Communication Ports - Javad HPT404BT JL User Manual

4G cellular module (optional)
4G LTE Mini Card (option 1)
Technology:
LTE
UMTS (WCDMA), HSDPA,
HSUPA, HSPA+,DC-HSPA+
GSM, GPRS, EDGE
4G LTE Mini Card (option 2)
Technology:
LTE
CDMA (EVDO Rel. 0 and Rel.A)
UMTS (WCDMA), HSDPA,
HSUPA, HSPA+,DC-HSPA+
GSM, GPRS, EDGE
GNSS Receiver (optional)
Tracking Channels
Signals Tracked
Cold / Warm Start
Sensitivity for Reacquisition - 161dBm

Communication ports

Wi-Fi (IEEE 802.11 b, g, n, d, e, i)
Full-duplex 10BASE-T/100BASE-TX Ethernet port
Bluetooth V2.0+EDR Class 2
High Speed USB 2.0 configurable as Device or Host port
MicroSD card slot (fully sealed)
Serial port configurable as RS232/RS422/RS485
HPT404BT JL USER MANUAL
LTE, DC-HSPA+, HSPA+, EDGE, GPRS, GSM and CDMA networks
Bands: 1 (2100 MHz), 3 (1800MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz)
Data Rates: Category 3
Downlink 100 Mbps (20 MHz bandwidth), 50 Mbps (10 MHz bandwidth)
Uplink 50 Mbps (20 MHz bandwidth), 25 Mbps (10 MHz bandwidth)
Bands: 1 (2100 MHz), 2 (1900 MHz), 5 (850 MHz), 6 (800 MHz), 8 (900 MHz)
Data Rates: HSPA+ rates
Downlink up to 42 Mbps (category 24)
Uplink up to 5.76 Mbps (category 6)
GSM 850 (850 MHz), EGSM 900 (900 MHz), DCS 1800 (1800 MHz), PCS 1900 (1900 MHz)
Data Rates: EDGE throughput up to 236 kbps
LTE, DC-HSPA+, HSPA+, EDGE, GPRS, GSM and CDMA networks
Bands: 2 (1900 MHz), 4 (AWS) (1700/2100MHz), 5 (850 MHz), 13 (700 MHz), 17 (700 MHz), 25 (1900 MHz G Bl
ock)
Data Rates: Category 3
Downlink 100 Mbps (20 MHz bandwidth), 50 Mbps (10 MHz bandwidth)
Uplink 50 Mbps (20 MHz bandwidth), 25 Mbps (10 MHz bandwidth)
Bands: BC0 (Cellular 800 MHz), BC1 (PCS 1900 MHz), BC10 (Secondary 800 MHz)
Data Rates: CDMA IS-856 (1xEV-DO Release A)
Up to 3.1 Mbps forward channel
Up to 1.8 Mbps reverse channel
CDMA IS-2000
Up to 153 kbps, simultaneous forward and reverse channels
Bands: 1 (2100 MHz), 2 (1900 MHz), 4 (AWS 1700/2100 MHz), 5 (850 MHz),8 (900 MHz)
Data Rates: HSPA+ rates
Downlink up to 42 Mbps (category 24)
Uplink up to 5.76 Mbps (category 6)
GSM 850 (850 MHz), EGSM 900 (900 MHz), DCS 1800 (1800 MHz), PCS 1900 (1900 MHz)
Data Rates: EDGE throughput up to 236 kbps
GPS/GLONASS L1
C/A Code
42 / 30 seconds
Environmental
Parameter
Temperature
Environmental
Dimensions (H x W x D)
Weight
Power Supply Voltage
Power Consumption
Average)
Housing/Color
Antenna Connector
18
Specification
Operating –40 C to +70 C
o o
Storage –40 C to +85 C
o o
IP 67
5.75 x 2.95 x1.73 inches (146 x75 x44 mm)
1.07 lbs (488 g)
+9 to +36 VDC nominal
18W / 2W / 0.01W –Transmit / Receive / Sleep
Aluminum / Two-tone Green / Gray
TNC, 50Ω
