.standardics.nxp.com/support/boards/i2c20051/. -
Page 5: Schematic
NXP Semiconductors 6. Schematic 3.3 V unswitched 5 V unswitched 5 V switched 3.3 V unswitched 3.3 V switched INPUT OUTPUT 5 V unswitched 5 V switched 3.3 V unswitched 3.3 V switched INPUT OUTPUT LED0 LED1 LED2 LED3 SOCKET - not populated Fig 2. -
Page 6: Om6282 Demonstration Board Main Components
NXP Semiconductors 7. OM6282 demonstration board main components Table 1. Device PCA9633PW 8. PCA9633 evaluation steps The PCA9633 functions are controlled by WIN-I2CUSB Lite GUI. Refer to the PCA9633 data sheet for additional information on the registers and functionality. 8.1 Color mixing and dimming LEDs 1. - Page 7 NXP Semiconductors Fig 3. Drop-down menu selections Fig 4. Device configuration screen Fig 5. Dimming effect UM10317_1 User manual PCA9633 demonstration board OM6282 Rev. 01 — 15 December 2008 UM10317 © NXP B.V. 2008. All rights reserved. 7 of 11...
-
Page 8: Color Mixing And Blinking Leds
NXP Semiconductors 8.2 Color mixing and blinking LEDS To set-up a blinking demo, repeat step 1 through step 7 as in following: 1. In the Mode 2 selection window, check the ‘Group Control’ box to change the mode to blinking. -
Page 9: Abbreviations
NXP Semiconductors 10. Abbreviations Table 2. Acronym C-bus RGBA SMBus 11. References PCA9633, 4-bit Fm+ I NXP Semiconductors; UM10206, I2C Demonstration Board 2005-1 Quick Start Guide — NXP Semiconductors; UM10317_1 User manual Abbreviations Description ElectroStatic Discharge Graphical User Interface Inter-integrated Circuit bus... -
Page 10: Legal Information
Right to make changes — NXP Semiconductors reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. -
Page 11: Table Of Contents
NXP Semiconductors 13. Contents Introduction ......3 Features ....... 3 Getting started .
