Javad HPT404BT JL User Manual page 11

Figure 12. HPT404BT JL Advanced tab
4. Reboot device.
Management tab click "Reboot" button and
wait until reboot.
Figure 13. HPT404BT JL Administration Man-
agement tab
5. Setup Router. In the Setup/Router tab se-
lect following parameters "NTRIP Client" as
Source and "Serial port" as Destination. Click
"Save Setting" button and wait until finish.
HPT404BT JL USER MANUAL
In the Administration/
Figure 14. HPT404BT JL NTRIP Data Router tab
6. Setup NTRIP Client. In the Services/NTRIP
tab set following parameters: "Server name/
address", "Port", "User" , "Password" .
Figure 15. HPT404BT JL NTRIP configuration tab
Click "Save Setting" button and wait until fin-
ish.
11
