  • Page 1 56F801 Evaluation Module User Manual 56F800 16-bit Digital Signal Controllers DSP56F801EVMUM Rev. 2 07/2005 freescale.com...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Preface vii Audience ............. vii Organization .
  • Page 4 2.16 Peripheral Connectors ..........2-18 2.16.1 External Control Signal Expansion Connector .
  • Page 5 LIST OF FIGURES Block Diagram of the 56F801EVM ........1-2 56F801EVMJumper Reference .
  • Page 6 DSP56F801EVM User Manual, Rev. 2 Freescale Semiconductor...
  • Page 7 LIST OF TABLES 56F801EVM Default Jumper Options ....... . . 1-3 RS-232 Serial Connector Description .
  • Page 8 DSP56F801EVM User Manual, Rev. 2 Freescale Semiconductor...

  • Page 9: Preface

    Preface This reference manual describes in detail the hardware on the 56F801 Evaluation Module. Audience This document is intended for application developers who are creating software for devices using the Freescale 56F801 part. Organization This manual is organized into two chapters and two appendixes. •...

  • Page 10: Notation Conventions

    Notation Conventions This manual uses the following notational conventions: Term or Value Symbol Examples Exceptions Active High Signals No special symbol (Logic One) attached to the CLKO signal name Active Low Signals Noted with an In schematic (Logic Zero) overbar in text and drawings, Active Low in most figures Signals may be noted...

  • Page 11: Definitions, Acronyms, And Abbreviations

    Definitions, Acronyms, and Abbreviations Definitions, acronyms and abbreviations for terms used in this document are defined below for reference. Analog-to-Digital Digital-to-Analog Evaluation Module GPIO General Purpose Input and Output Port Integrated Circuit JTAG Joint Test Action Group, a bus protocol/interface used for test and debug LQFP Low-profile Quad Flat Pack MPIO...

  • Page 12: References

    References The following sources were referenced to produce this manual: [1] DSP56800 Family Manual, DSP56800FM, Freescale Semiconductor [2] DSP56F801/803/805/807 User’s Manual, DSP56F801-7UM, Freescale Semicon- ductor [3] 56F801 Technical Data, DSP56F801, Freescale Semiconductor DSP56F801EVM User Manual, Rev. 2 Freescale Semiconductor...

  • Page 13: Chapter 1 Introduction

    Chapter 1 Introduction The 56F801EVM is used to demonstrate the abilities of the 56F801 and to provide a hardware tool allowing the development of applications that use the 56F801. The 56F801EVM is an evaluation module board that includes a 56F801 part, peripheral expansion connectors, external memory and a JTAG interface.

  • Page 14: 56F801Evm Architecture

    1.1 56F801EVM Architecture The 56F801EVM facilitates the evaluation of various features present in the 56F801 part. The 56F801EVM can be used to develop real-time software and hardware products based on the 56F801. The 56F801EVM provides the features necessary for a user to write and debug software, demonstrate the functionality of that software and interface with the customer's application-specific device(s).

  • Page 15: 56F801Evm Configuration Jumpers

    56F801EVM Configuration Jumpers 1.2 56F801EVM Configuration Jumpers Nine jumper groups, (JG1-JG9), shown in 1-2, are used to configure various features on Figure the 56F801EVM board. describes the default jumper group settings. Table 1-1 JTAG DSP56F801EVM IRQA RESET RUN/STOP DOWN Figure 1-2. 56F801EVMJumper Reference Table 1-1.

  • Page 16: 56F801Evm Connections

    1.3 56F801EVM Connections An interconnection diagram is shown in for connecting the PC and the external +12V Figure 1-3 DC power supply to the 56F801EVM board. Parallel Extension Cable 56F801EVM PC-compatible Computer Connect cable to Parallel/Printer port External with 2.1mm, +12V receptacle Power...

  • Page 17: Chapter 2 Technical Summary

    Chapter 2 Technical Summary The 56F801EVM is designed as a versatile controller development card for developing real-time software and hardware products to support a new generation of applications in digital and wireless messaging, servo and motor control, digital answering machines, feature phones, modems, and digital cameras.
  • Page 18 • Light Emitting Diode (LED) power indicator [LED8] • One on-board real-time user debugging LED [LED7] • Six on-board PWM monitoring LEDs [LED1-6] • UNI-3 Motor interface [P3] — Encoder/Hall-Effect interface and selector [JG2 & JG9] — Over-Voltage sensing [U6] —...

  • Page 19: Rs-232 Serial Communications

    RS-232 Serial Communications 2.2 RS-232 Serial Communications The 56F801EVM provides an RS-232 interface by the use of an RS-232 level converter, (Maxim MAX3245EEAI, designated as U2). Refer to the RS-232 schematic diagram in 2-1. The Figure RS-232 level converter transitions the SCI UART’s +3.3V signal levels to RS-232 compatible signal levels and connects to the host’s serial port via connector P4.

