How to use the AEKD-USBTYPEC1 kit

Step 1. Plug the AEK-USB-2TYPEC1 board on the SPC58EC-DISP
The
the 4x20 female pin connector from pins A18 to D37 (refer to pin numbering indications on the board).
Step 2. Connect the 1-Amp 12-Volt power supply plug into the socket located on the
turn on the board.
After about 5 seconds, the ROLE LED on the
1 Hz to indicate the board is a provider.
Step 3. Connect a consumer to a USB Type-C port
You can connect one or two consumers to one or both USB Type-C ports. The USB Type-C ports
supply 5 V each and 500 mA in total for both ports.
UM2451 - Rev 1
AEK-USB-2TYPEC1 is plugged into the 4x37 male pin connector of the
Figure 4. AEKD-USBTYPEC1 plugged on SPC58EC-DISP
Figure 5. Voltage supply socket and power switch on SPC58EC-DISP
How to use the AEKD-USBTYPEC1 kit
AEK-USB-2TYPEC1 board should start blinking at rate of
UM2451
SPC58EC-DISP board via
SPC58EC-DISP and then
page 4/22
