Quadstick User Manual page 79

touch normal lip
The "touch" output presses the touchpad and is probably all that is normally needed. The directional outputs allow
the position of the touch to be controlled. See the configuration spreadsheet PS4 Full Crossover Default for an
example.
The user has the option of not connecting the DS4 to USB A and operating in partial-crossover if a second player
needs to use the DS4. The Quadstick will need to be unplugged and plugged back in to the PS4 again if the DS4
is removed after power is applied. If the DS4 is plugged into the USB A port after power up, and the system is in
partial-crossover mode, it will switch to full-crossover when the next interruption timeout occurs.
When the DS4 is being used with the USB A port, do not turn it on. Use the front panel button to start the PS4.
The DS4 will appear to be off, but will be providing a stream of data to the Quadstick.
The Dual Shock 4 controller must be properly configured and prepared
before use.
79