  • Page 20: Clock Source

    2.3 Clock Source The 56F801EVM uses an 8.00MHz crystal, Y1, connected to its External Crystal Inputs, EXTAL and XTAL. The 56F801 uses its internal PLL to multiply the input frequency by 10, to achieve its 80MHz maximum operating frequency. An external oscillator source can be connected to the device by using the oscillator bypass connector, JG7 and JG8;...

  • Page 21: Debug Support

    Debug Support 2.5 Debug Support The 56F801EVM provides an on-board Parallel JTAG Host Target Interface and a JTAG interface connector for external Target Interface support. Two interface connectors are provided to support each of these debugging approaches. These two connectors are designated the JTAG connector and the Host Parallel Interface Connector.

  • Page 22: Parallel Jtag Interface Connector

    2.5.2 Parallel JTAG Interface Connector The Parallel JTAG Interface Connector, P2, allows the 56F801 to communicate with a Parallel Printer Port on a Windows PC; reference 2-4. By using this connector, the user can Figure download programs and work with the 56F801’s registers. shows the pin-out for this Table 2-4 connector.

  • Page 23: External Interrupt

    External Interrupt Table 2-4. Parallel JTAG Interface Connector Description (Continued) Pin # Signal Pin # Signal PORT_IDENT PORT_VCC PORT_TDO PORT_CONNECT 2.6 External Interrupt One on-board push-button switch is provided for external interrupt generation, as shown in Figure 2-5. S1 allows the user to generate a hardware interrupt for signal line IRQA. This switch allows the user to generate interrupts for his user-specific programs.

  • Page 24: Reset

    2.7 Reset Logic is provided on the 56F801 to generate a clean Power-On RESET signal. Additional, reset logic is provided to support the RESET signals from the JTAG connector, the Parallel JTAG Interface and the user RESET push-button; refer to Figure 2-6.

  • Page 25: Power Supply

    Power Supply 2.8 Power Supply The main power input to the 56F801EVM, +12V DC at 4.0A, is through a 2.1mm coax power jack. A 4.0A power supply is provided with the 56F801EVM; however, less than 300mA is required by the EVM. The remaining current is available for user motor control applications when connected to an optional motor power stage board.

  • Page 26: Uni-3 Connector Description

    2.9 UNI-3 Interface Motor control signals from a family of motor driver boards can be connected to the EVM board via the UNI-3 connector/interface. The UNI-3 connector/interface contains all of the signals needed to drive and control the motor drive boards. These signals are connected to various groups of the controller’s input and output ports;...

  • Page 27: Uni-3 Interface

    UNI-3 Interface Table 2-5. UNI-3 Connector Description (Continued) Pin # Signal Pin # Signal PFC Zero Cross Zero Cross A Zero Cross B Zero Cross C Shield Back-EMF Phase A Sense Back-EMF Phase Back-EMF Phase B Sense C Sense Technical Summary, Rev. 2 Freescale Semiconductor 2-11...

  • Page 28: Speed Up/Down Switches And Run/Stop Switch

    2.10 Speed Up/Down Switches and Run/Stop Switch Two push-button switches are connected to form the Speed UP/DOWN logic via a set of resistors to the A/D Port’s signal AN6. The resistors create a voltage divider network presenting unique voltage to the A/D port when each push button is pressed. A RUN/STOP toggle switch is connected to A/D Port’s signal AN7.

  • Page 29: Motor Control Pwm Signals And Leds

    Motor Control PWM Signals and LEDs 2.11 Motor Control PWM Signals and LEDs The 56F801 has one dedicated PWM unit. The PWM unit’s lines are connected to the UNI-3 interface connector and to a set of six PWM LEDs via inverting buffers. The inverting buffers are used to isolate and drive the device’s PWM’s outputs to the PWM LEDs.

  • Page 30: Motor Protection Logic

    2.12 Motor Protection Logic The 56F801EVM contains a UNI-3 connector that interfaces with various motor drive boards. The device can sense error conditions generated by the motor power stage boards via signals on the UNI-3 connector. The motor driver board’s Motor Supply DC Bus Voltage, Current and Motor Phase Currents are sensed on the power stage board.

  • Page 31: Fault0 Selection Circuit

    Motor Protection Logic 2.12.1 UNI-3 Motor Protection Logic The UNI-3 DC Bus Over-Voltage or the UNI-3 DC Bus Over-Current signal can be connected to the controller’s PWM fault input, FAULT0. Jumper JG3 provides the selection; reference Figure 2-10 Table 2-6. DC BUS VOLTAGE SENSE V_S_DCB +3.3V...

  • Page 32: Back-Emf And Motor Phase Current Sensing

    2.13 Back-EMF and Motor Phase Current Sensing The UNI-3 connector supplies Back-EMF and Motor Phase Current signals from the three phases of a motor attached to a motor drive unit. The Back-EMF signals on the UNI-3 connector are derived from a resistor divider network contained in the motor drive unit. These resistors divide down the attached motor’s Back-EMF voltages to a 0 to +3.3V level.

