Javad HPT404BT JL User Manual page 13

In the Communication/Power Management
tab activate the UHF interface:
Figure 18. HPT404BT JL Power Management tab
Detailed connection status you can check in
Status/UHF int. tab
Figure 19. HPT404BT JL UHF Int. Status tab
3. Setup Serial Port
In the Communication/Advanced tab select
"Serial port as" parameter as Terminal.
Click "Save Setting" button and wait until
finish.
HPT404BT JL USER MANUAL
Figure 20. HPT404BT JL Advanced tab
4. Reboot device
In the Administration/Management tab click
"Reboot" button and wait until reboot.
Figure 21.
agement tab
5. Setup Router
In the Setup/Router tab select following pa-
rameters "UHF Modem" as Source and "Se-
rial port" as Destination.
Click "Save Setting" button and wait until
finish.
13
HPT404BT JL Administration Man-