  • Page 33: Zero-Crossing Detection

    Zero-Crossing Detection 2.15 Zero-Crossing Detection An attached UNI-3 motor drive board contains logic that can send out pulses when the phase voltage of an attached 3-phase motor drops to zero. The motor drive board circuits generate a 0 to +5.0V DC pulse via voltage comparators. The resulting pulse signals are sent to a set of jumper blocks shared with the Encoder/Hall-Effect interface.

  • Page 34: Peripheral Connectors

    2.16 Peripheral Connectors The EVM board contains a group of Peripheral Expansion Connectors used to gain access to the resources of the 56F801. These signal groups have Expansion Connectors: • Timer Channel D • A/D Input Port • Serial Communications Port •...

  • Page 35: Timer Channel D Expansion Connector

    Peripheral Connectors 2.16.2 Timer Channel D Expansion Connector The Timer Channel D port is an MPIO port attached to the Timer D expansion connector. Refer for the signals attached to the connector. Table 2-8 Table 2-8. Timer D Connector Description Pin # Signal Pin #...

  • Page 36: Serial Communications Port Expansion Connector

    2.16.4 Serial Communications Port Expansion Connector The Serial Communications Port, SCI0, is attached to this connector. See for the Table 2-10 connection information. Table 2-10. SCI0 Connector Description Pin # Signal Pin # Signal +3.3V DSP56F801EVM User Manual, Rev. 2 2-20 Freescale Semiconductor...

  • Page 37: Appendix A 56F801Evm Schematics

    Appendix A 56F801EVM Schematics 56F801EVM Schematics, Rev. 2 Freescale Semiconductor Appendix A-1...
  • Page 38 DSP56F801EVM User Manual, Rev. 2 Appendix A-2 Freescale Semiconductor...
  • Page 39 56F801EVM Schematics, Rev. 2 Freescale Semiconductor Appendix A-3...
  • Page 40 DSP56F801EVM User Manual, Rev. 2 Appendix A-4 Freescale Semiconductor...
  • Page 41 56F801EVM Schematics, Rev. 2 Freescale Semiconductor Appendix A-5...
  • Page 42 DSP56F801EVM User Manual, Rev. 2 Appendix A-6 Freescale Semiconductor...
  • Page 43 56F801EVM Schematics, Rev. 2 Freescale Semiconductor Appendix A-7...
  • Page 44 DSP56F801EVM User Manual, Rev. 2 Appendix A-8 Freescale Semiconductor...
  • Page 45 56F801EVM Schematics, Rev. 2 Freescale Semiconductor Appendix A-9...
  • Page 46 DSP56F801EVM User Manual, Rev. 2 Appendix A-10 Freescale Semiconductor...
  • Page 47 56F801EVM Schematics, Rev. 2 Freescale Semiconductor Appendix A-11...
  • Page 48 DSP56F801EVM User Manual, Rev. 2 Appendix A-12 Freescale Semiconductor...

  • Page 49: Appendix B 56F801Evm Bill Of Material

    Appendix B 56F801EVM Bill of Material Description Ref. Designators Vendor Part #s Integrated Circuits DSP56F801FA80 Freescale, DSP56F801FA80 MAX3245 Maxim, MAX3245EEAI 74AC04 U3, U4 Fairchild, 74AC04SC 74LCX244 ON Semiconductor, MC74LCX244DW LM393 National, LM393M MC33269DT-5.0 ON Semiconductor, MC33269DT-5.0 MC33269DT-3.3 ON Semiconductor, MC33269DT-3.3 74AC00 Fairchild, 74AC00SC Resistors...
  • Page 50 Description Ref. Designators Vendor Part #s Resistors (Continued) R2-R8, R31-R35 SMEC, RC73L2A270OHMJT R10, R11, R13, R14, R16, R17 SMEC, RC73L2A24OHMJT Potentioneters R25, R30 BC/MEPCOPAL, ST4B103CT Inductors 1.0mH L1, L2, L3, L4 Panasonic, EXC-ELSA35V LEDs Yellow LED LED1, LED3, LED5 Hewlett-Packard, HSMY-C650 Green LED LED2, LED4, LED6, LED7, Hewlett-Packard, HSMG-C650...
  • Page 51 Description Ref. Designators Vendor Part #s Jumpers (Continued) 7 x 2 Bergstick SAMTEC, TSW-107-07-S-D 6 x 1 MTA AMP, MTA 640456-6 2 x 2 Bergstick JG1, J6 SAMTEC, TSW-102-07-S-D 20 x 2 Shrouded 3M, 2540-6002UB Test Points 1 Bergstick TP1 - TP9 Samtec, TSW-101-07-S-S Crystals 8.00MHz Crystal...
